Summary of Contents for CUOGHI Nader Yard Pro Series
- Page 2 A A A A B B B B...
-
Page 5: Table Of Contents
Table of contents Table of contents Table of contents Table of contents References (A, B) ........................2 Symbols used in the manual ....................2 Introduction ..........................2 Operating principle (B)......................2 Hot gas defrosting (A,B)...................... 2 Installation rules ........................3 Condensate drain pipe...................... -
Page 6: References (A, B)
References (A, B) 1. Humidistat (optional) 6. Defrost solenoid valve 11. Evaporator 2. Relay 7. Temperature probe 12. Condenser 3. Compressor 8. General switch 13. Capillary 4. Fan 9. Electronic card 14. Hour counter (optional) 5. Defrost pilot light 10. Air flow Symbols used in the manual SYMBOL MEANING... -
Page 7: Installation Rules
Installation rules Condensate drain pipe The only installation required, for the dehumidifier to operate correctly, is that of the condensate drain pipe: the condensate is drained continuously through a connection on the right side of the machine, as shown in Figure 1. The drain pipe must be positioned so that the water may flow off: there must not, therefore, be any obstacles along the way, the pipe must not be kinked and must always have a certain slope, and, at... -
Page 8: Humidistat (Optional)
Humidistat (optional) This optional device allows more accurate control of the environmental humidity (Figure 2); installation: the humidistat is simply connected to the dehumidifier by means of the special socket on the control panel. The humidistat can be hung on the wall or simply hooked onto the N handle. -
Page 9: Storage
Protect your nose and mouth with the appropriate mask to avoid inhaling the dust when cleaning with compressed air. As far as possible, try not to touch the coil battery fins to avoid damaging them. Once cleaning is done, refit the mantle by following the instructions by working in the reverse order (from the last to the first), taking special care to re-connect the ground wire to the faston connector on the mantle: first set down the upper part while at the same time slipping the sides into the appropriate lodgings that keeps it with the panels. -
Page 10: Technical Data
Technical Data ADER ARD PRO Condensate capacity * 48 L/24ore ** 81 L/24ore Working limit temperatures +2°C / +32°C Working limit relative humidity 35% ÷ 100% Air Flow rate 236 L/s (850 m³/ora) Power supply voltage 230V, 50Hz Current absorption * 4,1A ** 4,8A Power absorption...
