Summary of Contents for Mee-go SWIRL
-
Page 2: Table Of Contents
CONTENTS: HOMOLOGATION CORRECT POSITION IN THE VEHICLE SAFETY IN THE VEHICLE PROTECTING THE VEHICLE USING THE CAR SEAT IN THE VEHICLE REARWARD-FACING USE(PART 1) FORWARD-FACING USE(PART 1) INSTALLING IN VEHICLE ADJUSTING THE SUPPORT LEG REMOVING FROM THE VEHICLE ADJUSTING THE RECLINING POSITION REARWARD-FACING USE(PART 2) 360 °... -
Page 3: Homologation
HOMOLOGATION: 18KG 01*0052*00 Dear Customer, thankyou very much for purchasing the new Mee-go swirl 360 Car seat. Please refer to the vehicle manufacturer's handbook in order to have a great experience with the new Swirl I-Size Car seat. WARNING! To properly protect your child, it is essential to use and install the car seat... -
Page 4: Correct Position In The Vehicle
CORRECT POSITION IN VEHICLE: This is an I-Size Child Restraint system. It is approved to ECE R129, for use in I-Size compatible vehicle seating positions as indicated by vehicle manufacturers in the user manual. If your vehicle does not have an I-Size seating position, please check the vehicle type list included on our website to check if the installation is allowed. -
Page 5: Safety In The Vehicle
SAFETY IN THE VEHICLE: WARNING! Never use the car seat on a vehicle seat with an activated front airbag. This does not apply to so-called side airbags. In order to guarantee the best possible safety for all passengers make sure that: foldable backrests in the vehicle are locked in their upright position when installing the car seat on the front passenger seat, adjust the vehicle seat to rearmost position... -
Page 6: Using The Car Seat In The Vehicle
40cm-105cm USING THE CAR SEAT IN THE VEHICLE: Depending on age and size of the infant, the car seat may be used forward- facing and rear ward-facing. NOTE! Accident statistics and leading crash tests all verify that rearward facing travel is the safest way to transport children. -
Page 7: Installing In Vehicle
INSTALLING IN VEHICLE: Note! If your vehicle does not have an I-Size seating position, please check the vehicle type list that is included. Please select an appropriate seat in the vehicle Unfold the support leg (1), until it locks Pull the isofix extent strap (8A) under seat body, and both ISOFIX (3) will extend out automatically The safety indicator must be clearly visible on both ISOFIX release buttons Push the seat towards the backrest until it is fully aligned with the backrest Latch both ISOFIX attachments on the car seat onto the corresponding ISOFIX lower anchorage... -
Page 8: Adjusting The Support Leg
ADJUSTING THE SUPPORT LEG: To fix the support leg in the forward position: Press the support leg switches (8) whilst simultaneously pulling out the support leg Pull out the support leg until it safely stands on the vehicle floor. Press the support leg adjustment buttons (9) and pull the support leg to the next locking position to ensure optimal force absorption. -
Page 9: Removing From The Vehicle
REMOVING FROM THE VEHICLE: Perform the installation procedure in reverse order: Unlock the ISOFIX connectors (3) on both sides by pressing release buttons (4) and withdrawing simultaneously Push the ISOFIX extent strap (8A) under the seat body to adjust both the ISOFIX connectors (3) to the short position Pull out the car seat from the ISOFIX anchorage points. -
Page 10: Adjusting The Reclining Position
ADJUSTING THE RECLINE POSITION: This I-Size car seat offers different sitting and reclining positions for the safe and comfortable transport of your child. To adjust the seat, activate the position adjustment handle (11) on the front of the car seat. When the car seat is rearward facing please use only the seat position shown in the blue on the backrest position label and for forward facing car seat please only choose from 3 seat positions shown in red on the backrest position label. -
Page 11: Rearward-Facing Use(Part 2)
REARWARD-FACING USE (PART2): (40-105cm) To adjust the headrest (13): NOTE! The newborn inlay protects your child and should be used up to size of 60cm NOTE! The headrest ensures the best possible protection for you child only if its adjusted to the optimum height. -
Page 12: 360 Rotation
360 ROTATION: The car seat can be rotated 360 , to make it easier to put your child into and take out of the vehicle. This also allows you to change the position from rearward-facing to forward-facing. Push rotation button 14, to rotate the seat shell towards the door to strap the child in without difficulty, please also see chapter, “Securing by means of harness system”. -
Page 13: Securing By Means Of Harness System
SECURING BY MEANS OF A HARNESS SYSTEM: The shoulder belts are firmly attached to the headrest and must not be adjusted separately. NOTE! Ensure that the headrest is correctly locked in place before using the car seat. NOTE! Ensure that the car seat is free from toys and hard objects. Loosen shoulder belts by pressing the adjustment button (16) on central adjuster and simultaneously pulling both shoulder belts (17) up NOTE! Always pull on the shoulder belts, do not pull on the belt pads. -
Page 14: Forward-Facing Use(Part 2)
FORWARD-FACING USE (PART 2): (76cm - 105cm and older than 15 months) Using the seat in the forward-facing position is permitted if the child is older than 15 months and minimum 76cm tall. In order to offer your child the highest level of protection, we recommend to use the car seat in the rearward-facing position for as long as possible. -
Page 15: Securing The Child Correctly
SECURING THE CHILD CORRECTLY: To ensure optimum safety for your child, please always check before commencing travel that: the ISOFIX connectors (3) are correctly fastened to the vehicle and the support leg (1) has been correctly installed the seat is locked in either rearward or forward facing position the headrest has been adjusted to the correct height the 5 point harness has been locked the support leg (1) has been stood on the car floor safely and the support leg indicator (10) shows... -
Page 16: Removing The Newborn Inlay
REMOVING THE NEWBORN INLAY: The preinstalled newborn inlay (21) helps to support, lying comfort and fit for the smallest babies. The newborn inlay may be removed after the baby is 61cm (approximately 3 months old) to provide more space for the child. To remove the newborn inlay open the snap buttons of the headrest cover. -
Page 17: Removing The Cover
REMOVING THE COVER: The cover consists of 7 components fixed to the seat shell by hook and loop fastener, elastic piping, snap buttons and brackets. Once you have released all of the fastenings, you can remove the individual components for washing. Proceed as follows: Open the belt buckle of the 5-point belt system Open all of the snap buttons of the pads and cover parts... -
Page 18: Cleaning
Make and model of the vehicle and the position of the vehicle seat on which the car seat is used Weight, age and height of the child Further information about our products can be found at the our website: www.mee-go.co.uk/... -
Page 19: Product Durability
This car seat is exclusively available through our chain of retailers & distributors around the world. Contact Mee-go: Mee-go Ltd Unit 5, Victoria Mills British Design...
