Summary of Contents for Vista Optio OPA Camera
- Page 1 OPA Camera User Guide Please read this manual thoroughly before use and keep it handy for future reference. OPA camera user manual version 1.1...
- Page 3 Norbain SD, Inspired, Easthampstead Road, Bracknell, Berkshire, RG12 1YQ, England. UK +44 (0) 118 912 5000 / Vista Technical Support +44 (0) 118 912 5125 Note: You should be at the equipment and ready with details before calling Technical Support.
-
Page 4: Important Safety Instructions
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. - Page 5 General Introduction Overview This series of HDCVI camera comply with the HDCVI 3.0 standard. It supports long-distance video transmission and control over a single coaxial cable without any delay. They produce high definition video and can be controlled by the OPDVR using HDCVI 3.0 protocols. Features CMOS image sensor, megapixel definition.
-
Page 6: Extension Cable
Extension Cable Item Description Inputs 12V DC power. Please be sure to supply power as instructed in the Manual. 12V DC Power Input Device abnormity or damage could occur if power is not supplied correctly. Video Output Connects to XVR to output video signal Dial switches to change output mode. -
Page 7: Installation
Installation PLEASE REFER TO QSG FOR INSTALLATION INSTRUCTION. OSD menu structure SETUP MENU FORMAT FORMAT VIDEO MODE * VIDEO MODE BACK LIGHT MODE 4M CVI IMAGE ADJUST NTSC 1080 CVI EXPOSURE 720 CVI WHITE BALANCE 4M TVI DAY NIGHT LANGUAGE 4M AHD ADVANCED DEFAULT... - Page 8 OSD advanced menu structure ADAVANCED CAMERA NAME CAMERA NAME MIRROR MIRROR H MIRROR SMART IR VOLTAGE PROMPT PRIVACY MASK V MIRROR LENS RESET SYTEM INFO SMART IR VOLTAGE PROMPT PRIVACY MASK LENS RESET SYSTEM INFO DEFAULT ON / OFF RESET VERSION AREA SELECT DISPLAY...
- Page 9 Setup OPDVR Settings The Optio HDCVI camera series can be adjusted via the OSD using coaxial control After connecting to the camera with the OPDVR, select Main Menu->Setting->Camera->PTZ Choose the channel number and verify control mode - HDCVI and the protocol - HDCVI3.0 Click Save to confirm setup.
-
Page 10: Menu Operation
Menu Operation Right click the mouse and select “PTZ Control”, the PTZ interface is displayed. Click the Enter Menu icon to open the MENU OPERATION interface. - Page 11 Using a mobile phone scan the above QR code for a link to all literature and available software. NORBAIN SD Inspired Easthamptead Road Bracknell Berkshire RG12 1YQ (Subject to change without notice)
