VBC13MC / VBC13M/P Monochrome Board Camera
Thank you for choosing this high quality camera, before attempting to connect or operate this product, please
read these instructions completely the instruction carefully.

General

This Monochrome CCD video camera employs a 1/3" Sony CCD device, which provide extremely long life
and high reliability. The camera offers excellent reproducibility with low lag and high burn resistance, and is
not subject to distortion from magnetic fields and the camera functions reliability in wide temperature range.

Features

1. 1/3" Sony Colour CCD image sensor.
2. 380 TV lines of horizontal resolution and high quality picture.
3. Built in Auto Electronic Shutter.
4. Minimum illumination of 0.25 Lux / F2.0.
5. Signal-to-noise ratio of 46dB.
6. Long life and high reliability.

SPECIFICATION

Pick up Element
Number of Pixel
Resolution
Min. Illumination
S/N Ratio
Electronic Shutter
Video Output
Gamma Correction
White Balance
AGC
Standard Pinhole Lens
Pinhole Lens
Lens Angle
Power Source
Current Consumption
Dimension (mm)
Weight

INSTRUCTION MANUAL

1/3" Monochrome CCD image sensor
Board Lens: 36(W) x 36(H) x 14(D)
Pinhole Lens: 36(W) x 36(H) x 13(D)
500(H) x 582(V) <CCIR>
380 TV lines
0.25 Lux / F2.0
More than 46dB(AGC off)
1/50 to 1/100,000 sec.
1.0Vp-p composite75O
0.45
Auto white balance
Yes
F3.7mm / F2.0
F5.5mm / F3.5
o
Board Lens: 92
o
Pinhole Lens: 70
DC12V±10%
120mA( activated)
Board Lens: 105g
Pinhole Lens: 95g
