Customer satisfaction is important to us at Dorel Asia. Our agents are available Monday to Friday 8am to 5pm (EST) to answer any question you may have. For faster service, always have the model number ready when calling our toll free number 1-800-295-1980 or emailing us at das@dorel.com .
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 HARDWARE LIST Ø1/4"*1/2" φ1/4"*3/4" BOLT BOLT 12 PCS 8 PCS φ5/32"*1-1/8" φ1/8"*5/8" ROUND HEAD SCREW FLAT HEAD SCREW 8 PCS 8 PCS ALLEN KEY 1 PC...
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 PARTS LIST TABLE TOP TABLE LEG TABLE TOP FRAME 1 PC 4 PCS 1 PC TABLE BASE SEAT BOARD STOOL LEG 1 PC 2 PCS 2 PCS STOOL LEG STOOL BASE...
Page 5
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 STEP 1 Attach table legs (B) to table top frame (C ) and table base (D) with bolts (1) and Allen key (5). Do not fully tighten the bolts. This will facilitate assembly in the next step.
Page 6
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 STEP 2 With the help of another person, place the assembled table frame on table top (A) as shown below. Attach table legs (B) to table top (A) using round head screws (3) and a Phillips head screwdriver (not included).
Page 7
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 STEP 3 Connect the stool legs (F) and (G) as shown below. Attach the stool base (H) to the stool legs (F & G) using bolts (2) and Allen key (5).
Page 8
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 STEP 4 With the help of another person, place the assembled stool frame on top of seat board (E) as shown below. Attach the stool legs (F & G) to seat board (E) using flat head screws (4) and a Phillips head screwdriver (not included).
Page 9
ROUND 3PC METAL PUB SET WITH WOOD TOP DL7685 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury.
Page 10
MODEL #: DL7685 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
Page 11
Caoba / Negro ¡Felicitaciones por su nueva compra de un mueble! Los muebles de la línea Dorel Living han sido diseñados con la calidad, la comodidad y el estilo en mente. Estamos seguros de que este mueble le servirá por muchos años con su comodidad excepcional.
GARANTÍA LIMITADA Dorel garantiza que este producto está libre de defectos de material y mano de obra y se compromete a remediar cualquiera de esos defectos. Esta garantía cubre 1 año a partir de la fecha de compra original. Esta garantía es válida únicamente si se presenta una prueba de compra.
JUEGO DE PUB REDONDA 3 PZ DE METAL CON TAPA DE MADERA DL7685 LISTA DE ACCESORIOS Ø1/4"*1/2" φ1/4"*3/4" PERNO PERNO 12 PCS 8 PCS φ5/32"*1-1/8" φ1/8"*5/8" TORNILLO DE CABEZA REDONDA TORNILLO DE CABEZA PLANA 8 PCS 8 PCS LLAVE ALLEN...
JUEGO DE PUB REDONDA 3 PZ DE METAL CON TAPA DE MADERA DL7685 LISTA DE PIEZAS TAPA DE MESA PATA DE MESA MARCO DE TAPA DE MESA 1 PC 4 PCS 1 PC BASE DE MESA ASIENTO PATA DE TABURETE...
Page 15
JUEGO DE PUB REDONDA 3 PZ DE METAL CON TAPA DE MADERA DL7685 ETAPA 1 Una las patas de la mesa (B) con el cuadro de la tapa de la mesa (C ) y la base de la mesa (D) con pernos (1) y la llave Allen (5).
Page 16
JUEGO DE PUB REDONDA 3 PZ DE METAL CON TAPA DE MADERA DL7685 ETAPA 2 Con la ayuda de otra persona, coloque el cuadro de la mesa ya ensamblado sobre la tapa de la mesa (A) como ilustrado más abajo. Una las patas de la mesa (B) con la tapa de la mesa (A) con tornillos de cabeza redonda (3) y un destornillador Phillips (no incluido).
Page 17
JUEGO DE PUB REDONDA 3 PZ DE METAL CON TAPA DE MADERA DL7685 ETAPA 3 Una las patas del taburete (F) y (G) como ilustrado más abajo. Una la base del taburete (H) con las patas del taburete (F y G) con pernos (2) y la llave Allen (5).
Page 18
JUEGO DE PUB REDONDA 3 PZ DE METAL CON TAPA DE MADERA DL7685 ETAPA 4 Con la ayuda de otra persona, coloque el cuadro del taburete ya ensamblado sobre el asiento (E) como ilustrado más abajo. Una las patas del taburete (F y G) con el asiento (E) con tornillos de cabeza plana (4) y un destornillador Phillips (no incluido).
Page 19
Si falta una pieza o está dañada, contacte nuestro departamento de servicio a la clientela. Reemplazaremos la pieza SIN cargo. Tel #: 1-800-295-1980 NEED HELP! Correo electrónico: das@dorel.com CALL US FOR ASSISTANCE Fax #: 514-353-7819 1-800-295-1980 DO NOT RETURN PRODUCT TO S...
Page 20
MODELO #: DL7685 Servicio a la Clientela POR FAVOR, NO DEVUELVA ESTE PRODUCTO A LA TIENDA POR FAVOR, CONTACTE LOS REPRESENTANTES DEL SERVICIO A LA CLIENTELA A LOS SIGUIENTES NÚMEROS SI FALTA UNA PIEZA O ESTÁ DEFECTUOSA. Número de teléfono del Servicio a la Clientela 1-800-295-1980 Email: das@dorel.com...
Page 21
Acajou / Noir Félicitations pour votre dernier achat d’un meuble ! Les meubles de la ligne Dorel Living ont été conçus ayant en tête la qualité, la commodité et le style. Nous sommes convaincus que ce meuble vous servira durant de nombreuses années avec un confort exceptionnel.
GARANTIE LIMITÉE Dorel garantit que ce produit est exempt de défauts de matériel et de fabrication et s'engage à remédier à un tel défaut. Cette garantie couvre un (1) an à compter de la date d'achat originale. Cette garantie est valide uniquement sur présentation d'une preuve d'achat.
Page 23
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 LISTE DE QUINCAILLERIE Ø1/4"*1/2" φ1/4"*3/4" BOULON BOULON 12 PCS 8 PCS φ5/32"*1-1/8" φ1/8"*5/8" VIS À TÊTE ARRONDIE VIS À TÊTE PLATE 8 PCS 8 PCS CLÉ ALLEN 1 PC...
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 LISTE DE PIÈCES DESSUS DE TABLE PIED DE TABLE CADRE DESSUS DE TABLE 1 PC 4 PCS 1 PC BASE DE TABLE SIÈGE PIED DE TABOURET 1 PC...
Page 25
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 ÉTAPE 1 Attachez les pieds de la table (B) au cadre du dessus de la table (C) et à la base de la table (D) avec des boulons (1) et la clé Allen (5).
Page 26
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 ÉTAPE 2 Avec l’aide d’une autre personne, placez le cadre de la table déjà assemblé sur le dessus de la table (A) tel qu’illustré ci-dessous. Attachez les pieds de la table (B) au dessus de la table (A) avec des vis à...
Page 27
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 ÉTAPE 3 Assemblez les pieds du tabouret (F) et (G) tel qu’illustré ci-dessous. Attachez la base du tabouret (H) aux pieds du tabouret (F et G) avec des boulons (2) à...
Page 28
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 ÉTAPE 4 Avec l’aide d’une autre personne, placez le cadre du tabouret déjà assemblé sur le siège (E) tel qu’illustré ci-dessous. Attachez les pieds du tabouret (F et G) avec le siège (E) avec des vis à tête plate (4) à...
Page 29
ENSEMBLE DE PUB 3 PC DE MÉTAL AVEC DESSUS EN BOIS DL7685 ATTENTION: Cette unité est conçue pour être utilisée seulement avec les produits et/ou les poids maximum indiqués. L'utilisation avec d'autres produits et/ou des produits plus lourds que les poids maximum indiqués peut entraîner de l'instabilité...
Page 30
MODÈLE #: DL7685 Service à la Clientèle S.V.P. NE PAS RETOURNER CE PRODUIT AU MAGASIN S.V.P. CONTACTEZ NOS REPRÉSENTANTS DU SERVICE À LA CLIENTÈLE AUX NUMÉROS SUIVANTS SI VOUS AVEZ DES PIÈCES MANQUANTES OU DÉFECTUEUSES. No. de téléphone du Service à la clientèle: 1-800-295-1980 Courriel: das@dorel.com...
