Installation Guide for Beam LTE Fixed
Installation Bundle (MG200-FB10 / MG200-FB20)
Beam MG200 LTE Gateway
Package Contents
1 x Beam MG200 LTE Gateway Kit
20m
20m
2 x Beam LTE933 20m Cable
(MG200-FB20 only)
Optimal Antenna Installation Location
• Antenna front panel to face the service provider tower
• Antenna must be installed with a separation distance
of at least 20cm away from all persons
• Install under the cover of the lightning rod
Applications
FARM
For more information please visit: beamcommunications.com/cellular
Beam LTE932 10m Cable
Beam LTE933 20m Cable
SMA
Lightning
Arrestor
(not included)
1 x Beam LTE720 Panel Antenna
10m
OR
2 x Beam LTE932 10m Cable
(MG200-FB10 only)
MINING
BUILDING
Beam LTE720
Panel Antenna
(MG200-FB10 only)
OR
N-Type
(MG200-FB20 only)
1 x Installation Guide
10m
• Keep away from heat or fumes
• Keep away from other antennas
INDUSTRIAL
