Installation Guide for Beam LTE Off-Road Bundle
(MG200-ORB)
Beam MG200 LTE Gateway
Package Contents
1 x Beam MG200 LTE Gateway Kit
1 x Beam RST708 GPS Antenna
with 5m Cable
Optimal Antenna Installation Location
• Keep away from metallic obstructions (maximise the 360° clear view of the horizon)
• Keep away from other antennas
• Antenna must be installed with a separation distance of at least 20cm away from all persons
• Keep away from heat or fumes
Applications
4WD
For more information please visit: beamcommunications.com/cellular
Beam RST708 GPS Antenna
with 5m Cable
1 x Beam LTE714 Whip Antenna
with 5m Cable
(*SMA adaptor provided if required)
1 x Installation Guide
CARAVAN
Beam LTE714 Whip Antenna
with 5m Cable
1 x Beam LTE151 Bull Bar
Mount 45mm
TRUCKS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Beam MG200
Summary of Contents for Beam MG200
- Page 1 5m Cable Beam RST708 GPS Antenna with 5m Cable Beam MG200 LTE Gateway Package Contents 1 x Beam MG200 LTE Gateway Kit 1 x Beam LTE151 Bull Bar 1 x Beam LTE714 Whip Antenna Mount 45mm with 5m Cable...
- Page 2 4. To install the MG200 LTE Gateway, refer to the MG200 LTE Gateway Quick Start Guide section 1-4. 5. Connect the SMA port of the LTE714 Whip Antenna Cable to the CELL MAIN port of the MG200 LTE Gateway. 6. Connect the SMA port of the RST708 GPS Antenna Cable to the GPS port of the MG200 LTE Gateway.
