- Page 1 BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com Intelligent CAN Bus Multi-drop Bus Fiber Optic Converter User Manual Contact: sales@bueno-electric.com Fax: +86-25-51816989...
-
Page 2: Table Of Contents
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com Table of Contents 1. Overview ................3 1.1 Introduction ……………………….……………………………..3 1.2 Technical Specification……………………………...………….3 1.3 Warranty .…………………...……………………….…..……...4 2. Installation ................5 2.1 Package Contents ………………………………………..…..5 2.2 Enclosure ................5 2.3 Install Method..............…7 2.4 Software Configuration............8... -
Page 3: Overview
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 1. Overview 1.1 Introduction The No-Cascading new CAN Fiber Optic Converter is a multi-master and high performance Field bus Control System (FCS). The modular fiber optic transmission system can be used to transmit CAN-based bus systems such as DeviceNet or CANOpen via fiber optics data interfaces over a pair of multi mode or single mode optical fibers. -
Page 4: Warranty
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 1.3 Warranty Repair Please contact your local distributors when product is defective. Please apply RA in advance and prepay shipping cost when returning the defective product to us. We will pay the cost for sending it back to you. -
Page 5: Installation
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 2 Installation 2.1 Package Contents • Fiber Optic Converter • Please contact dealer or distributor if part is missing or damaged. Enclosure Panel 1: LED Rotary button Console Power Contact: sales@bueno-electric.com... - Page 6 BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com LED: LED No LED For LED Name LED Function CAN0 Transmitting Receiving Error Failure Fiber0 & Fiber1 Transmitting Receiving Error Failure Others: Name Relevant Function Remarks Baudrate CAN0 Rotary button Configure baud rate by button,fast configuration...
-
Page 7: Install Method
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 2.3 Install Methods 1. Switch off all power supply before installation. 2. Connect the local “TX” Fiber Optic to the remote “RX” Fiber Optic, the local “RX” to the remote “TX”. And ensure that fiber is properly aligned to the receiving connector. -
Page 8: Software Configuration
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 2.4 Configure the baud rate by software Switch the “B0” button to F position and connect the straight line(NOT cross line) to the console port(DB9) and the other end of the line to the computer. - Page 9 BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com Common standard baud rate’s BTR0 and BTR1 values: CAN Baud rate BTR0(Time0-SJA1000) BTR1(Time1-SJA1000) 5Kbps 0xBF 0xFF 10Kbps 0x31 0x1C 20Kbps 0x18 0x1C 40Kbps 0x87 0xFF 50Kbps 0x09 0x1C 80Kbps 0x83 0Xff...
- Page 10 BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 500Kbps 0x00 0x1C 666Kbps 0x80 0xB6 800Kbps 0x00 0x16 1000Kbps 0x00 0x14 3.3 Filter The CAN FIB-100BT has a strong message filter,on F ilter option button,The user can set up the “...
- Page 11 BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com How to use the filter function ： (1) Select F ilter Enable a nd you can revise the content of the filter. “ ” (2) Select the channel that needs filter function from the sub list of “...
-
Page 12: Install Application
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 2.5 Install Application Contact: sales@bueno-electric.com Fax: +86-25-51816989... -
Page 13: Dimensions
BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC BUENO ELECTRIC Https://www.bueno-electric.com 3 Dimensions (mm) Contact: sales@bueno-electric.com Fax: +86-25-51816989...
