- Page 1 BUENO ELECTRIC Https://www.bueno-electric.com CAN Bus Bus Fiber Optic Converter (CAN-FIB-MIXED-P1S & P2S) User Manual...
-
Page 2: Table Of Contents
Table of Contents 1. Overview ................3 1.1 Introduction 1.2 Technical Specification 1.3 Warranty ..4 2. Installation ................5 2.1 Package Contents ..5 2.2 Enclosure ................5 2.3 Install Method..............7 2.4 Software Configuration............8 2.5 Install Application .............. 11 3. -
Page 3: Overview
1. Overview 1.1 Introduction The No-Cascading new CAN Fiber Optic Converter is a multi-master and high performance Field bus Control System (FCS). The modular fiber optic transmission system can be used to transmit CAN-based bus systems such as DeviceNet or CANOpen via fiber optics data interfaces over a pair of multi mode or single mode optical fibers. -
Page 4: Warranty
1.3 Warranty Repair Please contact your local distributors when product is defective. Please apply RA in advance and prepay shipping cost when returning the defective product to us. We will pay the cost for sending it back to you. Please attach a statement clearly describing the problem. We will repair defective product under warranty free of charge to our customer. -
Page 5: Installation
2 Installation 2.1 Package Contents • Fiber Optic Converter • Please contact dealer or distributor if part is missing or damaged. Enclosure Panel 1: Rotary button Console Power (Only button 1 & button 2 are necessary in this order) LED: LED No LED For LED Name... - Page 6 Others: Name Relevant Function Remarks Baudrate CAN0 & Rotary button Configure baud rate by button,fast configuration CAN1 RS232 CAN0 & Console port Configure baud rate by software on computer CAN1 V+ Power input DC 9~40V, With SPD,RCP,OCP V- Power input DC 9~40V,With SPD,RCP,OCP Panel 2: Fiber optic...
-
Page 7: Install Method
2.3 Install Methods 1. Switch off all power supply before installation. 2. Connect the local “TX” Fiber Optic to the remote “RX” Fiber Optic, the local “RX” to the remote “TX”. And ensure that fiber is properly aligned to the receiving connector. 3. -
Page 8: Software Configuration
2.4 Configure the baud rate by software Switch the “CAN0” button to F position and connect the straight line(NOT cross line) to the console port(DB9) and the other end of the line to the computer. 1.Open CANConfig and click“CAN FIB-MIXED”,you will see 3 options: Basic Info,Baud rate and Filter. - Page 9 Common standard baud rate’s BTR0 and BTR1 values: CAN Baud rate BTR0(Time0-SJA1000) BTR1(Time1-SJA1000) 5Kbps 0xBF 0xFF 10Kbps 0x31 0x1C 20Kbps 0x18 0x1C 40Kbps 0x87 0xFF 50Kbps 0x09 0x1C 80Kbps 0x83 0Xff 100Kbps 0x04 0x1C 125Kbps 0x03 0x1C 200Kbps 0x81 0xFA 250Kbps 0x01 0x1C...
- Page 10 3.3 Filter The CAN FIB-MIXED has a strong message filter,on F ilter option button,The user can set up “ ” the filter.This function depends on the work condition of the user. How to use the filter function ： (1) Select F ilter Enable a nd you can revise the content of the filter.
-
Page 11: Install Application
2.5 Install Application... -
Page 12: Dimensions
3 Dimensions (mm)
