- Page 1 BUENO ELECTRIC Https://www.bueno-electric.com CAN Bus Fiber Optic Converter User Manual Contact:sales@bueno-electirc.com...
-
Page 2: Table Of Contents
BUENO ELECTRIC Https://www.bueno-electric.com Table of Contents 1. Overview ................3 1.1 Introduction 1.2 Technical Specification 1.3 Warranty ..4 2. Installation ................5 2.1 Package Contents ..5 2.2 Enclosure ................5 2.3 Install Method..............7 2.4 Software Configuration............8 2.5 Install Application .............. -
Page 3: Overview
BUENO ELECTRIC Https://www.bueno-electric.com 1. Overview 1.1 Introduction The No-Cascading new CAN Fiber Optic Converter is a multi-master and high performance Field bus Control System (FCS). The modular fiber optic transmission system can be used to transmit CAN-based bus systems such as DeviceNet or CANOpen via fiber optics data interfaces over a pair of multimode or single mode optical fibers. -
Page 4: Warranty
BUENO ELECTRIC Https://www.bueno-electric.com Dimensions (H ×L×W) 112(H)×147(W)×36(D)MM 1.3 Warranty Repair Please contact your local distributors when product is defective. Please apply RA in advance and prepay shipping cost when returning the defective product to us. We will pay the cost for sending it back to you. -
Page 5: Installation
BUENO ELECTRIC Https://www.bueno-electric.com 2 Installation 2.1 Package Contents • Fiber Optic Converter • Please contact dealer or distributor if part is missing or damaged. Enclosure Panel 1: LED: LED No LED For LED Name LED Function CAN0 Transmitting Contact:sales@bueno-electirc.com... - Page 6 BUENO ELECTRIC Https://www.bueno-electric.com Receiving Error Failure Fiber0 Transmitting Receiving Error Failure Others: Name Relevant Function Remarks Baudrate CAN0 Rotary button Configure baud rate by button,fast configuration RS232 CAN0 Console port Configure baud rate by software on computer V+ Power input...
-
Page 7: Install Method
BUENO ELECTRIC Https://www.bueno-electric.com 2.3 Install Methods 1. Switch off all power supply before installation. 2. Connect the local “TX” Fiber Optic to the remote “RX” Fiber Optic, the local “RX” to the remote “TX”. And ensure that fiber is properly aligned to the receiving connector. -
Page 8: Software Configuration
Switch the “B0” button to F position and connect the straight line(NOT cross line) to the console port(DB9) and the other end of the line to the computer. 1.Open CANConfig and click“CAN FIB-100PT”,you will see 3 options: Basic Info,Baudrate and Filter. - Page 9 BUENO ELECTRIC Https://www.bueno-electric.com 3.Device Parameters 3.1 Basic Info Click the “Open RS232” and read out all information by clicking “Read Parameter” button.The “Basic info” option contains the vendor ID,device type,device code,hardware version,software version and serial numbers. 3.2 Baudrate B audrate” is for setting up the baud rate of all channels of the device.When the rotary button is “...
- Page 10 0x00 0x16 1000Kbps 0x00 0x14 3.3 Filter The CAN FIB-100PT has a strong message filter,on F ilter option button,The user can set up the “ ” filter.This function depends on the work condition of the user. How to use the filter function ：...
-
Page 11: Install Application
BUENO ELECTRIC Https://www.bueno-electric.com (1) Select F ilter Enable a nd you can revise the content of the filter. “ ” (2) Select the channel that needs filter function from the sub list of P ort “ ” (3) Select the frame type(Standard or extended frame types) from the “Frame Type” . -
Page 12: Dimensions
BUENO ELECTRIC Https://www.bueno-electric.com 3 Dimensions (mm) Contact:sales@bueno-electirc.com...
