Hardware Installation

Requirements

•
Intel
•
A host system/board with the TPM connector on the board
The TPM module docks into a connector on the baseboard and is retained by a tamper
resistant screw. Below is a drawing of the physical dimension of the TPM module.
Note: Measurements are in millimeters.
Intel® Trusted Platform Module Hardware User's Guide
®
Trusted Platform Module
®
Trusted Platform Module , with the provided standoffs
Figure 2. TPM module Dimensioned Drawing
