- Page 1 ® Intel Trusted Platform Module (TPM module-AXXTPME3) Hardware User’s Guide Intel Order Number: G21682-003...
- Page 2 Intel literature, may be obtained by calling 1-800-548-4725, or go to: http://www.intel.com/design/literature.htm Intel ® is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries. *Other names and brands may be claimed as the property of others.
-
Page 3: Preface
• Chapter 3 provides the procedures for configuring the Intel TPM module. ® • Chapter 4 provides the characteristics and technical specifications for the Intel TPM module. • Appendix A provides safety instructions to be observed during installation and assembly. - Page 4 Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 5: Table Of Contents
Security Screen ........................6 Intel® Trusted Execution Technology (Intel® TXT) ............... 7 Overview ........................7 Intel® TXT hardware overview ..................8 Enabling Intel® TXT on Intel® Server Board ..............8 ® Intel Trusted Platform Module Characteristics ............ 11 TPM module Connector List & Pinouts ................11 A. - Page 6 Intel® Trrusted Platform Module Hardware User’s Guide...
- Page 7 List of Figures Figure 1. TPM module....................... 1 Figure 2. TPM module Dimensioned Drawing................3 Figure 3. Setup Utility – TPM Configuration Screen..............6 Intel® Trusted Platform Module Hardware User’s Guide...
- Page 8 Intel® Trusted Platform Module Hardware User’s Guide...
- Page 9 List of Tables Table 1. TPM Setup Utility – Security Configuration Screen Fields .......... 7 Table 2. TPM module Connector Pin-out ................11 Intel® Trusted Platform Module Hardware User’s Guide...
- Page 10 Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 11: Overview
® ® The Intel TPM module is a common board across the series of Intel servers and baseboards (for a list of supported servers and baseboards, please refer: http://www.intel.com/support/motherboards/server/sb/CS-032301.htm). The TPM module is a small board that provides hardware level security for the server. The TPM module docks into a connector on the baseboard and is retained by a tamper resistant screw. - Page 12 Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 13: Intel Trusted Platform Module Hardware Installation
The TPM module docks into a connector on the baseboard and is retained by a tamper resistant screw. Below is a drawing of the physical dimension of the TPM module. Note: Measurements are in millimeters. Figure 2. TPM module Dimensioned Drawing Intel® Trusted Platform Module Hardware User’s Guide... -
Page 14: Installing The Tpm Module
4. Press down gently but firmly to ensure that the module is properly seated in the connectors, and then tighten the tamper resistant screw. Intel® Trusted Platform Module Hardware User’s Guide... -
Page 15: Configuring The Tpm Module
3. The BIOS verifies the physical presence and confirms the command with the operator. 4. The BIOS executes TPM administrative command(s), inhibits BIOS Setup entry and boots directly to the operating system which requested the TPM command(s). Intel® Trusted Platform Module Hardware User’s Guide... -
Page 16: Tpm Security Setup Options
TPM ownership security key was lost. Security Screen The Security screen provides fields to enable and set the user and administrative ® passwords and to lock out the front panel buttons so they cannot be used. The Intel ® server boards support Intel TPM module. -
Page 17: Intel® Trusted Execution Technology (Intel® Txt)
Trusted Execution Technology (Intel TXT) for safer computing, formerly code ® named LaGrande Technology, is a versatile set of hardware extensions to Intel processors and chipsets that enhance the platform with security capabilities such as ® measured launch and protected execution. Intel... -
Page 18: Intel® Txt Hardware Overview
In turn, this can help to protect vital data and processes from being compromised by malicious software running on the platform. Long available on client platforms, Intel is now enabling Intel TXT on selected server platforms as well. Intel® TXT hardware overview Implementation of a Trusted Execution Technology-enabled platform requires a number of hardware enhancements. - Page 19 ® Intel TXT Setup: ® 1. Go to BIOS Setup Menu, Advanced > Processor Configuration, set Intel ® for directed I/O and Intel TXT option as Enabled. ® 2. Press F10 to save and exit. Now Intel TXT is successfully enabled.
- Page 20 Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 21: Intel Trusted Platform Module Characteristics
FCI 20021321-00014D4LF, or equivalent connector on the server board. Table 2. TPM module Connector Pin-out Name Name LPC_LAD<1> Key Pin LPC_LAD<0> LPC_FRAME_N IRQ_SERIAL P3V3 CLK_33M_TPM RST_IBMC_NIC_N LPC_LAD<3> LPC_LAD<2> Intel® Trusted Platform Module Hardware User’s Guide... - Page 22 Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 23: Installation/Assembly Safety Instructions
When working inside your computer: • Do not attempt to service the computer system yourself, except as explained in this guide and elsewhere in Intel documentation. Always follow installation and service instructions closely. • Turn off your computer and any peripherals. - Page 24 • When transporting a sensitive component, first place it in an antistatic container or packaging. • Handle all sensitive components in a static-safe area. If possible, use antistatic floor pads and workbench pads. Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 25: English
4. Insert and lock the padlock to the system to prevent unauthorized access inside the system. 5. Connect all external cables and the AC power cord(s) to the system. Intel® Trusted Platform Module Hardware User’s Guide... -
Page 26: Deutsch
Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel-Serverplatinen und -Servergehäusen auf der Ressourcen-CD oder unter http://www.intel.com/support/motherboards/server/sb/cs-010770.htm. Der Wechselstrom des Systems wird durch den Ein-/Aus-Schalter für Gleichstrom nicht ausgeschaltet. -
Page 27: Français
Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce ® document avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le CD Resource CD ou bien rendez-vous sur le site http://www.intel.com/support/motherboards/server/sb/cs-010770.htm. - Page 28 4. Remettez le cadenas en place et verrouillez-le afin de prévenir tout accès non autorisé à l'intérieur du système. 5. Rebranchez tous les cordons d'alimentation c. a. et câbles externes au système. Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 29: Español
Para ello: 1. Desbloquee y extraiga el bloqueo de seguridad de la parte posterior del sistema, si se ha instalado uno. 2. Extraiga y guarde todos los tornillos de las tapas.Extraiga las tapas. Intel® Trusted Platform Module Hardware User’s Guide... -
Page 30: Italiano
Il cavo è considerato il dispositivo d'interruzione dell'alimentazione principale (in c.a.). La presa alla quale si collega il sistema deve essere installata vicino all'unità e deve essere facilmente accessibile. Intel® Trusted Platform Module Hardware User’s Guide... - Page 31 Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione. Intel® Trusted Platform Module Hardware User’s Guide...
- Page 32 Intel® Trusted Platform Module Hardware User’s Guide...
-
Page 33: Regulatory And Certification Information
® This Intel TPM module has been evaluated for regulatory compliance as an Intel end system, and is included as part of the end system certification. For information on end system certification, refer to the product regulatory certification for the end system level product. - Page 34 Intel® Trusted Platform Module Hardware User’s Guide...
