- Page 1 Intel® RealSense™ ID Solution F450, F455 Datasheet Intel ® RealSense™ ID Solution F450, Intel® RealSense™ ID Solution F455 January 2021 Revision 001 Rev: 001...
- Page 2 Intel technologies’ features and benefits depend on system configuration and may require enabled hardware, software or service activation. Learn more at Intel.com, or from the OEM or retailer. No computer system can be absolutely secure. Intel does not assume any liability for lost or stolen data or systems or any damages resulting from such losses.
-
Page 3: Table Of Contents
Orientation ................... 20 System Tilt ..................20 3.5.1 Heat Sink ................21 Software Definition ..................22 Intel® RealSense™ ID SDK for Facial Authentication ......... 22 Face Authentication ................22 System Integration ..................24 Product Assembly ................. 24 5.1.1 Optical Assembly Considerations ..........25 Trigger Heuristic ................... - Page 4 6.2.10 Customs Union ................ 32 Ecology Compliance ................33 6.3.1 China RoHS Declaration ............33 6.3.2 Waste Electrical and Electronic Equipment (WEEE) ....... 34 6.3.3 Turkey ................... 34 Mechanical Drawings ..................35 Appendix A – Interposer Reference Designs ............36 Rev: 001...
- Page 5 List of Figures Figure 1-1: Intel® RealSense™ ID Solution F450 Module ........8 Figure 1-2: Intel® RealSense™ ID Solution F450 Module Host System Topology ..9 Figure 2-1: Intel® RealSense™ ID Solution F450 Module Front Side ...... 10 Figure 2-2: Intel® RealSense™ ID Solution F450 Module Rear Side ....... 10 Figure 2-3: Intel®...
- Page 6 Table 2-2: Data Interface ................. 11 Table 2-3: Power Interface ................11 Table 2-4: Power Consumption ................12 Table 2-5: Intel® RealSense™ ID Solution F450 Module Pin Out ......12 Table 2-6. Interposer Interconnect Signal Description ......... 13 Table 2-7: Camera Parameters ................15 Table 2-8: Lens Parameters ................
- Page 7 Revision History Revision Description Date • Initial Public Release January 2021 § § Rev: 001...
-
Page 8: Overview
RealSense™ ID Solution F450 module. Figure 1-1: Intel® RealSense™ ID Solution F450 Module The Intel® RealSense™ ID Solution F450 can be implemented as a peripheral or host. If the Intel® RealSense™ ID Solution F450 is implemented as a peripheral, the embedded host module or external host system will be responsible for defining the enrollment and authentication flows using the Intel®... -
Page 9: Figure 1-2: Intel® Realsense™ Id Solution F450 Module Host System Topology
Overview Figure 1-2: Intel® RealSense™ ID Solution F450 Module Host System Topology Rev: 001... -
Page 10: Hardware Details
Hardware Details Hardware Details The Intel® RealSense™ ID Solution F450 module is a single optical PCB subassembly with processing capabilities that the product will mount into a system chassis and connect to a host. The optical components consist of both image sensors and illumination components. -
Page 11: Host Interconnect
2.1.2 Power Interface The Intel® RealSense™ ID Solution F450 module has a peak power of up to 3W. The host system must ensure the power supply can satisfy this peak power based on the chosen Intel® RealSense™ ID Solution F450 voltage source (VDD). If the host... -
Page 12: Receptacle Pin Out
Receptacle Pin Out The host connector receptacle part number is IPEX 20708-050E. The required host cable plug for connecting the Intel® RealSense™ ID Solution F450 module must use IPEX 20709-050E. Table 2-5: Intel® RealSense™ ID Solution F450 Module Pin Out... -
Page 13: Table 2-6. Interposer Interconnect Signal Description
GPIO Output (No external PU/PD GPO_4 needed). Ground Ground USB2+ USB 2 differential pair positive Output 3V UART TxD (Output from the Intel® CPU_TxD2 RealSense™ ID Solution F450 Module) USB2- USB 2 differential pair negative Input 3V UART RxD (Input into the Intel® CPU_RxD2 RealSense™... -
Page 14: Optical System
The optical system consists of two synced semi-mechanically aligned cameras which capture images from different perspectives for the purpose of 3D triangulation to create disparity. The Intel® RealSense™ ID Solution F450 utilizes the cameras for face authentication. The right camera can provide 1080P RGB. -
Page 15: Ir Illuminators
RG0 (IEC-62471) Thermal 2.3.1 Intel® RealSense™ ID Solution F450 Thermal The Intel® RealSense™ ID Solution F450 module is designed to work indoors and outdoors across a wide temperature range. Table 2-10: Intel® RealSense™ ID Solution F450 Temperature Specifications DIMENSION UNIT... -
Page 16: Intel® Realsense™ Id Solution F455 Thermal
Firmware Upgrade The Intel® RealSense™ ID Solution F450 implements 512Mb of local storage which will contain the OS and face authentication runtime. Intel will provide a FW image Rev: 001... -
Page 17: Table 2-13: Firmware Upgrade Parameter
Hardware Details which is used for initial provisioning of the Intel® RealSense™ ID Solution F450. The FW image contains a local flash update runtime which allows the host to push new FW payloads to update the Intel® RealSense™ ID Solution F450 device. -
Page 18: Mechanical
Mechanical Mechanical The small form factor of the Intel® RealSense™ ID Solution F450 module enables integration flexibility. The host system will mount and tilt the Intel® RealSense™ ID Solution F450 module based on the system installation height specification, user height range, and user approach paths to the device. The placement and orientation of the system design will depend on the following factors. -
Page 19: Cover Glass
It is recommended to use a gasket material in between the cover glass and the Intel® RealSense™ ID Solution F450 module. The gasket material needs to be compliant so that it does not transmit chassis flex forces to the module. -
Page 20: Orientation
Intel® RealSense™ ID Solution F450 module parallel to a typical mounting surface may not cover the intended user height range for the product requirement. To mitigate, the Intel® RealSense™ ID Solution F450 module can be assembled at an angle to adjust the min and max user height for face authentication. -
Page 21: Heat Sink
3.5.1 Heat Sink Although the peak power is up to 3W, the Intel® RealSense™ ID Solution F450 module is only expected to dissipate a total of 1.3W while the optical system is activated during face authentication. This assumes a 30% duty cycle while the illumination components are active. -
Page 22: Software Definition
In this use case, one or more users will walk up to the device in the runtime or standby state, the host will notify the Intel® RealSense™ ID Solution F450 module to perform face authentication and the Intel® RealSense™ ID Solution F450 module will respond back the result. -
Page 23: Table 4-3: Performance Metrics
Software Definition Spoof Accept Rate (SAR) Recognizes a recorded sample of you as <1% you (photo or model). Table 4-3: Performance Metrics METRIC DESCRIPTION VALUE Cold Latency Cold Power Up to Face Authentication Result 2-3s Warm Latency Wake Up to Face Authentication Result 1.5s FA Flow Time to Complete Face Authentication... -
Page 24: System Integration
Figure 5-1: System Design Considerations Product Assembly The Intel® RealSense™ ID Solution F450 module is intended to be assembled into the system in a horizontal or landscape orientation. The Intel® RealSense™ ID Solution F450 module should be secured to ensure the camera and illumination extrinsic specifications are not exceeded for post assembly and throughout the thermal operating range of the product. -
Page 25: Optical Assembly Considerations
5.1.1 Optical Assembly Considerations The Intel® RealSense™ ID Solution F450 module will be shipped with an easily removable protective film on the camera and illumination components. This must be removed before assembly as the Intel® RealSense™ ID Solution F450 module will not function with this film installed. -
Page 26: User Feedback
As the enrollment and authentication flows are initiated by the host system, the Intel® RealSense™ ID Solution F450 module can return status codes. It is up to the host system to translate those codes into respective audio or visual feedback which can cause the user to perform certain actions. -
Page 27: Table 5-4: Result Scenario Feedback
System Integration Table 5-4: Result Scenario Feedback SCENARIO AUDIO VISUAL Authentication Success “Welcome” GREEN (Blink) Authentication Failed “Authentication Failed” RED (Blink) Enrollment Success “Enroll Success” GREEN (Blink) Table 5-5: Device Status Scenario Feedback SCENARIO AUDIO VISUAL No Face Detected “Not Detected” YELLOW (BLINK) Face is Too Far Top “Lower Head”... -
Page 28: Regulatory Compliance
Regulatory Compliance Regulatory Compliance System Laser Compliance The Intel ® RealSense™ ID Solution series certification is transferable to the system and no system recertification is required. However, the following statements and labels must be included in the user manual of the end product 6.1.1... -
Page 29: Us Fda Accession Number
Modification or service of the hardware, specifically the infrared projector, may cause the emissions to exceed Class 1. Do not try to update Intel RealSense ID Solution F455 firmware • that is not officially released for Intel RealSense ID Solution F455 SKU and revision. -
Page 30: Fcc Part 15 Declaration Of Conformity
Intel Corporation: Attn: Corp. Quality, 2200Mission College Blvd, Santa Clara, CA 95054-1549, USA This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 31: European Directives
Please handle according to the instruction manual correctly. VCCI-B 6.2.9 South Korea 인증 번호: R-R-CPU-F455C 제조자: Intel Corporation 상품명: Intel ® RealSense™ ID Solution 모델: F455 제조국: 태국... -
Page 32: Customs Union
Regulatory Compliance 6.2.10 Customs Union Наименование продукции: Intel ® RealSense™ ID Solution Модель: F455 Производитель: Intel Corporation Сделано в Таиланде Rev: 001... -
Page 33: Ecology Compliance
Regulatory Compliance Ecology Compliance 6.3.1 China RoHS Declaration China RoHS Declaration 产品中有毒有害物质的名称及含量 Hazardous Substances Table 部件名称 有毒有害物质或元素 Hazardous Substance Component Name 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 Cr (VI) PBDE 解决方案 ○ ○ ○ ○ ○ Solution 印刷电路板组件 ○ ○ ○... -
Page 34: Waste Electrical And Electronic Equipment (Weee)
Regulatory Compliance 6.3.2 Waste Electrical and Electronic Equipment (WEEE) “In the EU, this symbol means that this product must not be disposed of with household waste. It is your responsibility to bring it to a designated collection point for the recycling of waste electrical and electronic equipment. For more information, contact the local waste collection center or your point of purchase of this product.”... -
Page 35: Mechanical Drawings
Mechanical Drawings Mechanical Drawings Figure 7-1. Intel® RealSense™ ID Solution F455 Rev: 001... -
Page 36: Appendix A - Interposer Reference Designs
Appendix A – Interposer Reference Designs Appendix A – Interposer Reference Designs Figure 8-1. USB Interposer Reference Design Rev: 001... -
Page 37: Figure 8-2. Uart Interposer Reference Design
Appendix A – Interposer Reference Designs Figure 8-2. UART Interposer Reference Design Rev: 001... - Page 38 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Intel 82635DSF450 82635DSF455...
