Pet Door; Batteries - SureFlap Microchip Pet Door Connect Manual

Batteries

Always use 4 good quality 1.5V alkaline C cell batteries to ensure the best performance.
The battery indicator light (next to the LCD screen) will flash red when the batteries
are running low.
The Pet Door has 2 battery compartments, one on each side of the product.
1
Remove the battery covers from both
sides of the Pet Door.
3
Whilst holding the first battery in place,
slot the second battery in the space below,
making sure the +/- symbols are at the
correct orientation.
11

Pet Door

2
Insert the first battery into the compartment
with the negative end facing up. Push this
battery upwards into the compartment and
hold it there.
4
Once both batteries are inserted they should
fit snugly into the compartment. Now
replace the battery cover and repeat the
process on the opposite side.
