Toa WTU-M9800 Instruction Manual

WIRELESS TUNER MODULE
Thank you for purchasing TOA's Wireless tuner module.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. SAFETY PRECAUTIONS
• Be sure to read the instructions in this section
carefully before use.
• Make sure to observe the instructions in this manual
as the conventions of safety symbols and messages
regarded as very important precautions are included.
• We also recommend you keep this instruction
manual handy for future reference.
WARNING
hazardous situation which, if mishandled, could result
in death or serious personal injury.
When Installing the Unit
• Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.
Caution to the user
Notice:
The changes or modifications not expressly approved
by the party responsible for compliance could void the
user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
2. GENERAL DESCRIPTION
The TOA WTU-M9800 Wireless Tuner Module is designed for plugged into the 9000 series, 900 series and TOA's
other equipment. It is used in conjunction with UHF wireless equipment for vocal or speech reinforcement
applications. Its built-in circuit minimizes the influence of ambient noise
3. FEATURES
• An optimized PLL-synthesizer drastically minimizes the oscillation frequency drift resulting from the ambient
temperature changes.
• A contact output terminal is provided for control of external equipment.
4. HANDLING PRECAUTION
• Be sure to connect at least two receiving antennas (one each for Antenna A and B).
Indicates a potentially
INSTRUCTION MANUAL
CAUTION
situation which, if mishandled, could result in moderate or
minor personal injury, and/or property damage.
When Installing the Unit
• Do not mount the module in equipment other than
those designated.
• Use only with the voltage specified on the module.
Using a voltage higher than that which is specified
may result in fire or electric shock.
• Be sure to turn off the power of the equipment
before installing the module.
• Avoid touching parts and terminals on the module's
circuit board when inserting or removing the module.
IMPORTANT NOTE
This device contains license-exempt
transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada's
license-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including
interference that may cause undesired operation of
the device.
L'émetteur/récepteur exempt de licence contenu dans
le présent appareil est conforme aux CNR d'Innovation,
Sciences et Développement économique Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions
suivantes :
(1) l'appareil ne doit pas produire de brouillage;
(2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le
fonctionnement.
WTU-M9800
Indicates a potentially hazardous
