Toa SX-200IP Installation Manual

IP MODULE
Thank you for purchasing TOA's IP Module.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe
operation.
• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or
cautions regarding safety.
• After reading, keep this manual handy for future reference.
WARNING
Indicates a potentially hazardous situation which,
if mishandled, could result in death or serious
personal injury.
• Do not expose the unit to rain or an environment
where it may be splashed by water or other liquids,
as doing so may result in fire or electric shock.

2. GENERAL DESCRIPTION

The SX-200IP, designed to be installed in the SX-2100AI Audio input unit of the SX-2000 series, is an Interface
module for connection to the N-8000 series.
By connecting the SX-200IP to a network (LAN or WAN), paging announcements can be made to the SX-2000
system using the N-8000 series' station(s) (N-8600MS and N-8610RM) employing the packet audio technology.
Each function is set by the dedicated setting software on a PC.

3. FEATURES

• Up to 8 SX-200IPs can be used per SX-2000 System.
• Paging announcements can be made to up to 8 SX-2000 systems using the SX-200IPs.

4. SPECIFICATIONS

Network Section
Indicator
Operating Temperature
Operating Humidity
Finish
Dimensions
Weight
Note: The design and specifications are subject to change without notice for improvement.
Network I/F:
Network protocol:
Connector:
Voice sampling frequency: 16 kHz, 8 kHz (controllable on the software)
Quantifying bit number:
Voice encoding method:
Voice packet loss recovery: Silence insertion
Audio delay time:
Operation indicator (RUN)
0 to 40 ºC
90% RH or less (no condensation)
Panel: Pre-coated steel plate, black, 30% gloss
35 (w) x 119.5 (h) x 178.4 (d) mm
150 g
INSTALLATION MANUAL
• Should the following irregularity be found during
use, immediately turn off the power supply to the
SX-2100AI Audio Input Unit where the SX-200IP
is installed and contact your nearest TOA dealer.
Make no further attempt to operate the unit in this
condition as this may cause fire or electric shock.
· If you detect smoke or a strange smell coming
from the unit
· If water or metallic object gets on the circuit board
· If the unit falls or breaks
· If it is malfunctioning (no tone sounds.)
10BASE-T/100BASE-TX (Automatic-Negotiation)
TCP/IP, UDP, HTTP, RTP, ARP, ICMP, IGMP
RJ45 connector for LAN
48 kHz sample rate is used for SX-2000 system only.
16 bits
Sub-band ADPCM, Cryptosystem
80 ms, 320 ms (controllable on the software)
SX-200IP
