National Instruments Phase Matrix PXI-1440 Quick Start Manual

National Instruments Phase Matrix PXI-1440 Quick Start Manual

Microwave if downconverter module
Hide thumbs

Advertisement

Quick Links

Download this manual
PXI MICROWAVE
IF DOWNCONVERTER MODULE
Phase Matrix, Inc.  4600 Patrick Henry Drive, Santa Clara CA 95054  Tel: 1-408-610-6810  www.phasematrix.com
Quick Start Guide
Quick Start Guide
PXI-1440 CCN 13001
Manual Assy Part Number 5585114-01
Manual Text Part Number 5580114-01 Rev
Model PXI-1440

Advertisement

loading
Need help?

Need help?

Do you have a question about the Phase Matrix PXI-1440 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for National Instruments Phase Matrix PXI-1440

Summary of Contents for National Instruments Phase Matrix PXI-1440

  • Page 1 PXI MICROWAVE Model PXI-1440 IF DOWNCONVERTER MODULE Quick Start Guide Quick Start Guide PXI-1440 CCN 13001 Manual Assy Part Number 5585114-01 Manual Text Part Number 5580114-01 Rev Phase Matrix, Inc.  4600 Patrick Henry Drive, Santa Clara CA 95054  Tel: 1-408-610-6810  www.phasematrix.com...
  • Page 2 Do not proceed beyond a ments are traceable to the United States National Instruments®, NI®, WARNING notice until the indi- National Institute of Standards and Tech- ni.com®, LabVIEW®, nology.

  • Page 3: Table Of Contents

    Quick Start Guide Introducing the PXI-1440 IF Downconverter Module Congratulations on purchasing a Phase Matrix PXI-1440 IF Downconverter Module! To get the most out of your purchase, it is recommended that this be read carefully and completely. Quick Start Guide In this document...

  • Page 4: Step 1. Confirm Module Operating Requirements

    LabVIEW does not support Windows NT/Me/98/95, any of the Windows Server NOT E editions, or Windows XP x64. LabVIEW does support Windows 7 (64-bit version). LabVIEW or the LabVIEW Run-Time Engine does support Windows 2000 with Service Pack 3 or later. Phase Matrix PXI-1440 IF Downconverter Module...

  • Page 5: Step 2. Perform Hardware Installation/Configuration

    • Remove each module from its package and inspect it for loose components or any signs of damage. Notify Phase Matrix if any module appears damaged in any way. • Do not install damaged modules into a system. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 6 • Keep the module free of dust by cleaning only with compressed air. • Do not clean the module with any solvents or liquids. • To prevent damage to the module caused by ESD or contamination, handle the module using the edges or the metal bracket. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 7 Phase Matrix recommends installing slot blockers in adjacent vacant PXI slots to NOT E maximize cooling air flow to the PXI modules. A PXI Chassis Slot Blocker Kit (National Instruments part number 778678-01) is available for purchase at www.ni.com. Plug-in and power-on the PXI chassis.
  • Page 8 To avoid ESD, do not touch the exposed connector pins or any exposed circuitry on the device. When not in use, PXI modules should be stored in the original antistatic envelope to avoid damage. Phase Matrix PXI-1440 IF Downconverter Module...

  • Page 9: Step 3. Perform Software Installation/Configuration

    PXI remote controller. in the laptop and a PXI/PXI Express module in slot 1 of the PXI system, Reboot the PXI remote controller. connected by a copper cable. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 10 CAUTION Before installing the PXI-1440 IF Downconverter Module, the PXI chassis must be powered off and unplugged to prevent damage to PXI modules. Install PXI modules into the PXI chassis and turn on power. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 11 Figure Figure 2 Example Welcome Window Select Next to continue. Windows will display the End User License Agreement (EULA) as shown in Figure Figure 3 Example of Software License Agreement Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 12 Figure 4 Example of Windows Security Window Select Install to continue. Windows should display a message indicating that the installation was successful. Figure 5 Example of Completing the Installer Select Finish to complete the device driver installation. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 13 The actual screen that appears will have the label of the module Soft Front Panel being installed, so instead of “PXI-14XX,” the label is displayed as either “PXI-1410,” “PXI-1420,” “PXI-1430B,” “PXI-1440,” “PXI-1440B,” or “PXI-1450B.” Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 14 Enter the destination directory for the PXI-1440’s Soft Front Panel executables or browse to a destination directory by selecting the Browse button. Once the file path has been entered, select Next to continue to the Software License Agreement. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 15 If you do not agree, you will not be able to install the software. Figure 9 Example Summary of Files Being Installed Review the list of files to be installed and select Next to begin the installation. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 16 Quick Start Guide Figure 10 Example of Completing Soft Front Panel Installation Wizard Select Finish to complete the Soft Front Panel installation. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 17 Select the Hardware tab and select Device Manger. Select the View pull-down menu. Select Devices by connection and the device should appear under "NI-VISA PXI Devices" with the label as "PM14XX." * PM14XX will actually display as PXI-1440 IF Downconverter Module. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 18 Select Uninstall and a popup window is displayed with a conformation to continue with the uninstall process. Figure 12 Example of Confirming Device Driver Removal Select OK to confirm the prompt and uninstall the device driver. Phase Matrix PXI-1440 IF Downconverter Module...

  • Page 19: Step 4. Review Hardware And Software Front Panels

    Quick Start Guide Step 4. Review Hardware and Software Front Panels Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 20 MW Downconverter Module and PXI-1430 RF Downconverter Module. The maximum power input to any of the input connectors (IF A IN, IF B IN, or REF A IN 100 MHz) must not exceed +10 dBm! Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 21 • (bypass mode) directly to the IF OUT connector, in a range of 100 kHz to 425 MHz which bypasses the filtering/mixing/amplification circuitry. • (filtered/mixed/amplified) through filtering/mixing/amplification circuitry to produce a 250 MHz IF output signal. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 22 8 MHz or 30 kHz. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 23 • When IF A IN is selected, the IF input signal that is applied to the IF A IN connector is used. • When IF B IN is selected, the IF input signal that is applied to the IF B IN connector is used. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 24 IF AUX OUT. • When 30 kHz is selected, the IF AUX bandwidth is set to 30 kHz. • When 8 MHz is selected, the IF AUX bandwidth is set to 8 MHz. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 25 PXI module while BUSY is active.  This number indicates the internal real-time ambient temperature of the module in degrees Celsius. Status Indicator The Status Indicator displays messages related to system configuration. Messages may be errors or warnings. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 26 Although data values can be viewed from this tab, the Soft Front Panel cannot be used to modify or overwrite the data values. These stored data values are normally utilized by the driver in real-time correction applications. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 27 (EEPROM). This EEPROM controls the PXI related configuration such as the manufacture ID, etc. Last Cal Date displays the date that the last calibration was run and that the calibration file was created. FPGA Date Displays the applicable FPGA version date. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 28 (flatten) the signal path. Table 4 IF B IN to IF OUT Loss -1.1 -1.05 -1.02 -1.04 Use the Horizontal Slider Bar to view correction values to the left and right of the values currently being displayed. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 29 30 kHz filter response. Table 6 30 kHz Filter Response 21.398 21.399 21.800 22.04 0.45 0.58 0.73 Use the Horizontal Slider Bar to view correction values to the left and right of the values currently being displayed. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 30 Quick Start Guide This Page Left Intentionally Blank Phase Matrix PXI-1440 IF Downconverter Module...

  • Page 31: Step 5. Confirm Basic Module Operation

    Table 7 Equipment Requirements to Confirm Basic Module Operation Qty Equipment Description Agilent 83650A Signal Generator, 26.5 GHz Agilent 8566B Spectrum Analyzer NI PXIe-1065 PXI chassis NI PXI-8106 PXI Embedded Controller with Windows 7/XP Display Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 32 100 MHz reference. PXI-1440 IF Downconverter Module Set IF Gain Control to provide 38 dB of gain. (Refer to the “IF OUT, IF AUX OUT, IF Center Frequency, and Power Check" on page 33 Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 33 Set the Signal Generator frequency to 249.4 MHz and the output power to -2 dBm. Confirm that the output frequency on the Spectrum Analyzer is 21.4 MHz and the power level is -2 dBm +/- 2 dB. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 34 Repeat this process for IF B IN. Change the connection in step 1 and using the Soft Front Panel of the PXI-1440 IF Downconverter Module, set the Select Input Path to IF B IN. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 35 Check that the STATUS LED is Green. (Refer to page 21.) Check that the ACCESS LED switches each time that a path is selected. (Refer to page 21.) Contact Phase Matrix Customer Support for additional help. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 36 • The name and telephone number of someone familiar with the problem who can be contacted by Phase Matrix if any further information is required. • The shipping address to which the PXI module is to be returned. Include any special shipping instructions. Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 37 Mark the carton to indicate that it contains a fragile electronic instrument. Ship the PXI module to Phase Matrix at the following address: Phase Matrix, Inc. 4600 Patrick Henry Dr. Santa Clara CA 95054 Tel: 1-408-610-6810 www.phasematrix.com Phase Matrix PXI-1440 IF Downconverter Module...
  • Page 38 DECLARATION OF CONFORMITY Manufacturer’s Name: Phase Matrix, Inc. Manufacturer’s Address: 4600 Patrick Henry Drive Santa Clara CA 95054 Product Name: Preselector, MW Downconverter, RF Downconverter, IF Downconverter, Local Oscillator, LO Distributor Model Number: PXI-1410, PXI-1420, PXI-1430, PXI-1440, PXI-1450, PXI-1455 Statement: Phase Matrix, Inc.
