- Page 1 PXIe-4466/4467/4468 Getting Started Guide 2023-03-28...
- Page 2 PXIe-4466/4467/4468 Getting Started Guide Contents Getting Started Guide............3...
-
Page 3: Unpacking The Kit
This document explains how to install, configure, and set up the PXIe-446x Sound and Vibration Module. Note In this document, the PXIe-4466, PXIe-4467, and PXIe-4468 are referred to inclusively as the PXIe-446x. Driver support for the modules was first available in the following NI-DAQmx versions: PXIe-4466—NI-DAQmx 20.7... -
Page 4: Verify The Kit Contents
PXIe-4466/4467/4468 Getting Started Guide Note Do not install a module if it appears damaged in any way. 3. Unpack any other items and documentation from the kit. Store the module in the antistatic package when the module is not in use. -
Page 5: Installing The Software
PXIe-4466/4467/4468 Getting Started Guide Note This model is intended for use in indoor applications only. Installing the Software You must be an Administrator to install NI software on your computer. 1. Install an ADE, such as LabVIEW or LabWindows™/CVI™. 2. Download the NI-DAQmx driver software installer from ni.com/downloads. - Page 6 PXIe-4466/4467/4468 Getting Started Guide Installing the PXIe-446x Notice To prevent damage to the PXIe-446x caused by ESD or contamination, handle the module using the edges or the metal bracket. Note To maintain forced air cooling in the PXIe system, refer to the Maintain Forced-Air Cooling document.
- Page 7 PXIe-4466/4467/4468 Getting Started Guide PXIe-446x modules can be placed in PXI peripheral slots or PXI Express Hybrid peripheral slots. 6. Touch any metal part of the chassis to discharge static electricity. 7. Ensure that the ejector handle is in the downward (unlatched) position.
- Page 8 PXIe-4466/4467/4468 Getting Started Guide Note For more information about installing slot blockers and filler panels, go to ni.com/r/pxiblocker. 12. Power on the chassis. Configuring the PXIe-446x in MAX Use Measurement & Automation Explorer (MAX) to configure your NI hardware. MAX informs other programs about which NI hardware products are in the system and how they are configured.
- Page 9 PXIe-4466/4467/4468 Getting Started Guide Note Refer to the module specifications for information about the operating input and output ranges and overvoltage protection. Figure 3. PXIe-4466/4467 Front Panel PXIe-4467 PXIe-4466 DSA Analog I/O DSA Analog I/O ACTIVE ACTIVE PFI 0 PFI 0...
- Page 10 PXIe-4466/4467/4468 Getting Started Guide Figure 4. PXIe-4468 Front Panel PXIe-4468 PXIe-4468 DSA Analog I/O DSA Analog I/O ACTIVE ACTIVE PFI 0 PFI 0 AI 0 AI 0 AI 1 AI 1 AO 0 AO 0 AO 1 AO 1 1. PFI 2.
- Page 11 PXIe-4466/4467/4468 Getting Started Guide Signal Name Signal Description Positive analog output signal Negative analog output signal Chassis ground Table 2. LEDs Description Access—Indicates the basic hardware status of the analog output module. OFF—The module is not yet functional, or has detected a problem with a PXI power rail.
- Page 12 PXIe-4466/4467/4468 Getting Started Guide Description <AI 0..1> AMBER/GREEN (alternating)—The reference clock source is changing to onboard or PXIeClk100. AMBER (solid)—The channel is waiting for a trigger to start acquiring. GREEN (solid)—The channel is actively acquiring a signal. RED (solid)—An error has been detected on the channel or board.
- Page 13 PXIe-4466/4467/4468 Getting Started Guide Description RED (solid)—An error has been detected on the channel or board. Possible errors include the following: The board is overheated ■ The power supply is not at the proper ■ voltage A clocking error occurred (PLL fell out ■...
- Page 14 PXIe-4466/4467/4468 Getting Started Guide Figure 6. PXIe-446x Input Connection in Pseudodifferential Mode 210 pF Ω – – Ω The following figure shows the PXIe-446x analog input circuitry block diagram. Depending on the connector type, connect the signals as shown in the inset.
- Page 15 PXIe-4466/4467/4468 Getting Started Guide Figure 8. PXIe-446x Analog Output Block Diagram 40/600 Ω Termination Output Enable Selection Relay Differential Relay Low-Pass Amplifier 19.0 Ω 1.0 Ω Filter Attenuator +AOn 280 Ω Differential 19.0 Ω 1.0 Ω –AOn 280 Ω Gain = 0 dB Gain = –10 dB...
-
Page 16: Troubleshooting
PXIe-4466/4467/4468 Getting Started Guide Figure 9. PXIe-446x Recommended Output Connection PXIe-4466 Front Panel Ground-Referenced Ground-Referenced Floating Load Balanced Load Unbalanced Load Mini-XLR +AOn –AOn Grounded Shielding Enclosure Figure 10. PXIe-446x BNC Recommended Output Connection PXIe-4466 Front Panel Ground-Referenced Ground-Referenced Floating Load... - Page 17 PXIe-4466/4467/4468 Getting Started Guide Note If you are using a PC with a device for PXI remote control system, under System Devices, also confirm that no error conditions appear for the PCI-to-PCI Bridge. 2. If error conditions appear, reinstall the NI-DAQmx driver.
- Page 18 PXIe-4466/4467/4468 Getting Started Guide What Should I Do if the PXIe-446x Fails the Self-Test? 1. Restart the system. 2. Launch MAX, and perform the self-test again. 3. Power off the chassis. 4. Reinstall the failed module in a different slot.
