Specifications

8.1 Imaging and Optical Specifications

IR resolution
Digital image enhancement
Thermal Sensitivity /NETD
Field of View (FOV)
Minimum focus distance
Distance-to-Spot ratio
Dual range operation
Focus
Image frequency

8.2 Detector Specifications

Focal plane array /Spectral response range
Detector pitch

8.3 Image Presentation Specifications

Display resolution
Screen size
Viewing angle
Color depth
Aspect ratio
Display type
Image adjustment
Image modes
#NAS100031; r. AD/63425/63425; en-US
80 x 60 pixels
Included
< 70 mK
51° x 66 (H x W)°
0.89 ft. (0.3 m)
30:1
Range 1: < 752℉ (400℃)
Range 2: > 752℉ (400℃)
For Range 2, the high temperature lever
must be engaged
Fixed
8.7 Hz
Uncooled microbolometer /7.5 ~ 14 μm
12 μm
320 x 240 pixels
2.4 in. (portrait)
80°
24 bit
4:3
TFT technology
Automatic
Thermal MSX® (Multi-Spectral Dynamic
Imaging) and Visible Spectrum modes.
