10. Do not adjust the tank pressure switch without reference to Axminster Power Tool Service
Department.
11. Do not remove parts from the compressor whilst it is running.
12. Do not operate the compressor with protective covers removed or damaged.
13. When spray painting always work in a well-ventilated area and never close to open flames.
14. Never direct a jet of compressed air towards people or animals. Keep children and animals away
from the compressor.
15. Do not use on an inclined surface.
16. Only use in ambient temperatures between –10˚C and +40˚C.
17. Only operate on 230 volt supply and with maximum fuse rating of 13 amps.
Axminster Part No:
Power:
Supply Requirements:
Speed:
Free Air Delivery:
Max Pressure:
Receiver Volume:
Oil Capacity:
Overall L x W x H:
Weight:
Axminster Part No:
Power:
Supply Requirements:
Speed:
Free Air Delivery:
Max Pressure:
Receiver Volume:
Oil Capacity:
Overall L x W x H:
Weight:

Safety Precautions...

Specification
AWBDC20 (210647)
230v 50Hz, 1.5 kW
50 litres (11 gallons)
980 x 460 x 740mm
AWBDC30 (210648)
230v 50Hz, 2.2 kW
100 litres (22 gallons)
1050 x 500 x 850mm
W
A X M I N S T E R
W H I T E
13 Amps
2800rpm
10.5cfm
8 bar (120 psi)
500ml
53kg
13 Amps
2800rpm
13.5cfm
8 bar (120 psi)
500ml
65kg
