- Page 1 AC21C Code 104295 AC44C Code 104296 Original Instructions AC21C (FA-2024) AC44C (FA-3050V) Air Compressors Code 104295 AC21C Code104296 AC44C AT&M: 12/06/2018 BOOK REF : 104534...
-
Page 2: Eu Declaration Of Conformity
Exploded Diagram/Parts List AC44C 20-21 Notes 22-23 EU Declaration of Conformity Cert No: FA-2024, FA-3050V EU Declaration of Conformity Axminster Tools & Machinery Ltd, This machine complies with the following directives: Weycroft Avenue, Axminster, Devon, EX13 5PH, UK axminster.co.uk 2006/42/EC EN 1012-1: 2010... -
Page 3: What's Included
What’s Included Model Number AC21C (FA-2024) Model Number AC44C (FA-3050V) Quantity Item Part Quantity Item Part 1 No Air Compressor 1 No Air Compressor 1 No Compressor Oil Bottle 1 No Compressor Oil Bottle 2 No Wheels 2 No Wheels 1 No Rubber Foot 2 No... -
Page 4: Safety Precautions
WARNING!! KEEP TOOLS AND EQUIPMENT OUT 10. Do not adjust the tank pressure relief valve without OF THE REACH OF YOUNG CHILDREN reference to Axminster Tools & Machinery Service Department. 11. Do not remove parts from the compressor whilst it is Air Powered Tools running. - Page 5 Assembly Fitting the Rear Wheels Continues Over...
- Page 6 Assembly Fitting the Rubber Feet Fitting the Air Filters Remove transport plug...
- Page 7 Assembly Fitting the Oil Dipstick Plug Remove transport plug Oil level Remove transport plug...
-
Page 8: Illustration & Parts Description
Illustration & Parts Description Regulator adjusting knob (A) Regulator preset lock (B) Pressure relief valve ON/OFF control switch (A), Regulator control knob (B), 1/4" BSP male coupling (C), Tank pressure gauge (D), and Outlet pressure gauge (E) Oil level indicator (A), Crankcase (B), Crankcase oil filler plug (C) Oil Level indicator (A) Oil drain plug (AC21C ONLY) (B) - Page 9 Illustration & Parts Description AC21C Motor cover Pump air vent ON/OFF Switch Pressure regulator Oil filler plug Handle Pressure gauges Tank Water drain valve Rubber foot Pressure switch unit Motor air vent Air inlet filter Handle Crankcase 1/4" BSP Male coupling Pressure relief valve Wheel...
- Page 10 Illustration & Parts Description Control Assembly (A), Pressure release valve (B) Compressor ON (I) Regulator adjusting knob (C) Compressor OFF (O) (+) to increase pressure and (-) to decrease it REST AC44C ONLY Water drain valve, to drain ‘REST’ button, press this button if compressor is not functioning properly water from the tank...
- Page 11 Illustration & Parts Description Motor AC44C Pump air vent ON/OFF Switch Pressure regulator Handle Pressure gauges Tank Water drain valve Rubber foot Pressure switch unit Motor REST control Motor air vent Handle Air inlet filter 1/4" BSP Male coupling Pressure relief valve Crankcase Wheel...
- Page 12 Operating Instructions NOTE: It is advisable to fully drain the air from the tank if Turning on the Compressor the compressor is left unused for a period, this will prevent the build-up of water in the tank. Connect the compressor to the mains supply and switch on by pulling the on/off knob upwards.
- Page 13 Operating Instructions Output Air Pressure Regulator The outlet air pressure can be regulated by rotating the regulator knob clockwise to increase the pressure and anti-clockwise to reduce it. Do not leave the regulator set at maximum setting unnecessarily; reduce the setting by about two turns after finishing and then re-set to the required pressure when starting work again.
-
Page 14: Maintenance
Maintenance Daily: Drain water from tank, see fig 1. Fig 1 Monthly: Remove the air inlet filter outer casing and clean the filter element, see fig 6-7-8-9. • Wash in soapy water and leave to dry. Weekly: Do not use the compressor without the air filter fitted. Check oil level and top-up if necessary, see fig 2-3-4-5. - Page 15 Maintenance Six Monthly: Check the condition of the oil for the following. If you notice the oil is black insead of a golden colour, a build up of foam inside the crankcase or water bubbles showing inside the sight glass level indicator, it’s time to change the oil.
-
Page 16: Troubleshooting
The compressor stops and will not start again. Motor winding burnt out. Contact our techical team at Axminster Tools & Machinery for assistance. Compressor head gasket blown Contact our technical team at or valve broken. Axminster Tools & Machinery for assistance. -
Page 17: Wiring Diagram
Wiring Diagram... - Page 18 Exploded Diagram/Parts List AC21C...
- Page 19 Exploded Diagram/Parts List AC21C FA-2024 Air Compressor M8x1.25x30 SHCS Crankcase Description Capacitor Socket Head Cap Screw Over-load 6 Lock Washer Electric Motor Exhaust Elbow Electric Motor Back Cover Cylinder Head Washer Air Filter Screw Motor PV Cover Motor Fan SHCS Snap Ring Gasket,Cylinder Head Coupler...
- Page 20 Exploded Diagram/Parts List AC44C...
- Page 21 Exploded Diagram/Parts List AC44C FA-3050V Air Compressor Over-load cover Description Cable Clamp Screw Motor stator Shield Bolt The motor rotor Exhaust Elbow Bearing Exhaust Elbow The wave washer Exhaust Pipe Electric Motor Back Cover Cylinder Head 5 Flat Washer Air Filter Six Angle Nut Gasket,Cylinder Head Centrifugal switch...
- Page 22 Notes...
- Page 23 Notes...
- Page 24 Craft, Trade, Engineer, Air Tools & CNC Technology Series machines It’s probably the most comprehensive FREE guarantee ever- buy with confidence from Axminster! So sure are we of the quality, we cover all parts and labour free of charge for three years! For more information visit axminster.co.uk/3years...
