INSTALLATION MANUAL
11405 110W
11404 55W
AstralPool
UV Disinfection System
WARNING
FOR YOUR SAFETY - This product must be installed and serviced by a licensed electrician in accordance
with the latest, enforced version of AS/NZS 3000 and any other applicable local installation codes.
Before installing this product, read and follow all warning notices and instructions that accompany this
product. Failure to follow warning notices and instructions may result in property damage, personal
injury, or death. Improper installation and/or operation will void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which can cause serious
injury, property damage, or death.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Astralpool 11405
Summary of Contents for Astralpool 11405
- Page 1 INSTALLATION MANUAL 11405 110W 11404 55W AstralPool UV Disinfection System WARNING FOR YOUR SAFETY - This product must be installed and serviced by a licensed electrician in accordance with the latest, enforced version of AS/NZS 3000 and any other applicable local installation codes.
- Page 2 AstralPool UV Disinfection System Installation Manual EQUIPMENT INFORMATION RECORD DATE OF INSTALLATION INSTALLER INFORMATION INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER) PUMP MODEL HORSEPOWER FILTER MODEL CONTROL PANEL MODEL SERIAL NUMBER...
-
Page 3: Table Of Contents
Replace / Clean Quartz Supply ..........9 Section 4. Components ..........6 Section 8. Troubleshooting ........10 11404 - 55 Watt Components ..........6 Section 9. Frequently Asked Questions ....10 11405 - 110 Watt Components ..........6 Section 5. Flow Rates ..........7 Section 10. Warranty ..........11... -
Page 4: Important Safety Instructions
AstralPool UV Disinfection System AstralPool UV Disinfection System Installation Manual Installation Manual Section 1. Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. -
Page 5: Product Information
On the 11404 the stainless steel mounting brackets are pre-fitted. The 11405 mounting brackets can be found in the cardboard end fitments. Please remove these to fit the Section 3. Introduction 11405. -
Page 6: Components
11404 - 55 Watt NOTE: For optimum performance, the electronic ballast has been configured for UV bulbs supplied by AstralPool. When sourcing replacement UV Bulbs or quartz sleeves always buy components supplied by AstralPool from your nearest AstralPool stockist. 11405 - 110 Watt Components... -
Page 7: Flow Rates
AstralPool UV Disinfection System Installation Manual Section 5. Flow Rates Maximum System Volume Model Total No. of 55W Lamps Max Flow Rate (Litres) 11404 20,000 55,000 55 Watt 11405 25,000 75,000 11 Watt Table 4. Figure 3. Installation Position Section 6. Installation... -
Page 8: Testing The Quartz, O-Rings And Locking Nuts
AstralPool UV Disinfection System Installation Manual Testing the Quartz, O-Rings and Locking Install the UV Bulb Nuts Now that the unit is in position and connected to pipework, the quartz sleeve and O-ring at each end can be leak tested to ensure that they have been fitted properly. -
Page 9: Connect To The Electricity Suppy
Please note that the items list 1-5 are service items and therefore not subject to a claim under warranty. Refer to the installation of the UV Bulb steps in 6.2. The service items listed are available from your AstralPool stockist. IMPORTANT: After checking all the fittings are correctly tightened you can switch your unit back on. -
Page 10: Troubleshooting
• Make sure the end caps are dry. • 11405 Bulbs are electrically linked as a pair. If one bulb fails, both bulbs will not illuminate. Substituting either bulb will identify which bulb has failed. • Do not mix up the bulb connectors as this will result in the bulb not illuminating. -
Page 11: Section 10. Warranty
Detail are included with this product or for full terms and conditions, please visit www.astralpool.com.au All warranty issues should be resolved with your AstralPool dealer or place of purchase. Claims must include the UV Disinfection System serial number and model (this information can be found on the rating plate), installa- tion date, and name of the installer. - Page 12 Fluidra Australia Pty Ltd 219 Woodpark Rd Smithfield, NSW 2164, Australia 1300 763 021 For contact details visit: www.astralpool.com.au ©2019 Fluidra S.A. All rights reserved. This document is subject to change without notice.
