Car Solutions Q-ROIX Manual

Hide thumbs Also See for Q-ROIX:

Advertisement

Table of Contents

1. Features
• Android 8.1 (OREO)
•Powerful RAM and Internal Storage spec
(RAM 4GB LPDDR3 & 32GB
eMMC)
• Powerful CPU (ARM Cortex-A72 + Cortex-A53@2.0GHz
(HEXA
CORE)
ARM Mali-T860
(QUAD
CORE) )
• Able to install and update various application via Android Play-Store
• Provides High quality video display (720P, simultaneous Video Output of LVDS
and HDMI)
•Multiple ways to store data and communication ports (3 * USB, 1*Micro SD slot)
•Support AUX OUT by Bluetooth and FMTX
•Accessible to Internet & Data with using WiFi and 4G Data by Dongle
(Dongle Option)
•Program & FW update by USB Thumb memory stick

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q-ROIX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Car Solutions Q-ROIX

Summary of Contents for Car Solutions Q-ROIX

  • Page 1 1. Features • Android 8.1 (OREO) •Powerful RAM and Internal Storage spec (RAM 4GB LPDDR3 & 32GB eMMC) • Powerful CPU (ARM Cortex-A72 + Cortex-A53@2.0GHz (HEXA CORE) ARM Mali-T860 (QUAD CORE) ) • Able to install and update various application via Android Play-Store •...

  • Page 2: Specification

    2. Specification CATEGORY DEV SPEC ARM Cortex-A72 + Cortex-A53@2.0GHz (HEXA CORE) ARM Mali-T860 (QUAD CORE) - for GPU 4GB LPDDR3 INTERNAL S 32 GB eMMC Memory TORAGE EXTERNAL microSD slot (MAX 128GB) STORAGE WI-FI 802.11 a/b/g/n/ac (2.4 GHz / 5 GHz) Internally on board with Antenna BLUETOOTH 4.0 (Internally on board with Antenna) Network...
  • Page 3 3. Components POWER * 1ea MULTI * 1ea (HPOWER0245) (HAERTC0321) Mainboard * 1ea GPS * 1ea HDMI Cable * 1ea (HAGPS0013) (HARETC0067) USB extension MIC * 1ea Resistive touch * 1ea SPKEAR * 1ea cable * 1ea (MICPHOC0003) (HTOUCH0022) (SPEAKER007) (HARETC0078) Capacitive Touch * 1ea Touch Board * 1ea...

  • Page 4: Product Exterior

    4. Product Exterior Dipswitch settings Power cable Multi cable Capacitive Resistive touch Cable touch Cable Option GPS cable Micro SD card (option)

  • Page 5: Dip Switch

    5. Dip switch *Touch Type Selection UART & Cap Touch Use Resistive Touch Use *Cap Touch Selection Benz 8inch and 8.4inch Cap touch panel (XWC2800) Benz 12.1inch Cap touch panel Universal 7inch Cap touch panel (XWC2821) Audi A3, Q2 7inch Cap touch panel (XWC2410)
  • Page 6 5. Dip switch *Cap Touch Selection Universal 6.5inch Cap Touch panel (XWC1873) Lexus NX 7inch Cap touch panel (XWC3941) Audi A4, A5, Q7 8inch Cap touch panel (XWC3536) Audi A4, A5, Q7, Q2, A3 7inch Cap touch panel (XWC3534- Q2 & A3, XWC3535) Benz 7inch Cap Touch Panel (XWC2433) Benz A, B Class 7inch Cap Touch Panel...

  • Page 7: Installation Diagram

    6. Installation diagram USB extension cable LVDS IN Interface 12V GND ACC GPS connection...
  • Page 8 7.1 Capacitive touch installation *Capacitive touch cable is included in QDIS Cap touch Panel set. (option) Capacitive touch cable Capacitive touch Panel C-Touch B/D FPC connection Dip Switch No.4 should be Up.
  • Page 9 7.2 Resistive touch installation Interface Dip Switch No.4 should be Down.
  • Page 10 7.3 Uart touch installation *When HDMI OUT uses, Uart Touch wire should be connected to Video interface. *When LVDS OUT uses, no need to connect Uart touch wire. Interface UART Cable GND (Black) TX (White) RX (Red)
