Index 1. General spec 2. System Diagram 3. Components 4. Setting up Dip S/W 5. Setting up FACTORY MENU 6. Cautions before Installation 7. Installation Diagram 8. Installation 9. Quality Warranty...
Page 3
Warning / Precautions! Do not modify, dismantle or unintended operation this system outside Q-roi After Sales. Damage occurred by unintended operation Warning may cause Q-roi After Sales service void. Always wear seatbelt. When the vehicle is suddenly stop can cause injury. Warning ...
1. General Spec Android 4.2.2 (Jelly Bean) Telechips TCC8930 (1GHz Cortex A9 DualCore) Display OEM LCD Internal Memory DDR3 1GB RAM + 8GB eMMC External Memory SDHC Slot Support (up to 64GB) A/V Input x 3, Rear Cam Input x 1, CAN(Controller Area Network) x 2, Function Mic x 1,...
4. Setting up Dip Switch (Main board) ※ ON : DOWN / OFF : UP : A6, A7, A8 High Resolution Monitor (8inch) : A6, A7, A8 Low Resolution Monitor (5.8inch) : A6, A7, A8 2015year (Use AUDI15 sub-board) ※ Please make sure to disconnect the power cable of the interface and reconnect the power cable again to apply the dip switch setting whenever changing DIP switch.
Page 8
5. Setting Factory Menu ※ APPS→FACTORY SETTING ① Put Password and change program upgrade and set-up of external device. (Only Installers are authorized) ※ Please contact the manufacturer to get Password.
5. Setting up Factory Menu ⑤ ④ ① ② ③ ① CAR MODEL : No use ② DVD TYPE : Only for DVD connected to A/V (Connect IR-AV1 to DVD to use DVD as touch Screen) ③ CMMB SELECT : Select DTV model ( Only Chinese) ④...
6. Cautions before Installation Ignition key should be taken off before starting installation, interface power connection must be the last step in installation. Power cable should be separated when connecting interface. Should be no any electronic devices or magnetic pole around ...
7. Installation Diagram ※1. Remove Original LCD cable from Radio system and Connect it to Sub-Board “To monitor". 2. Connect Provided LCD cable to Behind of Radio system <Behind of Monitor> <Behind of Radio System> Speaker Provided Touch In cable Original LCD cable Provided LCD cable SAFE...
Page 12
8. Installation 8.1 Connection of CAN Wire * Connect CAN1-H(Yellow + White) of Provided Power cable to CAN-High(Brown + Orange) of Car. * Connect CAN1-L(Yellow) of Provided Power cable to CAN-Low(Green + Orange) of Car ※ You will be able to find the bunch of cable behind Radio System...
Page 13
8. Installation 8.2 Connection of LCD cable after dismantling a monitor Behind Monitor Remove Behind Command ② Remove OEM LCD cable ① Please refer to the photo from the Radio System and (After dismantling a monitor Connect to ‘To monitor’ of and command).
9. Quality Warranty This product has been tested and have passed under our strict quality control. If the failure occurred due to the carelessness of workmanship within one year after the purchase, we are responsible to repair free of charge. Please bring this warranty to dealer whom you purchased this product from at the repair time.
