INSTALLATION
Installation
Appliance usage range
This appliance is intended to be used in household
and similar applications such as:
•
staff kitchen areas in shops, offi ces and other
working environments;
•
farm houses and by clients in hotels, motels
and other residential type environments;
•
bed and breakfast type environments;
•
catering and similar non-retail applications
Climate class
The appliance is designed to operate at the limited
range of ambient temperature, depending on
climate zones. Do not use the appliance at the
temperature out of the limit. Climate class of your
appliance is indicated on the label with technical
description inside the fridge compartment.
Class
Symbol
Extended
SN
Temperate
Temperate
N
Subtropical
ST
Tropical
T
Installation
1.
Select a good location. Place your fridge-freez-
er where it is easy to use.
2.
Avoid placing the unit near heat sources, direct
sunlight or moisture.
3.
To ensure proper air circulation around the
fridge-freezer, please maintain suffi cient space
on both the sides as well as top and maintain
at least 2 inches (5cm) from the rear wall.
4.
To avoid vibration, the unit must be leveled. If
required, adjust the leveling screws to compen-
sate for the uneven fl oor.
The front should be slightly higher than the
rear to aid in door closing. Leveling screws can
be turned easily by tipping the cabinet slightly.
Turn the leveling screws counterclockwise (
to raise the unit, clockwise (
5.
Clean your fridge-freezer thoroughly and wipe
off all dust accumulated during shipping.
6.
7.
Starting
When your fridge-freezer is installed, allow it 2-3
hours to stabilize at normal operating temperature
prior to fi lling it with fresh or frozen foods. If power
plug is disconnected, allow 5 minutes delay before
restarting. Your fridge-freezer is now ready for use.
Operation
Identifi cation of parts
Refer to Refrigerator drawings at the end of the
manual:
If you fi nd some parts missing from your unit, they may
be parts only used in other models.
Ambient temperature
range °C
+10 ~ +32
8
9
+16 ~ +32
10
+16 ~ +38
11
+16 ~ +43
12
13
14
15
16
17
18
*
19
20
21
22
23
)
24
) to lower it.
25
7
7
INSTALLATION
Install accessories such as ice cube box, etc., in
their proper places. They are packed together
to prevent possible damage during shipment.
Connect the power supply cord (or plug) to the
outlet. Don't double up with other appliances
on the same outlet.
Bottle Rack
Removable Glass Shelf
Folding Glass Shelf
Fresh Converter
Fresh Balancer
Vegetable Drawer (Used to store fruits
and vegetables etc. fresh and crispy)
Fresh Converter
Ice Tray
Freezer Tray
Wire Shelf
Freezer Drawer
The process of freezing occurs
the fastest on the marked shelf
Leveling Screw
Basket Door
Water Tank)
Egg Tray
Diary Corner / Basket Door
Smart DiagnosisTM
LED Lamp
