OWNER'S MANUAL

FRIDGE & FREEZER

Before beginning installation, read these instructions

carefully. This will simplify installation and ensure that the

product is installed correctly and safely. Leave these

instructions near the product after installation for future

reference.

ENGLISH

GB-335WL / GB-335PL / GB-W335MBL / GB-335MBL

MFL71400038

Rev.05_021425

www.lg.com

Need help?

Do you have a question about the GB-W335MBL and is the answer not in the manual?

Questions and answers

Summary of Contents for LG GB-W335MBL

Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH GB-335WL / GB-335PL / GB-W335MBL / GB-335MBL www.lg.com MFL71400038 Rev.05_021425 Copyright © 2020-2025 LG Electronics. All Rights Reserved...
Page 2 Moving the Appliance for Relocation ............13 OPERATION Before Use ......................15 Product Features....................18 Control Panel ....................20 Water Dispenser....................21 Icemaker ......................22 Fridge Drawer....................23 Door Basket ......................24 Shelf ........................24 Freezer Drawer....................24 SMART FUNCTIONS LG ThinQ Application ..................26 Smart Diagnosis ....................27 MAINTENANCE Cleaning ......................29 TROUBLESHOOTING Before Calling for Service................30...
Page 3 SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk.
Page 4 SAFETY INSTRUCTIONS responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. • If the power cord is damaged or the hole of the outlet socket is loose, do not use the power cord and contact an authorized service centre. •...
Page 5 • Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material. • Only qualified service personnel from LG Electronics service centre should disassemble or repair the appliance. • Do not use a hair drier to dry the inside of the appliance or place a candle inside to remove the odours.
Page 6 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
Page 7 • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
Page 8 SAFETY INSTRUCTIONS • Do not put animals, such as pets into the appliance. • Do not place heavy or fragile objects, containers filled with liquid, combustible substances, flammable objects (such as candles, lamps, etc.), or heating devices (such as stoves, heaters, etc.) on the appliance.
Page 9 SAFETY INSTRUCTIONS CAUTION CAUTION • To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Installation • After unpacking, check the appliance for any damage that may have occurred during transit.
Page 10 They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • If ice forms in the freezer compartment, please contact LG Electronics customer service. Do not use sharp-edged objects to remove any frost or ice build-up.
Page 11 INSTALLATION INSTALLATION Before Installation Dimensions and Clearances Too small of a distance from adjacent items may result in the degradation of freezing capability and increased electricity costs. Allow over 50 mm of clearance from each adjacent wall when installing the appliance.
Page 12 • Reversing the doors must be performed by the • The climate class can be found on the rating qualified personnel of LG Electronics. If not, the label. doors will not be covered by the warranty. Ambient Temperature Climate Class Range ºC...
Page 13 INSTALLATION Moving the Appliance for Turn the levelling leg clockwise to raise that Relocation side of the appliance or counterclockwise to lower it. Moving the Appliance Remove all food from inside the appliance. Fix the power plug. • Models with a power plug hook: Pull the power plug out, insert and fix it into the power plug hook at the rear or on top of the appliance.
Page 14 INSTALLATION CAUTION - Do not move the appliance in zigzags. After installing the appliance, connect the power plug into a mains outlet socket and switch it on.
Page 15 Keep a distance of at least 3 cm from the sensor. NOTE • Contact the LG Electronics customer information Storing Foods Effectively centre if the alarm sound continues even after closing all doors. • Food may freeze or spoil if stored at the wrong temperature.
Page 16 OPERATION • Do not store food for a long period of time if it - You should avoid door openings while the spoils easily at a low temperature. power is off. • Do not place unfrozen food in direct contact with - When the power supply gets back to normal, food that is already frozen.
Page 17 OPERATION CAUTION • To remove the drawers, first remove the food from drawers and then pull out the drawers carefully. Not doing so could cause injury or damage to the drawers. NOTE • To get better air circulation, insert all drawers. •...
Page 18 OPERATION Product Features The appearance or components of the appliance may differ from model to model. Interior The appearance or components of the appliance may differ from model to model. *1 This feature is only available on some models. LED Lamp The LED lamps inside the appliance light up when you open the door.
Page 19 OPERATION CAUTION • Do not store short bottles on the bottle rack. The items may fall and cause an injury or appliance damage. Folding Shelf This is adjustable to meet individual storage needs. Bottle Rack Stores containers and tall bottles using the bottle rack. Vegetable Drawer Stores fruits and vegetables to keep fresh for as long as possible.
Page 20 OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Control Panel 1: On the Fridge Door Control Panel 2: Inside the Fridge Fridge Press this button repeatedly to select a desired temperature between 1 ℃...
Page 21 Wi-Fi This button allows the appliance to connect to a home Wi-Fi network. Refer to SMART FUNCTIONS for information on the initial setup of the LG ThinQ application. Lock This locks the buttons on the control panel.
Page 22 OPERATION Filling the Water Tank CAUTION The water tank holds the water which is to be • Keep children away from the dispenser to dispensed. prevent children playing with or damaging the controls. Open the cap on the top of the water tank. •...
Page 23 OPERATION Using the Ice Tray lever , where located in front of compartment, in either direction. This is where ice is manually produced. Fill the ice tray with water up to the marked water line. WARNING • Fill with potable water only. CAUTION For storing vegetables.
Page 24 OPERATION Shelf Removing/Refitting the Fridge Drawer Using Folding Shelf Remove the contents of the drawer. Hold the This feature is only available on some models. handle of the drawer and pull it out completely Store taller items, such as a gallon container or until it stops.
Page 25 OPERATION Lift the drawer up and remove it by pulling it out. Refit the drawer in the reverse order of the removal process.
Page 26 • The application is subject to change for on a smartphone. appliance improvement purposes without notice to users. Run the LG ThinQ application and sign in with • Functions may vary by model. your existing account or create an LG account to sign in.
Page 27 This equipment shall be installed and used at a minimum distance of 20 cm from the human body. • LG ThinQ is not responsible for any network connection problems or any faults, malfunctions, or errors caused by network connection.
Page 28 Control Panel 2: Inside the Fridge LG ThinQ application. • Launch the LG ThinQ application and select the Open the fridge door. Smart Diagnosis feature in the menu. Follow the instructions provided in the LG ThinQ application.
Page 29 MAINTENANCE MAINTENANCE Cleaning Do not use abrasive or harsh cleaners. Dry thoroughly with a soft dedicated cloth. Do not use contaminated cloths when cleaning the General Cleaning Tips stainless steel doors. Always use a dedicated cloth and wipe in the same direction as the grain. •...
Page 30 TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Appliance is unplugged. • Plug the power plug in the outlet properly. A fuse in your home may be blown or the circuit breaker tripped.
Page 31 TROUBLESHOOTING Symptoms Possible Cause & Solution The appliance contains Did you put in food with a strong smell? a bad smell. • Store foods with strong smells in sealed containers. Vegetables or fruit may have spoiled in the drawer. • Throw away rotten vegetables and clean the vegetable drawer. Do not store vegetables too long in the vegetable drawer.
Page 32 The inside lamp in the Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp.
Page 33 TROUBLESHOOTING Noises Symptoms Possible Cause & Solution The appliance is noisy Is the appliance installed on a weak floor or improperly levelled? and generates • Install the appliance on a solid and flat area. abnormal sounds. Does the rear of the appliance touch the wall? •...
Page 34 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
Page 35 Memo...
