Chord ULTIMA PRE Quick Start Manual

Chord Electronics
ULTIMA PRE | Quickstart Manual
Quickstart Manual
Introduction
Welcome to the ULTIMA PRE Quickstart Guide. This shortened guide is
supplementary to the main manual which should be referred to for full
safety and operational information.
Please note, more information on any of these topics is listed within the
full manual found under the product page:
chordelectronics.co.uk/product/ultima-pre
Warranty
The ULTIMA PRE comes with a comprehensive 5-year warranty.
To activate the warranty, please register your device via the Chord
Electronics website:
chordelectronics.co.uk/register-product
Placement
Please ensure there is sufficient ventilation around ULTIMA PRE 2 at
all times. Avoid placing ULTIMA PRE 2 in enclosed spaces, on soft
surfaces, near sources of heat and never cover its ventilation holes. For
optimum operation and ventilation leave some space around the unit.
The Pumphouse, Farleigh Lane, East Farleigh, Kent, ME16 9NB, United Kingdom
info@chordelectronics.co.uk
chordelectronics.co.uk
1.0 Connecting ULTIMA PRE to a source
1.1
Connecting ULTIMA PRE to a power amplifier
2.0
First, you must ensure that ULTIMA PRE, and any connecting
equipment, is turned off.
You can connect ULTIMA PRE to a source using any of the highlighted
inputs shown below.
Please note that each input is arranged as a stereo pair, right and then
left which is indicated on the furthermost sides of the inputs. Later,
when you come to switch ULTIMA PRE on, each pair of inputs will
be shown as 'LINE X' on the display. LINE 1-4 begins with the pairs of
XLRs and LINE 5-8 is the RCA pair next to these and so on.
Note that the connectors on the right hand side of the unit are
outputs and bypass ports. You must not connect any inputs here.
Balanced Unbalanced
input 1-4 line 5-8
To connect ULTIMA PRE to your power amplifier, choose either XLR
or RCA.
It is important to know that if you are using the volume dial or modifying
the balance on ULTIMA PRE, it will only effect this output.
Live XLR
and RCA
Outputs
3.0
4.0
