Summary of Contents for Beko WMY 71441PTL
- Page 1 Washing Machine User Manual WMY 71441PTL Document Number= 2820524935 / 15-08-15.(14:43)
- Page 2 Please read this user manual first! Dear Customer, Thank you for prefering a Beko product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Important instructions for safety and 5 Operating the product environment 5.1 Control panel ..... . .18 1.1 General safety . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section includes security instructions which may help prevent the injuries and material damage risks. All kinds of warranties shall be invalid if these instructions are not observed. 1.1 General safety This product can be used by the children who are at the age of 8 and over and the people whose physical, sensory or mental skills are not fully developed or who do not have necessary required experience and knowledge as long as they are supervised or trained about the safe use of the product and its risks. -
Page 5: Product Safety
Important instructions for safety and environment 1.1.2 Product safety The water supply and draining hoses must be securely fastened and remain undamaged. Otherwise, water leak may occur. While there is still water inside the product, never open the loading door or remove the filter. -
Page 6: Package Information
Important instructions for safety and environment 1.4 Package information Packaging materials of the product are manufactured from recyclable materials in accordance with our National Environment Regulations. Do not dispose of the packaging materials together with the domestic or other wastes. Take them to the packaging material collection points designated by the local authorities. -
Page 7: Your Washing Machine
Your washing machine 2.1 Technical specifications Supplier name or trademark Beko Model name WMY 71441 PTL Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) Class 1 Maximum spin speed (rpm) 1400 Rated capacity (kg) -
Page 8: Overview
Your washing machine 2.2 Overview 1- Power cable 2- Top panel 3- Control panel 4- Drain hose 5- Loading door 6- Filter cap 7- Adjustable feet 8- Detergent drawer 8 / EN Washing Machine / User’s Manual... -
Page 9: Package Contents
Your washing machine 2.3 Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronical water shut-off b- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual... -
Page 10: Installation
Installation 3.2 Removing packaging Apply to the nearest authorized service agent for the installation of your product. To make the reinforcement product ready for use, review the information in Tilt the machine backwards to remove the the user manual and make sure that the electricity, packaging reinforcement. -
Page 11: Connecting Water Supply
Installation 3.4 Connecting water supply 3.5 Connecting to the drain The water supply pressure required to run • Attach the end of the drain hose directly to the product is between 1 to 10 bars (0.1 – waste water drain, lavatory or bathtub. 10 MPa). -
Page 12: Adjusting The Feet
Installation 3.6 Adjusting the feet 3.7 Electrical connection Connect the product to a grounded outlet CAUTION: In order to ensure that the protected by a 16 A fuse. Our company shall not product operates more silently and be liable for any damages that will arise when the vibration-free, it must stand level and product is used without grounding in accordance balanced on its feet. -
Page 13: Preparation
Preparation 4.1 Washing symbols SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures Symbol(s) Drying Suitable for No Iron Do not dry- Sensitive / Do not dry Do not dry... -
Page 14: Sorting The Laundry
Preparation 4.2 Sorting the laundry 4.4 Things to be done for energy saving * Sort laundry according to type of fabric, color, and degree of soiling and allowable water Following information will help you use the product temperature. in an ecological and energy-efficient manner. * Always obey the instructions given on the •... -
Page 15: Correct Load Capacity
Preparation 4.6 Correct load capacity 4.8 Using detergent and softener The maximum load capacity depends on the type When using detergent, softener, starch, of laundry, the degree of soiling and the washing fabric dye, bleacher and decolorant, programme desired. descaling agents; read the manufacturer's instructions written on the package Machine automatically adjusts the water amount and follow the dosages specified. - Page 16 Preparation Choosing the detergent type Using liquid detergents If the product contains a liquid detergent cup: Detergent type to be used depends on the fabric type and color. • Put the liquid detergent container into the • Use different detergents for coloured and white compartment no “2”.
- Page 17 Preparation Using gel and tablet detergent • Oxygen-based decolorant can be used with the detergent; however, if it is not at the • If the gel detergent thickness is fluidal and your machine does not contain a special liquid same consistence, first put detergent in the detergent cup, put the gel detergent into the compartment number “2”...
-
Page 18: Operating The Product
Operating the product 5.1 Control panel 1. Programme selection knob 6 - On / Off button 2 - Spin Speed Adjustment button 7 - Start / Pause button 3 - Temperature adjustment button 8 - End Time Adjustment button 4 - Display 9 - Auxiliary Function buttons 5 - Programme follow-up indicator 10 - Programme Selection lights... -
Page 19: Programme Selection
Operating the product 5.3 Programme selection • Synthetics Use to wash your synthetic clothes (shirts, blouses, 1 Determine the programme suitable for the synthetic/cotton blends, etc.). It washes with a type, quantity and soiling level of the laundry gentle action and has a shorter washing cycle in accordance with the "Programme and compared to the Cottons programme. -
Page 20: Temperature Selection
Operating the product • Woollens laundry type is 60ºC. Washing performance may Use to wash your woolen clothes. Select the not be at the desired level for heavily soiled whites appropriate temperature complying with the tags and stubborn stains (collar, sock soil, perspiration of your clothes. -
Page 21: Spin Speed Selection
Operating the product the steps do not allow it. them from getting wrinkled when there is no water in the machine. If you scroll to cold wash option and press This function holds the laundry in the final rinsing Temperature Adjustment button again, the water. -
Page 22: Programme And Consumption Table
Operating the product 5.6 Programme and consumption table Auxiliary functions Selectable temperature Programme range °C 2.03 1600 • • • • • Cold-90 1.33 1600 • • • • • Cold-90 Cotton 0.93 1600 • • • • • Cold-90 60** 0.78 1600... -
Page 23: Auxiliary Function Selection
Operating the product 5.7 Auxiliary function selection • Prewash A Prewash is only worthwhile for heavily soiled Select the desired auxiliary functions before laundry. Not using the Prewash will save energy, starting the programme. Whenever a programme water, detergent and time. is selected, frames of the auxiliary function symbol that can be selected together with it illuminates. -
Page 24: End Time
Operating the product Time display 4 Press Start / Pause button. Time countdown Remaining time for the completion of the starts. “:” sign in the middle of the end time on programme while it is running is displayed as the display starts flashing. “01:30”... -
Page 25: Changing The Selections After The Programme
Operating the product 5.11 Changing the selections after Changing the auxiliary function, speed and temperature the programme has started Depending on the step the programme has Adding laundry after the programme has reached, you can cancel or activate the auxiliary started: functions. -
Page 26: Canceling The Programme
Operating the product 5.13 Canceling the programme 5.16 Your machine is equipped with a “Standby Mode” The programme is cancelled when the machine is turned off and on again. Press and hold On / Off In case of not starting any programme or waiting button for 3 seconds. -
Page 27: Maintenance And Cleaning
Maintenance and cleaning Service life of product extends and frequently the bellow with a clean piece of cloth after the experienced problems will be reduced if it is programme has come to an end. cleaned at regular intervals. Repeat Drum Cleaning process in every 2 6.1 Cleaning the detergent drawer months. -
Page 28: Cleaning The Water Intake Filters
Maintenance and cleaning 6.4 Cleaning the water intake filters 6.5 Draining remaining water and cleaning the pump filter There is a filter at the end of each water intake valve at the rear of the machine and also at the The filter system in your machine prevents solid end of each water intake hose where they are items such as buttons, coins and fabric fibers... - Page 29 Maintenance and cleaning If the product has an emergency water If the product does not have an emergency draining hose, in order to drain the water: water drain hose, in order to drain the water: a Pull the emergency draining hose out from its seat b Place a large container at the end of the hose.
-
Page 30: Troubleshooting
Troubleshooting Problem Reason Solution Programme cannot Washing machine has switched to self • The programme is cancelled when the protection mode due to a supply problem (line machine is turned off and on again. Press be started or voltage, water pressure, etc.). and hold On / Off button for 3 seconds. selected. Water in the Some water might have remained in the • This is not a failure; water is not harmful to product due to the quality control processes in the machine. - Page 31 Troubleshooting Problem Reason Solution Washing takes longer Water pressure is low. • Machine waits until taking in adequate amount of water to prevent poor washing time than specified quality due to the decreased amount in the manual.(*) of water. Therefore, the washing time extends. Voltage might be low. • Washing time is prolonged to avoid poor washing results when the supply voltage is low. Input temperature of water might be low. • Required time to heat up the water extends in cold seasons. Also, washing time can be lengthened to avoid poor washing results.
- Page 32 Troubleshooting Problem Reason Solution Washing Insufficient amount of detergent has been • Use the recommended amount of used over a long period of time. detergent appropriate for water hardness performance is poor: and the laundry. Laundry turns gray. Washing was made at low temperatures for • Select the proper temperature for the (**) a long time. laundry to be washed.
- Page 33 Troubleshooting Problem Reason Solution It does not rinse well. The amount, brand and storage conditions of • Use a detergent appropriate for the the detergent used are inappropriate. washing machine and your laundry. Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. Detergent is put in the wrong compartment. • If detergent is put in the prewash compartment although prewash cycle is not selected, machine can take this detergent during rinsing or softener step. Put the detergent in the correct compartment.
- Page 34 Troubleshooting Problem Reason Solution Detergent residue in Detergent is put in wet drawer. • Dry the detergent drawer before putting in detergent. the detergent drawer. (**) Detergent has gotten damp. • Keep detergents closed in an environment free of humidity and do not expose them to excessive temperatures. Water pressure is low. • Check the water pressure. The detergent in the main wash compartment • Check the holes and clean if they are got wet while taking in the prewash water.
- Page 35 Troubleshooting Problem Reason Solution Laundry remains Excessive foam might have occurred and • Use recommended amount of detergent. automatic foam absorption system might wet at the end of the have been activated due to too much programme. (*) detergent usage. (*) Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine and to its surrounding environment.
- Page 36 36 / EN Washing Machine / User’s Manual...
- Page 38 www.beko.com...
