Summary of Contents for Surfsight RemoteFound AI-12

  • Page 1 RemoteFound AI-12: User Guide...
  • Page 2 Need Help? support@surfsight.net surfsight.net...
  • Page 3 Thank you! We are excited to introduce to you your new Surfsight AI -12 Connected Dashcam. Surfsight is your next step in fleet safety packed into a sleek powerful device. Now all you have to do is sit back. Surfsight will...
  • Page 4 Explore Surfsight  View live video from your vehicle anytime, anywhere, from any device.  Real-time detection of harsh driving incidents and unsafe driving behavior.  Audio-alerts provide real-time feedback for a safer driving.  Video footage from harsh driving incidents stored in the...

  • Page 5: What's In The Box

    What’s in the box AI-12 Camera Mounting bracket USB cable Specialty screwdriver...
  • Page 6 What’s in the box: Surfsight AI-12 Features Road-facing camera Mounting bracket slot 1080P HD adjustable 140° angle camera Tamper resistant cover for SIM and SD card slots...
  • Page 7 Cabin-facing camera 720P HD adjustable wide angle camera IR for clear night vision Power & auxiliary inputs with locking screws Rotating and Touch screen SOS button locking rings...
  • Page 8 Install Surfsight AI-12  Unscrew the safety screws that lock the tamper proof case using the specialty screwdriver  Insert the SIM and SD cards  Attach the mounting bracket to the camera  Make sure the windshield is clean and dry ...
  • Page 9 DO NOT INSTALL THE PRODUCT IN A LOCATION WHERE IT CAN OBSTRUCT THE DRIVERS FIELD OF VISION.
  • Page 10 Direct camera  Unmount the camera from the windscreen. Make sure that the mounting bracket is not inserted, as it locks the camera position  Use the screwdriver provided to unscrew the three security screws on the round side of the camera ...
  • Page 11  Mount the camera back to the windscreen  Connect the camera to a power source (page 12)  The camera will turn on automatically  To unlock the camera touch screen enter a default PIN number 3333 (page 13)
  • Page 12 Direct camera  On the main screen enter to the ‘Live View’ mode  Use the ‘Live View’ to direct the road facing camera and the cabin facing camera to the proper direction. You can use the arrow keys to switch between the views ...
  • Page 13 Live View...
  • Page 14 Connect the camera to a power source  Surfsight may only be connected to a power source using the supplied cables  The power cable connects to the round connector located on the round side of the camera  The power source must provide 5V DC and at least 2A...
  • Page 15 Unlock the camera  Press the camera touchscreen  Enter the default PIN number 3333  The camera is now unlocked. You entered the camera main menu...
  • Page 16 Calibrating the camera sensors Surfsight AI-12 contains an internal accelerometer that detects unsafe driving events. The accelerometer is not calibrated in advance as the installation in every vehicle is different. Please follow the following steps to calibrate the accelerometer.  Turn on the vehicle ignition ...

  • Page 17: Setting Menu

    Setting menu  Enter the ‘Settings’ mode in the main menu to set your camera:  Calibration the camera accelerometer  Cabin facing camera  WiFi connectivity  Voice alerts  Distracted driver  Overlay text in the video recordings ...

  • Page 18: View Live Video

    View live video  Enter the ‘Live View’ mode in the main menu  The live video will be displayed on the screen  Use the arrow keys below the screen to switch between the road and cabin facing cameras ...
  • Page 19 Arrow keys to switch between the views Back...
  • Page 20 View recorded videos  Enter the ‘Recordings’ mode in the main menu  All the recorded videos on the SD card will be displayed in a list, sorted by date and time  Use the arrow buttons to scroll through the list ...
  • Page 21 Driving alerts  A white vehicle icon will be displayed on the screen while driving  In case of a dangerous driving event such as violent turn or unsafe driver behavior, the car icon will turn red, indicating a visual alert for the driver ...
  • Page 22  Open your internet browser and browse to surfsight.net  Click on the ‘Login’ button at the top menu  If you have a Surfsight account, then simply login to your account  If you do not have a Surfsight account click the ‘Signup’...
  • Page 23 Connect Surfsight AI-12 to your account  Turn on your car ignition  After about a minute you should see the Surfsight’s IMEI* number in the list of devices with a green icon next to it, indicating the camera is online ...
  • Page 24 Surfsight Cloud features A complete video telematics service for your fleet, including;  Live video view from your vehicles  Live location of your vehicles on a map in addition to trip analysis and location history reports  Review and download video footages from unsafe driving events, stored in the cloud for 30 days ...
  • Page 28 Surf Communication Solutions Ltd. surfsight.net Connected Dashcam AI-12 2 Year Limited Warranty Warranty: surfsight.net/warranty EULA: surfsight.net/eula Privacy: surfsight.net/privacy This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
