Assembly Steps - SLIDEWHIZZER SW-04 Assembly Instructions Manual

C
M6 10mm bolt (x 1)
D
M6 washer (x 7)
E
Spring washer (x 7)
F
Domenut (x 7)
G
Tie bar (x 1)
H
Ladder step (x 3)
I
Ladder stabilizar bar (x 1)
TOOL REQUIRED
1. Philips head screw driver
2. Combination Wrench 10
3. Rubber Mallet

Assembly Steps:

step 3
step 2
Step 1 Assembling the Top slide chute and the
L
Handrail tube (x 2)
M
1/4" x 5/8" (x 6)
N
Spanner (x 1)
O
Ground anchor (x 2)
P
Chute bottom support tube (x 1)
X
Steel plate (x 3)
Y
Support Bar (x 1)
step 1
step 6
Q
M4 x 14mm (x 6)
R
Plastic cap (x 4)
U
M6 square washer (x 6)
V
Middle slide chute (x 2)
W
Bottom slide chute (x 1)
step 5
step 4
Page 3 of 11
