Figure 21 Removing Battery from Hinges
Figure 22 Cutting the Battery Wires
Figure 23 Preparing the Replacement Battery
E-Coder)R900i Installation and Maintenance Guide
3
Use the hammer or punch to drive out the seal pin. The head of the
seal pin will shear off, and the body of the seal pin will be under-
neath the register.
4
Pull up on the battery housing to remove the battery from hinges
located on the register as shown in Figure 21.
5
Cut the battery wires one at a time, as close to the battery as possi-
ble. See Figure 22.
6
Prepare the replacement battery.
Maintenance and Troubleshooting
25
