Neptune Technology E-Coder)R900i Installation And Maintenance Manual
  1. Manuals
  2. Brands
  3. Neptune Technology Manuals
  4. Data Loggers
  5. E-Coder)R900i
  6. Installation and maintenance manual

Neptune Technology E-Coder)R900i Installation And Maintenance Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

E-Coder)R900i™ Installation and Maintenance Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-Coder)R900i and is the answer not in the manual?

Questions and answers

Related Manuals for Neptune Technology E-Coder)R900i

Summary of Contents for Neptune Technology E-Coder)R900i

  • Page 1 E-Coder)R900i™ Installation and Maintenance Guide...
  • Page 3 E-Coder)R900i™ Installation and Maintenance Guide...
  • Page 4 This manual is an unpublished work and contains the trade secrets and confidential information of Neptune Technology Group Inc., which are not to be divulged to third parties and may not be reproduced or transmitted in whole or part, in any form or by any means, electronic or mechanical for any purpose, without the express written permission of Neptune Technology Group Inc.
  • Page 5 L'opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l'interférence nocive, et (2) ce dispositif doit accepter n'importe quelle interférence reçue, y compris l'interférence qui peut causer l'opéra- tion peu désirée. E-Coder)R900i™ Installation and Maintenance Guide Neptune Technology Group Inc. Literature No. IM E-Coder)R900i 02.12 1600 Alabama Highway 229 Part No.

  • Page 7: Table Of Contents

    E-Coder)R900i Programming ........
  • Page 8 Replacing the MIU Battery (E-Coder)R900i Inside Version) ........
  • Page 9 Contents Glossary Index E-Coder)R900i Installation and Maintenance Guide...
  • Page 10 Contents Notes: viii E-Coder)R900i Installation and Maintenance Guide...
  • Page 11 Data Logging Activation for E-Coder)R900i Inside ........
  • Page 12 Figures Notes: E-Coder)R900i Installation and Maintenance Guide...
  • Page 13 E-Coder)R900i Flags ........
  • Page 14 Tables Notes: E-Coder)R900i Installation and Maintenance Guide...
  • Page 15 Gateway fixed network data collection system receives the data and stores it to be downloaded into the utility billing system for processing. The E-Coder)R900i is easily installed and operates within an RF band which does not require an operating license. The E-Coder)R900i meets FCC regulations part 15.247 allowing higher output power and greater range.

  • Page 16: E-Coder)R900I Programming

    Product Description E-Coder)R900i Programming The E-Coder)R900i is NOT field-programmable. At the factory, each of the following items is programmed into the MIU: • Serial number - Each MIU is given a unique 10-digit serial number/identification number. • Time between MIU transmissions - The time between MIU transmissions is set for approximately 14 seconds.

  • Page 17: Specifications

    2 Specifications This section provides you with the specifications for the E-Coder)R900i. Electrical Specifications Power Lithium battery Transmitter Specifications Transmit Period Every 14 seconds Transmitter Channels Channel Frequency 910-920 MHz Output Power Meets FCC Part 15.247 FCC Verification Part 15.247...

  • Page 18: E-Coder)R900I Dimensions

    Specifications E-Coder)R900i Dimensions The following diagrams show both the inside and pit dimensions for the E-Coder)R900i. Figure 2 E-Coder)R900i Inside Dimensions Figure 3 E-Coder)R900i Pit Dimensions E-Coder)R900i Installation and Maintenance Guide...

  • Page 19: General Installation Guidelines

    Tools and Materials Table 1 shows the recommended tools you may need to successfully install the E-Coder)R900i or to replace the MIU’s internal battery. Some items may not apply to your specific installation, or the list may not contain all required tools or materials.

  • Page 20: Activating And Reading The E-Coder)R900I

    The light sensor is recessed under the small round hole near the center of the dial face. The hole is marked with a flashlight graphic. See Figure 4. Light sensor Figure 4 Light Sensor for E-Coder)R900i Pit The light sensor activates the LCD display for several minutes when the unit is exposed to a light source.

  • Page 21: How To Read

    Table 2 Icons and Displays Light Sensor, recessed under the small hole near the center of the faceplate of the E-Coder)R900i, supplies the power for the LCD panel (light activated). Flow/Leak Indicator shows the direction of flow through the meter: Water in use Water not in use.

  • Page 22: Common Causes Of Leaks

    Activating and Reading the E-Coder)R900i Common Causes of Leaks If the leak indicator is flashing or continuously on, the E-Coder)R900i is indicating that a possible leak may exist. Leaks can result from various circumstances. To better help you identify a possible leak, the following table contains some common causes of leak prob- lems that can occur.

  • Page 23: How To Tell If Water Is In Use

    • If the arrow does not flash, water is not running. What to Do if There is a Leak The following checklist can be helpful if the E-Coder)R900i leak indicator shows a possible leak. Table 4 Checklist for Leaks Check all faucets for possible leaks.

  • Page 24: Installing The Inside Version

    Unpacking As with all precision electronic instruments, the E-Coder)R900i MIU should be handled carefully; however, no additional special handling is required. When shipped, the assem- bly is lying on its side. You should lift the assembly out of the box by the meter main case.

  • Page 25: Installing The E-Coder)R900I Inside Version Miu

    Some items may not apply to your specific installation, or the list may not contain all required tools or materials. Always follow your company's safety practices and installation guidelines when installing an E-Coder)R900i. Never perform an installation during a lightning storm or under excessively wet conditions. Installing the E-Coder)R900i Inside Version MIU The following are steps for installation of the E-Coder)R900i inside version MIU.

  • Page 26: Retrofit Meter Installation

    Remove the existing register by twisting counter-clockwise. Install the new E-Coder)R900i register head onto the meter body in the desired orientation by twisting clockwise. Test the installation as described in “Testing the E-Coder)R900i Inside Installation”...

  • Page 27: Testing The E-Coder)R900I Inside Installation

    MIU. In a densely saturated area, removing the antenna from the handheld can assist with readings. When the E-Coder)R900i is installed correctly, its MIU ID# and a meter-reading appear on the HHU’s display within one minute. Ver- ify that this is the correct meter reading by comparing it to the meter’s dial.

  • Page 28: Checklist

    Verify that you have followed all requirements of this Installation and Maintenance Guide. Verify that you have recorded all required information. Clean up any installation debris. Verify that the requirements of the Site Work Order have been completed. E-Coder)R900i Installation and Maintenance Guide...

  • Page 29: Installing The Pit Version

    Unpacking As with all precision electronic instruments, the E-Coder)R900i MIU should be handled carefully; however, no additional special handling is required. After unpacking the MIU, inspect it for damage. If the MIU appears to be damaged or proves to be defective upon installation, notify your Neptune Territory Manager or Dis- tributor.

  • Page 30: Installing The E-Coder)R900I Pit Version Miu

    Some items may not apply to your specific installation or the list may not contain all required tools or materials. Always follow your company's safety practices and installation guidelines when installing an E-Coder)R900i. Never perform an installation during a lightning storm or under excessively wet conditions. Installing the E-Coder)R900i...

  • Page 31: Retrofit Meter Installation

    11 Remove the existing register by twisting counter-clockwise 12 Install the new E-Coder)R900i register head onto the meter body in the desired orientation by twisting clockwise. 13 Test the installation as described in “Testing the E-Coder)R900i Inside Installation”...

  • Page 32: Testing The E-Coder)R900I Pit Installation

    MIU. In a densely saturated area, removing the antenna from the handheld can assist with readings. When the E-Coder)R900i is installed correctly, its MIU ID# and a meter-reading appears on the HHU’s display within one minute. Verify that this is the correct meter reading by comparing it to the meter’s dial.

  • Page 33: Data Logging Extraction Steps

    7 Data Logging Extraction Steps The E-Coder)R900i stores consumption in hourly intervals for a rolling total of 96 days. This is equal to 2,304 hourly intervals of consumption. A special data logging activation flashlight is required for this process. This flashlight is used to activate the E-Coder)R900i for data transmission for collection by the CE handheld unit (HHU).
  • Page 34 Listening for Transmissions. (See Figure 11) Figure 11 Listening for Transmissions Activate the E-Coder)R900i register by holding the special LED flashlight activator over the photo-sensor eye which is under the recessed hole in the dial face (noted by the flashlight symbol) until the LED flashes and turns off.
  • Page 35 Data Logging Extraction Steps Once activated properly, the E-Coder)R900i LCD displays RF LOG in place of the register reading. See Figure 13. RF Log Figure 13 RF Log Display for the E-Coder)R900i Inside The HHU begins receiving the interval data. The display on the HHU changes to read Receiving Interval Data along with a prog- ress bar and the percentage success rate.
  • Page 36 Data Logging Extraction Steps Once all the data has been sent to the HHU, the E-Coder)R900i LCD screen goes back to the normal meter reading. Click Save on the HHU screen. The HHU displays Data has been saved indicating that the log data is now stored to the HHU.

  • Page 37: Maintenance And Troubleshooting

    8 Maintenance and Troubleshooting This section takes you through maintenance and troubleshooting procedures for the E-Coder)R900i. The first topic will guide you through the steps necessary to replace the battery that is in the main housing. In addition, this section will guide you through some troubleshooting procedures for both a six-wheel and a four-wheel encoder.

  • Page 38: Replacing The Miu Battery (E-Coder)R900I Pit Version)

    Reactivate the E-Coder)R900i as described in Step 3 on page 13. For help on how to position and activate the MIU, refer to Step 8 on page 12.
  • Page 39 Cut the battery wires one at a time, as close to the battery as possi- ble. See Figure 22. Figure 22 Cutting the Battery Wires Prepare the replacement battery. Figure 23 Preparing the Replacement Battery E-Coder)R900i Installation and Maintenance Guide...
  • Page 40 Attach new battery pack to hinges and swing down into position. Be careful not to pinch any wires during this procedure. Figure 26 Attaching New Battery Pack 10 Push in new register seal pin until it snaps. Figure 27 Pushing Seal Pin E-Coder)R900i Installation and Maintenance Guide...

  • Page 41: Upgrading The E-Coder)R900I Antenna

    Place the flat black rubber washer on the MIU around the male coax connection. See Figure 29. Figure 29 Placing Washer on MIU 10 Apply a coating of Novaguard around the base of the "F" connector and on the flat black rubber washer. E-Coder)R900i Installation and Maintenance Guide...

  • Page 42: Contact Information

    To contact Customer Support by fax, send a description of your problem to (334) 283-7497. Please include on the fax cover sheet the best time of day for a Support Specialist to contact you. To contact Customer Support by email, send your email message to hhsupp@neptunetg.com E-Coder)R900i Installation and Maintenance Guide...

  • Page 43: E-Coder)R900I Flags

    Appendix A: E-Coder)R900i Flags Description of Flags Two tables in this appendix describe the volume represented by the 8th digit by meter size, and the flags used the by E-Coder)R900i. Table 6 8th Digit Resolution by Meter Size Register Size...
  • Page 44 Appendix A Table 7 E-Coder)R900i Flags (continued) Leak Status Flag (Resets After 35 Days) Based on total amount of 15-minute periods recorded in the previous 24-hour period. Leak icon off 8th digit incremented less than 50 of the 96 15-minute intervals...
  • Page 45 The small black plastic nail used to secure the battery pack to the Inside enclosure. transmission time The time between MIU transmissions. The default is approximately fourteen (14) seconds. Custom time is not available. E-Coder)R900i Installation and Maintenance Guide...
  • Page 46 Glossary Notes: E-Coder)R900i Installation and Maintenance Guide...
  • Page 47 24, 25 E-Coder)R900i description dimensions general description ice-maker, leaks install inside version icon reading serial number leak 7, 9 software for advanced features indicator specifications flashing storage, inside flow/leak storage, pit possible leak E-Coder)R900i Installation and Maintenance Guide...
  • Page 48 MIU ID 1, 3 weight MIU ID number sprinkler, leaks MIU transmissions MIU, definition E-Coder)R900i Installation and Maintenance Guide...
  • Page 49 HHU washing machine, leaks testing the installation water in use, determine toilet, leaks weight tools and materials whip, antenna pit version 11, 16 wires, splice recommended wrench, torque torque transcription errors 13, 18 transmission randomness E-Coder)R900i Installation and Maintenance Guide...
  • Page 50 Index Notes: E-Coder)R900i Installation and Maintenance Guide...
  • Page 52 Fax: (905) 858-0428 Tel: (525) 55203 5294 / (525) 55203 5708 TAKE CONTROL Fax: (525) 55203 6503 neptunetg.com M E-Coder)R900i 02.12 Part No. 12835-001 © Copyright 2006-2012, Neptune Technology Group Inc. Neptune is a registered trademark of Neptune Technology Group Inc.

Table of Contents
