- Page 1 Precedence Baths: K-1353-AA K-1354-AA Copyright E1993 Kohler Co. 113019- (1093)
-
Page 2: Important Safety Instructions
Use this unit only for its intended use as denoted in this suction fitting. manual. DO NOT use attachments not recommended by the Kohler Co. Never drop or insert any object into any opening. DANGER: To reduce the risk of injury, do not permit children to use this unit unless they are closely supervised at all times. -
Page 3: Table Of Contents
Follow the sections that pertain Kohler Co. reserves the right to make changes in to your particular installation. This will aid you in avoiding product characteristics, packaging, or availability at any the unnecessary expense associated with improper time without notice. -
Page 4: Roughing-In: K-1353-Aa, K-1354-Aa
ANSI Standard Z124.1. No change in measurements if connected with drain illustrated. 23-1/8” 25-1/2” 32” 37-3/4” AIR COMPRESSOR 8-1/2” 60” 1-1/2” 2-1/2” 3/4” 24” 3-1/2” FIELD WIRING 20-1/2” 3” COMPARTMENT 2” I.P.S. AIR COMPRESSOR 2” O.D. Kohler Co., Kohler WI 113019- (1093) -
Page 5: Product Notices
WARNING: Risk of electrical shock. Connect performance and safe operation of the bath. only to a circuit protected by a Ground-Fault Kohler Co. shall not be liable under its warranty or Circuit-Interrupter (GFCI). otherwise for personal injury or damage caused by... -
Page 6: Installation Requirements
Old Bath Floor Protection Boards B. SUBFLOOR PREPARATION Check flooring under the bath and repair if necessary. Make sure that the subfloor is level. Seal subfloor to reduce the risk of water damage. Kohler Co., Kohler WI 113019- (1093) -
Page 7: Remove Aprons And Inspect Unit
32” Min. apron removal. NOTE: Allow adequate clearance for plumbing. Centerline of drain is 23-1/8” from back of unit. E. PLUMBING PREPARATION Position plumbing according to roughing-in dimensions. Cap supplies and check for leaks. Kohler Co., Kohler WI 113019- (1093) -
Page 8: Before Installing Unit
B. PARTIALLY INSTALL BATH DRAIN Install drain on bath according to manufacturer’s instructions. C. PROTECT BATH UNIT Place a drop cloth or similar material in bath bottom. Be careful not to scratch product. Kohler Co., Kohler WI 113019- (1093) -
Page 9: Install Bath
24”. Set bath into position and align drain tailpiece with trap. Make sure bath is level. C. CONNECT DRAIN When bath is securely positioned, connect drain into trap as shown. Stud Pocket Drain Plumbing Kohler Co., Kohler WI 113019- (1093) -
Page 10: Secure Bath
A bolt-type latch secures the door. It is released by the button on top of the door. After the button is depressed, slight pressure inward should open the door. Back Gasket Air Line Air Compressor Air Compressor Control Box Kohler Co., Kohler WI 113019- (1093) -
Page 11: Field Wire Compressor
Provide a separate equipment grounding conductor for Bonding the inside grounding lug. Ground must not be connected to any current-carrying conductor except at Green Ground the main service breaker box (per National Electrical Wire (Ground) Code, Article 250-61-b). Kohler Co., Kohler WI 113019- (1093) -
Page 12: Test Door System
Suction inward. B. TROUBLESHOOT DOOR SYSTEM This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or a qualified electrician should correct all electrical problems. For warranty service, contact your dealer or wholesale distributor. SYMPTOMS PROBABLE CAUSES RECOMMENDED ACTION 1. -
Page 13: Install Aprons
Resistant gypsum wallboard. Tape and mud drywall... seal drywall Sealer and joints under bath rim. Install finished wall material to subwall. Seal joints between the bath rim and finished wall using silicone sealant. Bath Kohler Co., Kohler WI 113019- (1093) -
Page 14: Install Kick Strip
Do not use metal scrapers, wire brushes, or other metal tools. One of the powder-type detergents may be used on a damp cloth to provide mild abrasive action to the residual plaster. Polystyrene Kohler Co., Kohler WI 113019- (1093) - Page 15 113019- (1093) Kohler Co., Kohler WI...
