SAFETY PRECAUTIONS
When using electrical appliances, basic safety precautions should always be followed. These
instructions should be saved for future reference:
• Read and familiarise yourself with all operating instructions before using this Pedestal Fan.
• Before plugging your unit into the mains, visually check that the unit is intact and has not
suffered any transit damage.
• Do not use this product with a programmer, timer, separate remote-control system or any
other device.
• Check that the voltage indicated on the data plate corresponds with that of the local network
before connecting the appliance to the mains power supply.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. And Children should be supervised to ensure that they do not play with the appli-
ance
Advertisement
Table of Contents
Related Manuals for V-TAC VT-4016-3
Summary of Contents for V-TAC VT-4016-3
- Page 1 SAFETY PRECAUTIONS When using electrical appliances, basic safety precautions should always be followed. These instructions should be saved for future reference: • Read and familiarise yourself with all operating instructions before using this Pedestal Fan. • Before plugging your unit into the mains, visually check that the unit is intact and has not suffered any transit damage.
- Page 2 • Do not immerse the appliance or its cord in water or any other liquids. • Do not leave the appliance unattended during use. • Do not leave the appliance unattended whilst connected to the mains supply. • Always use this appliance on a solid, level, surface. •...
-
Page 3: Introduction & Warranty
INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product. -
Page 4: Technical Data
• 600mm Cross Base • 410mm Round Base • GW:2.6KGS • GW:4.3KGS • Size:600 × 600 × 120mm • Size:430 × 410 × 120mm MULTI-LANGUAGE MANUAL QR CODE Please scan the QR code to access the manual in multiple languages. VT-4016-3 VT-5016-5... -
Page 5: Description Of Parts
DESCRIPTION OF PARTS 1. Front Guard 2. Guard Nut and Screw 3. Fan Blade 4. Rear Guard Central Fixing Nut 5. Rear Guard 6. Speed Control Switches 7. Motor Housing 8. Oscillation Control 9. Motor Spindle 10. Blade Retaining Nut 11. -
Page 6: Product Assembly
PRODUCT ASSEMBLY FIG 1 FIG 2 FIG 3 Step 2. Remove the four Step 3. Unscrew and Step 1. Take the two base screws from the two base remove the pole clamp (14 cross members (18) and push the 4 base end caps members and attach the –... - Page 7 Step 4. Replace the pole clamp (14) and at the same time raise the Guard locating pins chrome adjustable pole (13) then tighten the clamp (14). Step 5. Note the Rear Guard locating pins on Attach the fan assembly on the Motor Housing (7).
- Page 8 FIG 7 FIG 8 FIG 9 Step 7. Take the fan blade (3) and slide it onto the motor spindle (9) ensuring that notch- es on the rear of the fan blade line up with the splines on the spindle. Note: Rear Guard removed for clarity (see figure 7).
- Page 9 FIG 10 FIG 11 FIG 12 Step 10. Move the clips around the outside edge of the front guard outwards (see figure 10). Step 11. Hang the front guard (1) over the top of the rear guard (5) (see figure 11). Step 12.
- Page 10 • Do not immerse the fan or its cord in water or any other liquid. In case of any query/issue with the product, please reach out to us at: support@v-tac.eu For More products range, inquiry please contact our distributor or nearest dealers. V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B...
