V-TAC VT-6056-4 Instruction Manual

Decorative
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SAFETY PRECAUTIONS.
• Before beginning installation of your ceiling fans, read and follow these safety precautions. If
you are not familiar with national and local electrical codes and basic electrical wiring proce-
dures, we recommend that you have a qualified electrician to install your new ceiling fan.
• Before you begin. Turn off the electricity. Determine which circuit your new fan will be using
and remove the fuse or turn off the circuit breaker at the main electrical panel.
• Make sure that all wiring conforms to national and local electrical codes. If you are in ques-
tion, obtain a copy of the codes and wire the fan accordingly. Never leave bare wires uncovered
(wire connection), use wire nuts to cap all connections. Plastic electrical tape is not recom-
mended.
• When working with electricity, never take short cuts. Follow the code in every aspect. Basic
requirements for a ceiling fan installed with lights are match it with specifications, on a ground-
ed circuit with a 15 amp breaker or fuse. Make sure that your electrical system and choice of
location meet these requirements.
• If the location where you plan to install your fan does not already have an electrical outlet,
hire a licensed electrician to run the wiring and install an outlet box designed for ceiling fans or
heavy fixtures. The outlet box should be able to support a minimum moving weight of 22kg and
marked "Acceptable for Fan Support" (Plastic outlet boxes are not recommended for ceiling fan
installation).
• If you plan to use an existing electrical location, check to make sure that the outlet box is not
PLASTIC, that is securely attached and able to support at least 22kg of moving weight and
marked "Acceptable for Fan Support".

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VT-6056-4 and is the answer not in the manual?

Questions and answers

Related Manuals for V-TAC VT-6056-4

Summary of Contents for V-TAC VT-6056-4

  • Page 1 SAFETY PRECAUTIONS. • Before beginning installation of your ceiling fans, read and follow these safety precautions. If you are not familiar with national and local electrical codes and basic electrical wiring proce- dures, we recommend that you have a qualified electrician to install your new ceiling fan. •...
  • Page 2 • The location you choose should have a minimum clearance of 20 inches from any wall to the blade tip at any point in its rotation and a minimum of 7 feet from blade level to floor and 10 inches from the blades. •...
  • Page 3 • The important safeguards and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur. Please ensure to take caution and careful attention to detail are factors which cannot be built into this product. These factors must be supplied by the person or person installing, caring for and operating the unit.

  • Page 4: Introduction & Warranty

    INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product.

  • Page 5: Technical Data

    MULTI-LANGUAGE MANUAL QR CODE INSTRUCTION MANUAL DECORATIVE CEILING FANS (VT-6056-4) Please scan the QR code to access the manual in multiple languages. STEP 1. ATTACH THE MOUNTING BRACKET • Loosen the 2 canopy mounting screws on the downside face or the mounting bracket. Back them out about half way (see figure 1).
  • Page 6 Install the mounting bracket to the electrical junction box in the ceiling. Using two (2) machine screws, two (2) washers, and two (2) lock washers (see figure 2). Note: You may need a longer down rod to maintain JUNCTION BOX proper blade clearance when installing on a steep, sloped ceiling (see figure 3).
  • Page 7 Pull the electric wires in the junction box down through the mounting bracket then bend them up and back out of the way. Place the black wire to one side and the white and ground wire to the other side (see figure 5). The wires should be off to the side and up against the ceiling.
  • Page 8 • Thread the support rod into the support rod coupler until the safety pin can be inserted through the hole in both the rod and coupler. • Insert the safety screw through the hole in the support rod coupler and support rod then attach the washer and retaining clip on the other side.
  • Page 9 STEP 3. HANGING THE FAN BODY • Notice the half ball on the end of the support rod is grooved down one side (see figure 8). This Keyway fits over the small keyway pin on the inside of the mounting bracket and keeps the ceiling fan from spinning on the mounting bracket.

  • Page 10: Making The Electrical Connections

    MAKING THE ELECTRICAL CONNECTIONS • To operate your ceiling fan with the pull chain (sand switches mounted on your fan, follow the instruction below (see figure 11). • If you require or would like to use a different method of controlling your fan refer to the Opti- cal Electrical wiring Procedures.
  • Page 11 STEP 4. INSTALL THE CEILING FAN • If you are using the Flush Mount system skip this step. • Slide the ceiling canopy up into place over the ceiling mounting bracket (see figure 13). The two screws on the side of the mounting bracket face should slip through the key hole slots in the canopy then tighten both screws.
  • Page 12 STEP 6. BLADE ASSEMBLY INSTALLATION • Remove the large screws in the face of the motor. • Discard any rubber blocks attached to these screws. • The rubber blocks are installed at the factory to stabi- lize the motor during shipment. Select the correct mounting pattern and attach each blade to the motor face using pre-installed screws (see figure 15).
  • Page 13 FIG. 16...
  • Page 14 FIG. 17...
  • Page 15 FIG. 18 FIG. 19 BOWL GLASS: • Connect white wire to white wire and blue wire to black wire. Secure with wire nuts. • Remove switch housing screws. Press light kit fixture up into switch housing shell, aligning screw holes. Insert (3) screws and tighten firmly (see figure 18 and 19). •...

  • Page 16: Step 8. Final Checks

    STEP 8. FINAL CHECKS • Check that all safety pins, set screws and connections are properly in place and tight. • Check blade clearance and rotation. • Attach the decorative pull chain tassel(s) to the switch housing. • Located on the side of the switch housing is a slide switch. This switch controls the direction of blade rotation.

  • Page 17: Maintenance

    • Your dealer carries a number of different types of wall switches that have been designed and tested for use with our products. To obtain the best performance electrical components should be matched for output, for that reason we only recommend the use of wall switch(s) that your dealer provides.
  • Page 18 FIG. 22 FIG. 23 In case of any query/issue with the product, please reach out to us at: support@v-tac.eu For More products range, inquiry please contact our distributor or nearest dealers. V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B...
