FGR-115RE
LONG RANGE ETHERNET BRIDGE
Addendum to the FreeWave Manual
v 2.05
FreeWave Technologies Inc.
1880 S Flatiron Ct./ Suite F
Boulder CO 80301
303-444-3862
LAD0001AC Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FGR-115RE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FreeWave FGR-115RE

  • Page 1 FGR-115RE LONG RANGE ETHERNET BRIDGE Addendum to the FreeWave Manual v 2.05 FreeWave Technologies Inc. 1880 S Flatiron Ct./ Suite F Boulder CO 80301 303-444-3862 LAD0001AC Rev B...
  • Page 2: Table Of Contents

    FreeWave Technologies Ethernet Addendum 900 MHz V205 Table of Contents: Description:............................1 Crucial High Traffic LAN Environment Requirements: ..............1 Back Panel:............................2 Front Panel: ............................. 3 Setup: .............................. 4 Menu 1............................4 Menu 0, Submenu F......................... 4 Menu 3 (for Point-to-Point) ....................... 5 Menu 3 (for Point-to-MultiPoint) ....................
  • Page 3: Description

    900 MHz V205 Description: This is an addendum to the FreeWave User’s Manual 900MHz Modems (the "Main Manual"). It covers details applicable specifically to operation of FreeWave Ethernet modems. Please use this addendum in conjunction with the Main Manual. The Data Port in a FreeWave Ethernet Modem is a 10Base-T RJ45 connector, to be used as part of an Ethernet LAN (Local Area Network).
  • Page 4: Back Panel

    DIAG : 3-pin, RS-232-like connector for diagnostics and to program the radio. Adapter cables, part number ASC0409DC, are available from FreeWave. NORMAL/CROSSOVER: Switches the RJ45 connector from normal wiring to crossover wiring to avoid the need for a crossover cable.
  • Page 5: Front Panel

    FreeWave Technologies Ethernet Addendum 900 MHz V205 Front Panel: The modem has 2 rows of LEDs. The bottom row of 3 LEDs is described in the Main Manual. The top row has 7 LEDs that indicate the state of the Ethernet Interface.
  • Page 6: Setup

    FreeWave Technologies Ethernet Addendum 900 MHz V205 Setup: To program the modem, proceed as described in the Main Manual, with the following exceptions: • Capital U on the diagnostics port brings up the Setup menu. • The diagnostic port must be used, as there is no RS232 Data Port in this modem.
  • Page 7: Menu 3 (For Point-To-Point)

    FreeWave Technologies Ethernet Addendum 900 MHz V205 Menu 3 (for Point-to-Point) RADIO PARAMETERS (0) FreqKey (1) Max Packet Size Recommended: "9" (for best throughput) (2) Min Packet Size Recommended: "1" (for best throughput) (3) Xmit Rate … (A) High Noise (B) MCU Speed Must be "1"...
  • Page 8: Installation

    Upon power up, the Ethernet interface’s MAC filtering table can become corrupted, and must be reset, or allowed to timeout. After power up, press the Reset Button on the back of the FreeWave Ethernet, or allow 4.5 minutes to pass and the table to reset. •...
  • Page 9: Glossary Of Terms

    Ethernet Addendum 900 MHz V205 Glossary of Terms: Ethernet Modem: The entire FreeWave modem, which includes a Radio Modem and an Ethernet Interface. Ethernet Bridge: A connection between two Ethernet LANs, using an Ethernet modem at each end. Radio Modem: The radio portion of the Ethernet Modem.
