Sehr geehrter Kunde, wir gratulieren Ihnen zum Erwerb Ihres Klarfit Gerätes. Lesen Sie alle Hinweise sorgfältig durch und befolgen Sie sie, um möglichen Schäden vorzubeugen. Für Schäden, die durch Missachtung der Sicherheitshinweise und un- sachgemäßen Gebrauch entstehen, übernehmen wir keine Haftung. Inhaltsverzeichnis Sicherheitshinweise 2 Hinweise zur Entsorgung 3...
• Heben und bewegen Sie das Gerät sehr vorsichtig, damit Sie sich keine Rückenverletzungen zuziehen. Suchen Sie sich beim Bewegen Hilfe oder nehmen Sie eine rückenfreundliche Haltung ein. • Alle beweglichen Teile müssen wöchentlich gewartet werden. Überprüfen Sie sie vor jedem Gebrauch. Falls irgendein Teil lose ist, befestigen Sie es.
Zusammenbau Schritt 1 Befestigen Sie den vorderen Stabilisator (3) und den hinteren Stabilisator (2) am Hauptrahmen (1). Benutzen Sie dafür die 8 flache Unterlegschreiben (17) und Innensechskantschrauben (8) und ziehen Sie alles fest. Hinweis: Am vorderen Stabilisator sind Transportrollen angebracht. Schritt 2 Lösen Sie den Stellknopf (10) und ziehen Sie ihn heraus, bevor Sie die Sat- telstütze in den Hauptrahmen (1) schieben.
Schritt 6 Befestigen Sie das linke Pedal (11L), das mit einem „L“ markiert ist, mit der Kontermutter links (66) an der linken Kurbel, indem Sie es gegen den Uhrzeiger festdrehen. Befestigen Sie dann das rechte Pedal, das mit einem „R“ markiert ist, mit der Kontermutter rechts (67) an der linken Kurbel, indem Sie es im Uhrzei- ger festdrehen.
Programme und Funktionen Programm auswählen Auf dem Display steht solange MANUAL, bis sie eine Auswahl treffen. Drücken Sie die Pfeiltasten , um die Profile in der folgenden Reihenfolge aufzurufen: MANUAL > P2 > P3 > P4 > P5 > P6 > P7 > P8 > P9 >...
Page 9
THR-Programm • Drücken Sie auf MODE, um THR auszuwählen. Das Display zeigt ENTER TARGET HR, bis sie eine Eingabe machen. Drücken Sie Pfeiltasten, um die Ziel-Herzfrequenz einzugeben. • Drücken Sie dann auf START, um mit dem Training zu beginnen. Der Computer passt die Geschwindigkeit, Watt, etc.
Page 10
Pulsmessung Legen Sie während der Start- oder Erholungsphase Ihre Hände auf die Griffe oder lassen Sie ihren Pulsgurt an. Drücken Sie dann auf die Taste PULSE RECOV. und alle Funktionen bis auf die Zeitanzeige stoppen. Da Gerät misst nun ihre Herzfrequenz. Die Zeit zählt von 00:10 herunter bis 00:00. Falls das Messergebnis in dieser Zeit nicht ermittelt und angezeigt werden kann kehr das Gerät nach 10 Sekunden in den Sportmodus zurück.
Tastenfunktionen START/STOP Drücken Sie auf die Taste, um den Sport-Modus zu starten und mit dem Training zu beginnen. Drücken Sie wäh- rend des Trainings auf die Taste, um eine Pause zu machen. Jeder Wert wird gespeichert. Drücken Sie erneut auf die Taste, um das Training fortzusetzen.
Dear Customer, Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the mentioned items and cautions mentioned in the in- struction manual are not covered by our warranty and any liability. Contents Safety Instructions 12 Hints on Disposal 13...
• Care must be taken when lifting or moving the equipment so as not to injure your back. always use proper lifting techniques and /or seek assistance if necessary. • All moveable accessories(e.g. pedal, handlebar, saddle...etc.) require weekly maintenance. Check them before use every time.
Page 15
Overview of the relevant parts for assembly Name Name Main frame Cross recess head screw Rear stabilizer Waved washer Front stabilizer Console wire(bottom) Seat support post Power connection wire Seat Handle bar (left) Decorative part Allen flat round head screw Front post Seat sliding Console...
Assembly Step 1 Fix the front stabilizer (3) & rear stabilizer(2)on the main frame (1) with eight sets of flat washer (17), mushroom head allen screws (18) tightly. Note: the front sta- bilizer is with transport wheel. Step 2 Loosen the adjusting knob(10) and pull it out first before sliding the seat support post(4) into the seat support post housing on the main frame (1), and align holes for your desired height ,then release the adjusting knob and tighten it properly.
Step 5 Screw out the Cross recess head screw (19) from the console (9), and connect the console wires properly, then align the console (9) with the plate welded on the front post (7), then fix the console (9) with the cross recess head screw (19) tightly.
Programs and Functions Choose Program The message reads “MANUAL” until a selection is made. By pressing the arrow buttons to sc- roll through preset profiles. Will select following programs: MANUAL > P2 > P3 > P4 > P5 > P6 > P7 > P8 > P9 >...
Page 19
THR-Program • If Press MODE button to accept THR program. The message reads “ENTER TARGET HR” until a selection is made. By pressing the arrow buttons to adjust the Target Heart value. • Then press START button and begin exercise. The computer‘s adjusts the speed, watts, etc. to the set heart rate.
Page 20
Recovery Test During the START or PAUSE stage, leave the hands holding on grips or leave the chest transmitter attached and then press PULSE RECOV. button, all function displays will stop except “TIME”. The testing will measure the heartbeat rate, Time starts counting from 00:10 to 00:00 if the measurement does not show within 10 seconds, the measuring system will shut down and return to the sport mode.
Key Functions START/STOP Press this button to start workout in sport mode, and during exercising, press this key to pause the workout. Each value will be stored. Press this key to go on to exercise. Press and hold this button for three seconds for Total Reset(go to Power Up Mode).
