AR 1000T8G18B Series Operating And Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating and
Service Manual
1000T8G18B
Model
Part Number
Serial Number
160 School House Road, Souderton, PA 18964 • 215-723-8181 • Fax 215-723-5688 • www.arworld.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000T8G18B Series and is the answer not in the manual?

Questions and answers

Related Manuals for AR 1000T8G18B Series

Summary of Contents for AR 1000T8G18B Series

  • Page 1 Operating and Service Manual 1000T8G18B Model Part Number Serial Number 160 School House Road, Souderton, PA 18964 • 215-723-8181 • Fax 215-723-5688 • www.arworld.us...
  • Page 3 EC Declaration of Conformity Amplifier Research 160 School House Road Souderton, PA. 18964 declare that our product(s); the Model 1000T8G18 series RF amplifiers to which this declaration relates is in compliance with the following European directives: Low Voltage Directive: 2014/35/EU EMC Directive: 2014/30/EU Supplementary Information: Safety : EN 60215-1:1989...
  • Page 5 Instructions for European EMC Conformity WARNING It is the responsibility of the user of this equipment to provide electromagnetic shielding, filtering and isolation which is necessary for EMC compliance to Directive 2014/30/EU. The equipment must therefore be operated in a shielded area which provides a sufficient level of attenuation to meet the radiated emissions and immunity specifications.
  • Page 7 The caution symbol denotes a potential hazard. Attention must be given to the statement to prevent Your AR equipment may have more than one power supply cable. Use damage, destruction, or harm. only approved power cable(s). If you have not been provided with a Dangerous voltages are present.
  • Page 8 EQUIPMENT CONTAINING LASERS risk of serious injury due to unsafe AR Field Probes (FL/PL Series) and Field Analyzers (FA product handling should be a fundamental Series) are Class 1 laser products containing embedded consideration every user.
  • Page 9 Zur Vermeidung von Personen- oder Sachschäden gilt BEVOR SIE DAS GERÄT ANSCHLIESSEN es, die Hinweise zu beachten. Ihre AR-Ausrüstung hat möglicherweise mehr als ein Stromversorgungskabel. Gefährliche elektrische Spannungen sind vorhanden. Verwenden Sie nur zugelassene Stromkabel. Falls Sie kein Stromkabel oder Höchste Vorsicht ist geboten.
  • Page 10 Die meisten Geräte müssen während des Versands, der Montage und des Gebrauchs LASER-INFORMATION transportiert werden. Jeder Nutzer sollte sich AR - Feldsonden (FL/PL-Serie) und Feldanalysatoren (FA-Serie) über das Risiko von schweren Verletzungen sind Laserprodukte der Klasse 1 mit eingebetteten Klasse-4- durch unsachgemäße...
  • Page 11 électrode de mise à la Votre équipement AR peut disposer de plus d’un câble d’alimentation terre de protection. électrique. Utilisez uniquement un ou des câbles d’alimentation approuves.
  • Page 12 éliminer le risque injustifié de blessures causées par le levage est fournie par les méthodes de travail de NIOSH (publication Les sondes de champ AR (série FL/PL) et les analyseurs de n° 94-110) disponibles sur : champ (série FA) sont des produits laser de classe 1 contenant des lasers intégrés de classe 4.
  • Page 13 Er zijn gevaarlijke elektrische spanningen aanwezig. Wees uiterst voorzichtig. VOOR HET OPZETTEN VAN DE STROOM Uw AR-apparatuur kan meer dan een netvoedingskabel bezitten. Gebruik alleen goedgekeurde netvoedingskabel(s). Koopt een Wijst op een terminal aan die bedoeld is voor aansluiting netvoedingskabel die is goedgekeurd voor gebruik in uw land als u...
  • Page 14 APPARAAT DAT LASERS BEVAT distributie, de assemblage en het gebruik moeten worden behandeld, moet het risico AR-terreinsondes (FL/PL-serie) en terreinanalysatoren (FA- op ernstig letsel als gevolg van een serie) zijn laserproducten van klasse 1 met ingesloten onveilige behandeling van het product een klasse 4-lasers.
  • Page 15 ADDITIONAL WARNINGS & NOTES WARNING: This equipment operates at potentially lethal voltages. Only trained, qualified personnel should operate, maintain, or service it. CAUTION: The information in this document was obtained from reliable sources and was believed to be accurate at the time of publication. Since subsequent modifications to the machine may have been made, use this information only as a guide.
  • Page 17 Suggested Periodic Maintenance for TWT Amplifiers 1. Keep monthly log of the voltages, currents and temperatures as shown on Menus. Also record Date, “Console” and “Operate” hours. Take readings in Operate mode with the gain at zero (0%) percent. Leave unit in Operate mode for 20 minutes (Max Duty if Pulsed Unit), and then record data.

  • Page 19: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ....................i DESCRIPTION AND SPECIFICATIONS ............1 TWTA Description ....................1 Suggested Applications ..................1 Specifications ......................1 Accessories ......................2 Test Data Sheet ...................... 2 THEORY OF OPERATION ................5 Design of the Amplifier ..................5 Control Module ......................
  • Page 20 Model 1000T8G18B 5.4.4 Parts List, HPA Interface Board (Plastic Fibers), A25444-000 ......44 5.4.5 Parts List, 1000T Combiner VPC Interface, A27444-001 ........47 5.4.6 Parts List, Combiner RF Components, IJ Band, A27996-001 ......50 5.4.7 Parts List, 1000 W TWTA IJ-Band, Continuous, 208VAC, A28003-301 ..51 5.4.8 Parts List, 1000 W TWTA IJ-Band, Continuous, 380VAC, A28003-331 ..

  • Page 21: Description And Specifications

    Service panels of the amplifier are interlocked to reduce the likelihood of accidental contact with high voltage. SUGGESTED APPLICATIONS RF Susceptibility testing • Antenna and component testing • Equipment calibration • • General laboratory instrumentation SPECIFICATIONS Refer to the AR RF/Microwave Instrumentation Data Sheet at the end of this section for detailed specifications. Rev B...

  • Page 22: Accessories

    Model 1000T8G18B ACCESSORIES AR RF/Microwave Instrumentation offers a number of accessories for use with this amplifier including: Directional coupler • • Antenna Flexible transmission line • Refer to a current AR catalog for Microwave Accessories. TEST DATA SHEET A Test Data Sheet for a specific unit is prepared at the time of manufacture and is included with the unit's copy of this manual.

  • Page 23: Specifications

    Modular design of the power supply and RF components allow for easy access and re- pair. Use of a switching mode power supply results in significant weight reduction. AR RF/Microwave Instrumentation 160 School House Rd Souderton, PA 18964 215-723-8181 For an applications engi- neer call:800.933.8181...
  • Page 24 Specifications Page 2 POWER (fundamental), CW, @ OUTPUT CON- MODULATION CAPABILITY: Will faithfully repro- 1000T8G18B NECTOR: duce AM, FM, or pulse modulation appearing on the input signal. AM peak envelope power lim- Nominal 1100 watts  M1, M3–M7 ited to specified power. Minimum 1000 watts 7.5-17 GHz, ...
  • Page 25 Total size: 48.3 x 120 x 65.7 cm (19 x 47.25 x To order AR Products, call 215.723.8181. For an applications engineer call:800.933.8181. Direct to Service call: 215.723.0275 or email: service@arworld.us For Faxing Orders:866.859.0582 (Orders Only Please) info@arworld.us...

  • Page 27: Theory Of Operation

    2. THEORY OF OPERATION DESIGN OF THE AMPLIFIER The Model 1000T8G18B TWT amplifier consists of five principal subsystems. From top to bottom, these are the control module (A28010-300 for 380VAC, A28010-301 for 208VAC), Supertube #1 (A28007-006), the RF combiner assembly (A28006-001), Supertube #2 (A28007-006) and the two TWT power supplies (A28013-000).

  • Page 28: Description Of The Rf Combiner Assembly

    Model 1000T8G18B Since the fundamental frequencies are amplified 180° out of phase, the second harmonic products, which represent significant power in the lower part of the band, are largely in phase, and are dumped in the sum port. The residual harmonics are generally lower than –20 dBc, low enough in power that they can be blocked by a reflective filter without harm to the TWTs.

  • Page 29: Description Of The Twt Power Supplies

    Model 1000T8G18B DESCRIPTION OF THE TWT POWER SUPPLIES The two TWT power supplies are housed in separate 19” chassis 5 rack units (8.75") high. Each power supply chassis contains a TWT power supply assembly (A22525-900), an HPA interface board (A25444-000), as well as an AC input line filter and a front panel circuit breaker.
  • Page 30 Model 1000T8G18B Rev B...

  • Page 31: Operation

    3. OPERATION WARNINGS AND CAUTIONS Throughout this manual, the symbol: WARNING: indicates that a hazard exists that may result in personal injury or loss of life. CAUTION: indicates that failure to follow procedures may result in damage to the equipment. WARNING: DANGER - High Voltage Present: Electrical equipment in this TWTA generates and stores high-voltage energy that can result in fatal electrocution.

  • Page 32: Mounting

    Model 1000T8G18B 3.2.2 Mounting The TWTA must be located on a nominally flat surface, and restrained so that it will not inadvertently roll out of position. The casters are not provided with brakes. Set the leveling feet when the TWTA is properly positioned for use.

  • Page 33: Rf Connections

    Model 1000T8G18B 3.2.5 RF Connections The RF output connector is a WRD-750D24 waveguide flange. CAUTION: Never operate the TWTA without a matched output load rated for at least 1200 watts, continuous duty. The TWTA is not provided with an output isolator.

  • Page 34: Front Panel Features

    Model 1000T8G18B FRONT PANEL FEATURES Refer to Figure 3-1 below. Figure 3-1. Front Panel Features Rev B...
  • Page 35 Model 1000T8G18B Table 3-1. Front Panel Features Label Title Function Switchable 7.5 A. circuit breaker; turns on control module, closes contactor providing AC MAIN POWER to the power supply assemblies. OPERATE Push-button; turns on high voltage when all faults and heater delay are cleared. STANDBY Push-button;...

  • Page 36: Front Panel Display And Soft Keys

    Model 1000T8G18B FRONT PANEL DISPLAY AND SOFT KEYS The purpose of the front panel display is to permit the operator to access extensive information about the condition and operation of the TWTA. To accomplish this, a number of informational screens are programmed.
  • Page 37 Model 1000T8G18B Menu screens - The screens at the highest level are called menu screens. There are five menu screens. At power on, the MENU 1 screen is displayed. Each of the menu screens has the soft key S4 labeled MORE. The MORE key (S4) causes the next menu screen to appear.
  • Page 38 Model 1000T8G18B (Sleep Mode activated). This eliminates excessive STANDBY hours on the TWTs while still permitting remote capability to turn on the amplifier. After activating the Sleep Mode: Screen will display COOLING ON while heaters cool down. SYSTEM OFF notifies user that the amplifier is in Sleep Mode To de-Activate Sleep Mode: Press the ON soft key to de-activate Sleep Mode.
  • Page 39 Model 1000T8G18B Event Screen - From MENU 4, S2 (labeled EVENT) provides a display of events logged by the control system. These events include AC power-up, heater warm-up, change from standby to operate, faults, and resets. The events are stored in a first-in-first-out (FIFO) software buffer that has room for 100 events; as new events are logged, the older ones are discarded.

  • Page 40: Rear Panel Features

    Model 1000T8G18B REAR PANEL FEATURES See Figure 3-3 below. Figure 3-3. Rear Panel Features Rev B...

  • Page 41: Initial Turn On And Warm-Up Procedure

    Model 1000T8G18B Table 3-2. TWTA Rear Panel Features Label Title Function 208 or 380 VAC IN AC power input cable (Model dependant) REMOTE INTERFACE Remote control connector. 24 pin hermaphrodite Cooling air intake. Cooling air outlet. RF OUT Type WRD-750D24 flange Connector to remote temperature switch protecting the isolator or load;...

  • Page 42: Remote Ieee-488 Operation

    Model 1000T8G18B output. Do not set input drive above 0 dBm (Input drive above +13 dBm may damage the unit). The reverse power level should remain below 10% of the forward power, assuming that the load is properly matched. An alternate procedure is to pre-set the TWTA gain to minimum, set the RF generator to 0 dBm and then slowly increase the TWTA gain to set the desired RF output level.
  • Page 43 Model 1000T8G18B Command Function Units Response format RDTMPPSHPA1F Returns power supply1 temp (°F) °F PSHPA1F=[ ]F RDTMPPSHPA1C Returns power supply1 temp (°C) °C PSHPA1C=[ ]C RDTMPPSHPA2F Returns power supply2 temp (°F) °F PSHPA2F=[ ]F RDTMPPSHPA2C Returns power supply2 temp (°C) °C PSHPA2C=[ ]C RDTMPTWTHPA1F...

  • Page 44: Catalog Of Status Codes

    Model 1000T8G18B Table 3-4. Catalog of Status Codes (The RDSTAT command causes the TWTA to return a string in the form STATUS=[code], where [code] is an ASCII number whose meaning is given below) Status Code Meaning No command was given. Last command successful.

  • Page 45: Catalog Of System State Codes

    Model 1000T8G18B Table 3-6. Catalog of System State Codes (The RDLOGIC command causes the TWTA to send a string containing an operational state code consisting of 4 ASCII characters representing hex digits. The response is in the form Sys:[w][x][y][z][eol] where the hex values of [w],[x],[y] and [z]are formed as shown below) z bit Meaning...

  • Page 46: Catalog Of *Stb?; Response Codes

    Model 1000T8G18B Table 3-8. *STB?; Response Codes (The command *STB?; causes the TWTA to send a string containing an operational state code consisting of 2 ASCII characters representing hex digits. The response is in the form STATUS:[x][y][eol] where the hex values of [x] and [y] are formed as shown below) y bit Meaning...

  • Page 47: Twta General Considerations

    Cooling during Operate Mode: AR TWTAs have their air outlets and inlets on the rear panels. It is important to prevent the heated air, which is expelled from the TWTA’s air outlets, from being recycled into the air inlets.
  • Page 48 Model 1000T8G18B state amplifiers, and is inherent in present TWTAs. The noise may surprise users new to TWTAs when it accumulates and results in a significant indication in a broadband measurement device – such as a power meter or field probe. The error produced by this indication is not significant when operating near rated TWTA power levels, but may cause difficulty when trying to operate high power TWTAs at low output power levels.

  • Page 49: Maintenance

    4. MAINTENANCE The TWTA requires a minimum of routine maintenance. The only moving parts are the elements of switches, relays and blowers. Preventive maintenance is recommended in Section 4.3. In the event that the TWTA needs repairs, it is recommended that the unit be returned to the factory. However, some user service organizations may choose to perform their own corrective maintenance, and under some circumstances returning the unit to the factory may be impractical.

  • Page 50: Interconnect Cable Identification

    Model 1000T8G18B The air intake filters are the only items that require routine service. The frequency of service depends on the environment where the TWTA is used, and must be determined by inspection If there is accumulated dust on any of the air intake filters, remove them and clean them with dry compressed air.

  • Page 51: Twta Interconnect Cabling

    Model 1000T8G18B TWTA INTERCONNECT CABLING Figure 4-1. TWTA Interconnect Cabling Rev B...

  • Page 52: Troubleshooting

    Model 1000T8G18B TROUBLESHOOTING Symptom Possible cause TWT or power supply overtemperature Air inlet filter(s) dirty Collector heat sink dirty Inadequate clearance behind TWTA High air inlet temperature Defective fan or fan driver No response when main power turned on Disconnected power cable Defective circuit breaker Control module display does not come up;...

  • Page 53: Technical Documentation

    5. TECHNICAL DOCUMENTATION NOTE: The purpose of this technical documentation section is to provide a guide to the TWTA for technician- level servicing. It is intended for use by qualified technical personnel who must troubleshoot and repair the TWTA in the field. Such repairs are typically limited to replacement of modules or major components.
  • Page 54 Model 1000T8G18B Rev B...

  • Page 55: Top Level Build Tree

    Model 1000T8G18B TOP LEVEL BUILD TREE A28003-331 1000 W TWTA IJ-BAND, 380 VAC 3-PHASE, FRONT A28003-301 1000 W TWTA IJ-BAND, 208 VAC 3-PHASE A28006-001 RF COMBINER ASSEMBLY, IJ-BAND A28006-002 RF COMBINER ASSEMBLY, IJ-BAND, FRONT 1A1A1 A27996-001 COMBINER RF COMPONENTS, IJ BAND 1A1A2 A27444-001 1000T COMBINER VPC INTERFACE BRD...
  • Page 56 DATA STEERING BOARD (7 PORT) 1A4A5-A7 A28008-000 F/O TO RS-485 ADAPTER 1A4A9 A28046-000 CONTROL MOD WIRING KIT 1A4A10 A28045-000 CONTROL MOD CAB ASSY AR 1000T, 380VAC 1A4A10 A28045-003 CONTROL MOD CAB ASSY AR 1000T, 208VAC 1A5-A6 A28007-006 500 WATT RF SUBASSEMBLY, IJ-BAND 1A5-A6A9 A28049-000...

  • Page 57: Schematics

    Model 1000T8G18B SCHEMATICS 10-23050-000 HPA Logic and Control (A23050-000) 10-24830-002 Remote Control Board, Foldback only (A24830-002) 10-25444-000 HPA Interface (A25444-000) 10-27444-000 Switcher/Combiner Interface Board (A27444-001) 10-28006-000 RF Combiner, IJ-band (A28006-001/-002) 10-28007-000 IJ-Band supertube Assembly (A28007-006) 10-28010-300 Control Module, 1000T, 380VAC (A28010-300) 10-28010-301 Control Module, 1000T, 208VAC (A28010-301) 10-28013-000...
  • Page 58 Model 1000T8G18B Rev B...

  • Page 59: Block Diagram

    Model 1000T8G18B BLOCK DIAGRAM 25-28006-000 RF Combiner, IJ-Band (A28006-001/-002) Rev B...
  • Page 60 Model 1000T8G18B Rev B...

  • Page 61: Parts Lists

    Model 1000T8G18B PARTS LISTS A22525-900 1000T IJ-Band HV Power supply A23050-000 HPA Logic and Control Module A24830-002 Remote Control Board, Foldback only A25444-000 HPA interface A27444-001 Switcher/Combiner Interface Board A27996-001 Combiner RF Components, 1000T-IJ A28003-301 1000 W TWTA IJ-Band, 208VAC A28003-331 1000 W TWTA IJ-Band, 380VAC, Front Panel Connectors A28006-001...

  • Page 62: Parts List, 1000T I/J-Band Hv Power Supply, A22525-900

    Model 1000T8G18B 5.4.1 Parts List, 1000T I/J-Band HV Power Supply, A22525-900 REF. DESIG. ETM P/N DESCRIPTION QUANTITY A23013-000 MOTHER BOARD A23044-000 H.V. FILTER A23050-000 HPA LOGIC AND CONTROL MODULE A23054-000 HEATER POWER SUPPLY MODULE INPUT FILTER MODULE, PHASE LOST DETECTION A23065-001 NOT USED AVR CURRENT MODE PFC, 3KW, 200-250VAC...

  • Page 63: Parts List, Hpa Logic And Control Module, A23050-000

    Model 1000T8G18B 5.4.2 Parts List, HPA Logic and Control Module, A23050-000 REF. DESIG. ETM P/N DESCRIPTION QUANTITY B23050-000 LOGIC & CONTROL BOARD C48, C49 C06103-000 CAP,10MF,25V,20%,SOLID TANT,RADIAL,(AVX TAP106M025HSB) C16333-000 CAP,33MF,25V,AERL,(NICHICON UVX1E330M) C17104-000 CAP,100MF,50V,AERL,(NICHICON UVX1J101MPA) C2, C5, C15 C31028-000 CAP,1000PF,200VDC,10%,CER,1% FAILURE,(KEMET CKR05 SERIES W/"V" OPTION) C3, C9, C13, C14, C17, C19, C21, C31032-000 CAP,0.01MF,200VDC,10%,CER,1%...
  • Page 64 Model 1000T8G18B REF. DESIG. ETM P/N DESCRIPTION QUANTITY R42, R46, R47, R48, R60, R61, R23100-000 RES,100K,1/2W,1%,MF,100PPM,(DALE RN55D) R74, R78 R23169-000 RES,169K,1W,1%,MF,100PPM,(DALE RN60D) R23499-000 RES,499K,1/2W,1%,MF,100PPM,(DALE RN55D) R33, R55 R23698-000 RES,698K,1/2W,1%,MF,100PPM,(DALE RN55D) R23750-000 RES,750K,1/2W,1%,MF,100PPM,(DALE RN55D) R23845-000 RES,845K,1/2W,1%,MF,100PPM,(DALE RN55D) R23953-000 RES,953K,1/2W,1%,MF,100PPM,(DALE RN55D) R30035-000 RES,10K,1/2W,1%,MF,100PPM,(DALE RN55D) R31091-000 RES,47K,1/4W,5%,CC,<=1% FAIL,(A/B RCR07)

  • Page 65: Parts List, Emergency Bypass Board, A24830-002

    Model 1000T8G18B 5.4.3 Parts List, Emergency Bypass Board, A24830-002 REF. DESIG. ETM P/N DESCRIPTION QUANTITY B24830-000 EMERGENCY BYPASS BOARD C3-C5 C04105-000 CAP,0.1MF,100V,20%,MON,(KEMET C331C104M1R5CA) C06103-000 CAP,10MF,25V,20%,SOLID TANT,RADIAL,(AVX TAP106M025HSB) C1, C2 C31032-000 CAP,0.01MF,200VDC,10%,CER,1% FAILURE,(KEMET CKR06 SERIES W/"V" OPTION) C31040-000 CAP,1MF,50VDC,10%,CER,1% FAILURE,(KEMET CKR06 SERIES W/"V" OPTION) D1, D2 D14454-000 DIODE,AXIAL,(MOTOROLA 1N4454)

  • Page 66: Parts List, Hpa Interface Board (Plastic Fibers), A25444-000

    Model 1000T8G18B 5.4.4 Parts List, HPA Interface Board (Plastic Fibers), A25444-000 REF. DESIG. ETM P/N DESCRIPTION QUANTITY B25444-000 HPA INTERFACE BOARD C161 C03105-000 CAP,0.01MF,100V,CER,10%,RADIAL,(AVX SR201C103KAA) C171 C04223-000 CAP,0.22MF,35V,TANT,RADIAL, [JAMCO 33507] C20, C32, C100 C05153-000 CAP,1.5MF,35V,TANT,RADIAL,(JAMECO TM1.5/35) C129, C163 C05223-000 CAP,2.2MF,35V,10%,SOLID SEALED TANT,RADIAL,(SPRAGUE 199D225X9035BA1) C80, C81, C164 C06103-000...
  • Page 67 Model 1000T8G18B REF. DESIG. ETM P/N DESCRIPTION QUANTITY J16214-000 TEST JACK,YELLOW,VERTICAL,(EF JOHNSON 105- 0857-001) J16215-000 TEST JACK,GREEN,VERTICAL,(EF JOHNSON 105- 0854-001) J16216-000 TEST JACK,BLUE,VERTICAL,(EF JOHNSON 105- 0860-001) J18167-000 D-SUB,37 PIN,FEMALE,PCB MOUNT,RIGHT ANGLE (AMP 745784-4) J18180-000 CONN,D-SUB,15 PIN,MALE,STRAIGHT,PCB MOUNT (POSITRONIC MD15M3000) J31013-000 CONN,D-SUB,25 PIN,MALE,RIGHT ANGLE,PCB MOUNT,[AMP 747238-4] XJ1-XJ4...
  • Page 68 Model 1000T8G18B REF. DESIG. ETM P/N DESCRIPTION QUANTITY U6, U19, U34, U39, U60 U20148-000 IC,HEX INVERTER,SCHMIDTT TRIGGER,(74HC14) (SSD) U20730-000 IC,DUAL J-K FLIP FLOP W/RESET,(7473) (SSD) U21328-000 IC,QUAD 2 INPUT NAND,SCHMIDTT TRIGGER,(74HC132) (SSD) U21388-000 IC,3 TO 8 DECODER/DEMULTIPLEXER,INVERTING,(74HC138) (SSD) U21536-000 IC,DUAL 4 INPUT DIGTAL MULTIPLEXER,(74F153) (SSD) U22598-000 IC,8 BIT ADDRESSABLE LATCH...

  • Page 69: Parts List, 1000T Combiner Vpc Interface, A27444-001

    Model 1000T8G18B 5.4.5 Parts List, 1000T Combiner VPC Interface, A27444-001 REF. DESIG. ETM P/N DESCRIPTION QUANTITY REVD B27444-000 COMBINER INTERFACE C13, C49 C04105-000 CAP,0.1MF,100V,20%,MON,(KEMET C331C104M1R5CA) C144, C148 C04223-000 CAP,0.22MF,35V,TANT,RADIAL, [JAMCO 33507] C1, C19, C24 C05153-000 CAP,1.5MF,35V,TANT,RADIAL,(JAMECO TM1.5/35) C142, C143 C05223-000 CAP,2.2MF,35V,10%,SOLID SEALED TANT,RADIAL,(SPRAGUE 199D225X9035BA1) C06220-000...
  • Page 70 Model 1000T8G18B REF. DESIG. ETM P/N DESCRIPTION QUANTITY J31010-000 CONN,D-SUB,15 PIN,MALE,RIGHT ANGLE,PCB MOUNT,[AMPHENOL 617-A015P-AJ121] J31013-000 CONN,D-SUB,25 PIN,MALE,RIGHT ANGLE,PCB MOUNT,[AMP 747238-4] J31014-000 SPRING LATCH KIT,D-SUB,(AMPHENOL 17-529) K1-K16 K02009-000 RELAY,DPDT,5VDC,125V @ 0.5A / 30VDC @ 1A CONTACTS,PCB TERMINALS,SEALED (OMRON G6H-2-DC5) L1-L4 L00200-000 WIDE BAND CHOKE,(VK200 10/3B FERROXCUBE) Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q22222-000...
  • Page 71 Model 1000T8G18B REF. DESIG. ETM P/N DESCRIPTION QUANTITY U28, U52 U24018-000 IC,JOHNSON DECADE COUNTER W/10 DECODED OUTPUTS, (74HC4017) (SSD) U24138-000 IC,8 BIT BINARY DOWN COUNTER,(74HC40103) (SSD) U26889-000 IC,8 BIT MAGNITUDE COMPARATOR,(74HCT688) (SSD) U16, U48, U68 U28008-000 IC,QUAD 2 INPUT AND,(74HC08) (SSD) U17, U38, U67 U28032-000 IC,QUAD 2 INPUT OR,(74HC32) (SSD)

  • Page 72: Parts List, Combiner Rf Components, Ij Band, A27996-001

    Model 1000T8G18B 5.4.6 Parts List, Combiner RF Components, IJ Band, A27996-001 REF. DESIG. ETM P/N DESCRIPTION QUANTITY E00324-000 DUAL BROADWALL COUPLER, WRD-750 -40, -40 DB [PER SPECIFICATION DRAWING] E00325-000 RF LOAD, 500W, WRD-750, AIR COOLED E00463-000 WRD-750 90 DEG. H-BEND, ALUM, 2.5'' X 2.5'',HNL PER DESCRIPTION] E00464-000 WAVEGUIDE,WRD-750 STRAIGHT, 6.05'' LONG,[HNL...

  • Page 73: Parts List, 1000 W Twta Ij-Band, Continuous, 208Vac, A28003-301

    DESCRIPTION QUANTITY A28006-001 RF COMBINER ASSEMBLY, IJ-BAND CONTINUOUS A5, A6 A28007-006 500 WATT RF SUBASSEMBLY, IJ-BAND A28010-301 CONTROL UNIT, 1000T, 208VAC, 3-PHASE (AR) A2, A3 A28013-000 1000T I/J-BAND P.S. A28015-000 COMBINER CONTROL CABLE A7, A8 A28038-000 TWT CONTROL CABLE, I/J BAND...

  • Page 74: Parts List, 1000 W Twta Ij-Band, Continuous, 380Vac, A28003-331

    QUANTITY A28006-002 RF COMBINER ASSEMBLY, IJ-BAND CONTINUOUS, FRONT PORTS A5, A6 A28007-006 500 WATT RF SUBASSEMBLY, IJ-BAND A28010-300 CONTROL UNIT, 1000T, 380VAC, 3-PHASE (AR) A2, A3 A28013-000 1000T I/J-BAND P.S. A28015-000 COMBINER CONTROL CABLE A7, A8 A28038-000 TWT CONTROL CABLE, I/J BAND...

  • Page 75: Parts List, Rf Combiner Assembly, Ij-Band Continuous, A28006-001

    Model 1000T8G18B 5.4.9 Parts List, RF Combiner Assembly, IJ-Band Continuous, A28006-001 REF. DESIG. ETM P/N DESCRIPTION QUANTITY A24830-002 EMERGENCY BYPASS BOARD A27444-001 1000T COMBINER VPC INTERFACE BOARD, COMPONENT SIDE CONNECTORS A27996-001 COMBINER RF COMPONENTS, IJ BAND, NO SWITCHES OR FILTERS A27999-000 WIRING KIT, COMBINER ASSEMBLY I/J BAND A28008-000...

  • Page 76: Parts List, Rf Combiner Assembly, Ij-Band Continuous, Front Ports, A28006-002

    COMBINER RF COMPONENTS, IJ BAND, NO SWITCHES OR FILTERS A27999-000 WIRING KIT, COMBINER ASSEMBLY I/J BAND A28008-000 F/O TO RS-485 ADAPTER A30869-001 COMBINER MECHANICAL PARTS, 1000IJ CONTINUOUS, FRONT PORTS [AR] G02423-000 STANDOFF,10-32X 1/2,AL/HX,IRIDITE,#14,(ICO RALLY H463) N28182-000 PANEL,REAR, IJ COMBINER N30689-000 HYBRID COUPLER PLATE N30690-000 RF ASSY.

  • Page 77: Parts List, Control Unit, 1000T, 380Vac, 3-Phase, A28010-300

    DATA STEERING BOARD (7 PORT) A25403-300 TWTA CONTROL ASSY 20 CIJ/50X A5-A7 A28008-000 F/O TO RS-485 ADAPTER A28045-000 CONTROL MODULE CABINET ASSY AR 1000T, 380VAC A28046-000 CONTROL MODULE WIRING KIT E00765-000 P.S.,85-264VAC,47-440HZ TO 5VDC & 3.0A,(KEPCO FAW 5-3K/CA 24) E00810-000...

  • Page 78: Parts List, Control Unit, 1000T, 208Vac, 3-Phase, A28010-301

    DATA STEERING BOARD (7 PORT) A25403-300 TWTA CONTROL ASSY 20 CIJ/50X A5-A7 A28008-000 F/O TO RS-485 ADAPTER A28045-003 CONTROL MODULE CABINET ASSY AR 1000T, 208VAC A28046-000 CONTROL MODULE WIRING KIT E00765-000 P.S.,85-264VAC,47-440HZ TO 5VDC & 3.0A,(KEPCO FAW 5-3K/CA 24) E00810-000...

  • Page 79: Parts List, 1000T I/J-Band P.s., A28013-000

    Model 1000T8G18B 5.4.13 Parts List, 1000T I/J-Band P.S., A28013-000 REF. DESIG. ETM P/N DESCRIPTION QUANTITY A21422-000 GRID MODULATOR MODULE A21422-001 MODULATOR,ASSY STANDALONE A22525-900 1000T I/J-BAND HV POWER SUPPLY A23692-000 INSULATED FAN DRIVER A25444-000 HPA INTERFACE BOARD (PLASTIC FIBERS) A26874-000 DUAL MODULATOR LV HARNESS A27773-000 1000T IJ-BAND CABINET ASSY A28008-000...

  • Page 80: Sample Program For Ieee-488 Communication

    Model 1000T8G18B SAMPLE PROGRAM FOR IEEE-488 COMMUNICATION 1000 ! *********************************************** 1010 IEEE-488 COMMUNICATIONS SOFTWARE 1030 7/24/92 AARON D. McCLURE 1040 ! *********************************************** 1041 DIM F$[80] 1042 DIM A$[80] 1050 CLEAR SCREEN 1060 INPUT "INPUT COMMAND TO SEND TO POWER SUPPLY. EXIT TO QUIT.",A$ 1070 IF A$="EXIT"...
  • Page 81 These modules are not field-repairable and should never be opened outside of AR’s Microelectronics Lab. The modules in these product lines have a security label on two sides of the modules between the housing and lid/cover. If the security label is removed and or cut, the warranty of the module will be voided.
