Train-Tech SFX Quick Start Manual

Ideas on how to use SFX Sound capsules with N gauge
Our SFX real sound capsules fit relatively easily into most OO or larger gauge models but wont quite fit in N
without some modification, so here Tammy Palmer shows 2 examples of how you can fit SFX into N gauge stock
so that you can experience real train sounds on your N gauge layout! Please note that the first example requires
reasonable modelling skills using a sharp knife or saw to modify your model - Train-Tech cannot accept any
responsibility for any damage or injury caused. If unsure ask for help from your local model club or shop.
Fitting SFX into an N Gauge box van (a similar technique can be used to fit SFX in another wagon or coach).
The idea is to make a hole in the base of the van so that part of the SFX underhangs between the wheels.
You probably need to use a long wheelbase wagon - we used a Graham Farish 373-053B VBA Box Van EWS
1 First remove the roof of the van body
! ! ! !
3 Using a craft knife or mini saw carefully cut
a small hole in the centre of the body floor.
This is just an initial hole which will be made
larger in the next stage
5 Remove the metal weights from the base.
Use the hole you made in the van body as a
guide to cut the same size hole in the base
!
Telephone (01953) 457800
eMail sales@dcpmicro.com
Website www.train-tech.com
Webshop www.dcpexpress.com
2 Remove the body from the base - on this
model it was glued on. I also cut off the roof
mounting posts to give more room inside
4 Attach the sound tube to the SFX and trim
down the tube using scissors until it sits
snugly inside the van. Then mark and
enlarge the hole in the body floor to fit
6 Be careful not to break the sides of the base
