TECshow QUADBAR 12 PIX User Manual page 5

DMX mode2: 4-ch
DMX mode3: 6-ch
DMX mode4: 48-ch
CH1 CH2
Red 1 Green 1
CH9 CH10
Red 3 Green 3
CH17 CH18
Red 5 Green 5
CH25 CH26
Red 7 Green 7
CH33 CH34
Red 9 Green 9
CH41 CH42
Red 11 Green 11
CH
CH1 0 OFF
CH2 0 OFF
CH3 0 OFF
CH4 0 OFF
CH
CH1 0 OFF
CH2 0 OFF
CH3 0 OFF
CH4 0 OFF
CH5 0 OFF
CH6 0 OFF
CH3 CH4
Blue 1 White1
CH11 CH12
Blue 3 White3
CH19 CH20
Blue 5 White5
CH27 CH28
Blue 7 White7
CH35 CH36
Blue 9 White9
CH43 CH44
Blue 11 White11
DMX Value
1-255 red dimming
1-255 green dimming
1-255 blue dimming
1-255 white dimming
DMX Value
1-255 total dimming
1-255 red dimming
1-255 green dimming
1-255 blue dimming
1-255 white dimming
1-255 strobe adjustment
CH5 CH6
Red 2 Green 2
CH13 CH14
Red 4 Green 4
CH21 CH22
Red 6 Green 6
CH29 CH30
Red 8 Green 8
CH37 CH38
Red 10 Green 10
CH45 CH46
Red 12 Green 12
CH7 CH8
Blue 2 White2
CH15 CH16
Blue 4 White4
CH23 CH24
Blue 6 White6
CH31 CH32
Blue 8 White8
CH39 CH40
Blue 10 White10
CH47 CH48
Blue 12 White12
| Tecshow Quadbar 12 Pix
English version
P. 5
