About this document
This guide outlines the most important information regarding the installation of the camera. For instructions regarding the configuration and further
information, please refer to the configuration manual on CD.
CCPW3025/5025-IR
3M/5M Varifocal Day/Night IR Bullet
Camera
Quick Installation Guide
I/O Connectors (Alarm in/out, Audio in/out)
1
Power Connector for AC 24V
2
RJ-45 Ethernet Connector/ PoE
3
Mounting Bracket with 3 axes
4
Sun Shield Hood
5
Cap
6
Reset button
7
Default button
8
Video Output Connector
9
Micro SDHC/SDXC Card Slot
10
EN
Advertisement
Related Manuals for Vanderbilt CCPW3025-IR
Summary of Contents for Vanderbilt CCPW3025-IR
- Page 1 CCPW3025/5025-IR 3M/5M Varifocal Day/Night IR Bullet Camera Quick Installation Guide I/O Connectors (Alarm in/out, Audio in/out) Power Connector for AC 24V RJ-45 Ethernet Connector/ PoE Mounting Bracket with 3 axes Sun Shield Hood Reset button Default button Video Output Connector Micro SDHC/SDXC Card Slot About this document This guide outlines the most important information regarding the installation of the camera.
- Page 2 Do not attempt to service or modify this device CCPW3025: 11 W (Max) Set the parameters and back up the yourself. Power supply CCPW5025: 11.5 W (Max) configuration. Refer this work to qualified service personnel. Power 12 W (Max.) Consumption Operating -40°C ~ +50°C Temperature © Vanderbilt 2016...
- Page 3 -40°C ~ +60°C Temperature Weight 1600 kg Φ115mm x264mm Dimension Disposal All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities. © Vanderbilt 2016...
- Page 4 CCPW3025/CCPW5025-IR, 3M/5M Varifocal Day/Night IR Bullet Camera Issued by Vanderbilt © Vanderbilt 2016 Clonshaugh Business and Technology Park Data and design subject to change without notice Clonshaugh Supply subject to availability Dublin 17 Document no.: C-300850 Ireland Document version: 2.0 www.vanderbiltindustries.com...
