- Page 1 AGE60S AGE60BL INSTRUCTION MANUAL Do not use the oven until you have read this instruction manual Cod:0040306760...
- Page 2 DEAR CUSTOMER This appliance has been designed to be efficient and easy to use.The following instructions will show you how to best operate your appliance to enjoy years of hassle-free use. it is important to keep this instruction manual and store it in a safe place so that it can be referenced at any time.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ....................4 . . y ....... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS ● To avoid any possible hazard, the appliance must be installed by qualified/authorised personnel only. Installation should be carried out in accordance with the legal regulations and technical requirements of the local gas supplier. Important instructions in this regard may be found in the section “Installation”. ●... - Page 5 SAFETY INSTRUCTIONS Do not make your own alterations to the cooker in order to adapt it to a different ● type of gas, move the cooker to another place or make changes to the power supply. These operations may only be carried out by an authorised electrician or gas fitter.
- Page 6 SAFETY INSTRUCTIONS ● During the operation of gas burners the room may be filled with extra heat and humidity, so it is necessary to assure adequate ventilation. Occasional opening of the window or door should provide enough exchange of air. During the prolonged use of the appliance, or during a very intense use, more ventilation will be required, and it will probably be necessary to engage the extractor hood.
-
Page 7: Disposal Of The Appliance
HOW TO SAVE ENERGY UNPACKING Using energy in a During transportation, responsible way not only protective packaging was saves money but also used to protect the helps the environment. So appliance against any let’s save energy! damage. After unpacking, please dispose of all ●... -
Page 8: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Spark ignitor Burner safety valve (optional) Auxiliary burner Rapid burner Wok burner Grate Control panel Semi-Rapid burner Oven door handle Drawer Because we contiunally strive to improve our products. We may change our specifications and designes without prior notice. -
Page 9: Installation
INSTALLATION This appliance must be installed by an authorised person in accordance with this instruction manual, AS/NZS 5601.1-Gas installations (installation and pipe sizing), local gas fitting regulations, local electrical regulations, Building Code of NewZealand and any other government authority. Overhead clearances-(Measurement A) Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s... - Page 10 INSTALLATION Gas connection ● Install the cooktop Remove the crown caps and burner Caution! crowns from the oven, and arrange The cooker should only be connected to a them on the cooktop as per the earlier gas supply of the particular type that the diagram entitled.
- Page 11 INSTALLATION Caution! Flexible hose connection On completion of the cooker installation, In case the appliance is connected by the tightness of all connections should be means of a flexible hose, the position A of the hose is not permissible. Do not use fire to check tightness. In case the connection hose is made of Fix the cooker to the back wall with metal, position A is permissible.
- Page 12 INSTALLATION In order to adapt the cooker to burn a Adapting the cooker different type of gas, you should: another type of gas ● Exchange nozzles (see tables below), This operation may only be carried out by ● Adjust the flame intensity. Caution! When leaving the factory, burners are To adapt the cooker to be...
- Page 13 INSTALLATION Caution! Replacement of a burner ● Adapting the appliance to a different nozzle: Unscrew the type of gas than that indicated by the nozzle with special socket manufacturer of the cooker on the data spanner No 7 and replace plate, or purchasing a cooker for a different with a new one according type of gas than supplied to thehouse, is...
-
Page 14: Operation
OPERATION Oven function Control knobs Oven temperture Control knobs Top burner control knobs Before first use Switch on the ventilation in the room or Remove packaging elements, open a window, Gently (slowly) remove labels from the over door, trying not to break the glue Heat the oven(to a temperature of tape. -
Page 15: How To Use Gas Burners
OPERATION Ignition without an ignitor How to use gas burners Light a match. Press in the knob to the end and turn Choice of cookware it left to the MAX, Ignite gas with a match.， Mind that the diameter of a pan base is ... -
Page 16: Oven
OPERATION Selection of the approprite flame Oven A correctly adjusted burner has a light blue Oven is controlled by the function knob flame with a clearly visible internal cone. and the temperature control knob. Flame size depends on the position of the burner knob which has been set. - Page 17 OPERATION Button1 Button2 Button3 Cooking time Display field Seconds Icon End of cooking time Function To decrease the numbers Timer on the digital display Current time To increase the numbers on the digital display...
- Page 18 OPERATION directly press the button 2, At power on, displayed “12.00", your setting is saved. flashes. The current time can be set with button 1 and 3, 5 seconds after the time has been set ,the new data will be saved . and 59 minutes.
- Page 19 OPERATION end of cooking time End of cooking time end of cooking time End of cooking time = current time + cooking time set either the end of cooking time. end of cooking time Press the function button , After the auto function be off,the cooking time to 0,end of cooking time and current time remains the same.
- Page 20 OPERATION cooking end of cooking time: End of cooking time automatically change to 5:00. end of cooking time to adjust the cook time, And press button 2. cooking Cooking time automatically change to 3:00. always on. and the will go off. Press any button,the alarm signal and the alarm l l i...
- Page 21 OPERATION end of cooking time- end of cooking time The oven is switched off automatically. 1 and 3. 1 and 3. ● End of cooking time > current time + cooking time <= 10hours At least more than one minute cooking ●...
- Page 22 OPERATION end of cooking time- end of cooking time The oven is switched off automatically. 1 and 3. 1 and 3. ● End of cooking time > current time + cooking time <= 10hours At least more than one minute cooking ●...
- Page 23 OPERATION Fan Forced Static Grill At this function, allows the oven to be When the “combined grill” is active it heating up in a forced way with the enables grilling with the grill and with the thermofan, which is in the central part of top heater switched on at the same time.
- Page 24 OPERATION Repacement of the oven Oven guide levels light bulb Baking pans and accessories (oven grid, Before any maintenance is started baking tray, etc) may be inserted into the involving electrical parts, the oven in 6 guiding levels. appliance must be disconnected Appropriate levels are indicated in the from the power supply.
-
Page 25: Baking In The Oven
BAKING IN THE OVEN Baking We recommend using the baking trays which were provided with your cooker which should be put on the drying rack; Before the cake is taken out of the oven, check if it is ready using a wooden stick(if the cake is ready the stick should come out dry and clean after being inserted into the cake);... - Page 26 BAKING IN THE OVEN Roasting meat Cooking meat weighing over 1 kg in the oven, but smaller pieces should be cooked on the gas burners. Use heat proof ovenware for roasting, with handles that also resistant to high temperature. When roasting on the drying rack or the grate we recommend that you place a baking tray with a small amount of water on the lowest level of the oven;...
-
Page 27: Cleaning And Maintenance
CLEANING AND MAINTENANCE By ensuring proper cleaning and maintenance of your cooker you can have a significant influence on the continuing fault-free operation of your appliance. Before you start cleaning, the cooker must be switched off and you should ensure that all knobs are set to the “... - Page 28 CLEANING AND MAINTENANCE Removal of the internal glass panel Door removal Unscrew and unfasten the plastic latch that In order to obtain easier access to the oven is in the corner at the top of the door. Next chamber for cleaning , it is possible to take out the glass from the second blocking remove the door.
- Page 29 CLEANING AND MAINTENANCE In the event of an emergency, you should: Switch off all working units of the cooker Disconnect the mains plug Call the service centre Some minor faults can be fixed by referring to the instructions given in the table below. ...
-
Page 30: Technical Information
TECHNICAL INFORMATION Type AGE60S AGE60BL Dimensions: 900/600/600 height/width/depth(mm) Gas inlet: right rear 150mm from top Oven Guide levels 0.85 Top heater(kW) 1.15 Bottom heater(kW) Grill heater(kW) Oven illumination(W) Function modes Top+bottom heater(kW) Top+bottom heater+fan(kW) Fan+Rear heater(kW) 1.15 Bottom heater(kW) Fan+Bottom heater(kW) 1.15... - Page 31 Appliance Group Award Appliances (NZ) Limited Email: sales@award.co.nz www.awardappliances.co.nz...
