ZyXEL Prestige 480 (DSS1 – European)
Release Note / Manual Supplement
Date: January 20, 2000
This document describes the enhancements in ZyXEL Prestige product line since the last
manual printing.
The New Features section lists the new features added to this release.
Supported Platforms
ZyNOS 2.42(O.00) supports Prestige models: P480.
RVS-COM Lite Version: V1.63
New Features:
Mega-Bundle
Some ISP does not support multilink bundle of more than 2 links (it's inefficient any
way), therefore, it is currently impossible for a user to dedicate all 4 channels
available in a P-480 to Internet access. To differentiate P-480 from other similarly
equipped products, it is desirable to be able to support bundle of 4 links where P-480
calls a second ISP when the traffic exceeds a certain threshold and split the traffic
between the two connections. We'll call this bundling of ISPs "Mega-Bundle".
NetCAPI: RVS-COM ISDN-DCP support.
Supprot RVS-COM NetCAPI protocol.
IP Alias
In this release, Lan port can assign more than one IP address.
IP Policy Routing
This feature allows you to choose the gateway for certain IP packets.
IPX Routing
This feature allows you to route IPX packets.
Bridge
This feature allows you to bridge different network.
Upgrade Firmware via FTP
User can upgrade ZyNOS F/W by FTP.
Restore Configuration File via FTP
Users can restore configuration by FTP.
1
ZyNOS v2.42(O.00) | 01/20/2000
Advertisement
Related Manuals for ZyXEL Communications Prestige 480
Summary of Contents for ZyXEL Communications Prestige 480
- Page 1 ZyXEL Prestige 480 (DSS1 – European) ZyNOS v2.42(O.00) | 01/20/2000 Release Note / Manual Supplement Date: January 20, 2000 This document describes the enhancements in ZyXEL Prestige product line since the last manual printing. The New Features section lists the new features added to this release.
- Page 2 Enhancement Details: Mega-Bundle Setup In order to setup more than one ISP account, there is a little change in Remote mode setup procedure in Menu 11.2 when you want to setup a remote node as a “supplementary remote node”. In previous ZyNOS v2.4, there is only ISP account. I call the remote node as “ISP remote node”.
- Page 3 4. Set “Rem IP Addr= 1.2.3.4”. The value can be arbitrary IP address except “0.0.0.0” and “1.1.1.1”. 5. Set “Edit IP/IPX/Bridge= Yes” and then press Enter. You will enter menu 11.3. 6. Set “Rem Subnet Mask= 0.0.0.0” 7. Save the configuration. Check the configuration in menu 11.
- Page 4 The setup procedure of “Mega-Bundle” First an ISP remote node must be configured. 1.Setup ISP in menu 4. 2.Set “Multilink= BOD” or “Multilink= “Always” in menu 4 3.Set “Single User Account= Yes” 4.In menu 11, edit the ISP remote node. 5.Set “Edit PPP Options= Yes”...
- Page 5 Menu 25.1 - IP Routing Policy Policy Set Name= test Active= Yes Criteria: IP Protocol Type of Service= Don't Care Packet length= 0 Precedence = Don't Care Len Comp= N/A Source: Addr start= 0.0.0.0 end= N/A Port start= N/A end= N/A Destination: Addr start= 0.0.0.0 end= N/A...
- Page 6 ftp>hash ftp> put rasp480.bin ras ftp> by Now the firmware is update by ftp. NetCAPI: RVS-COM ISDN-DCP support. 1. Setup Go to Edit NetCAPI Setup in Menu 2 Menu 2 - ISDN Setup 1. ISDN Line 1 Setup 2. ISDN Line 2 Setup 3.
- Page 7 When you want to use NetCAPI to place outgoing calls or to listen incoming calls, you must start RVSCOM in your PC, and RVSCOM will register itself to the Prestige. This option is the limit of the maximum number of PC that can run RVSCOM at the same time. Incoming Data Call Matching: [MSN] means directing this call to the Prestige only when the incoming phone number matches the ISDN DATA number in menu 2.
- Page 8 Look at Figure 2. The red packets are sent by PC. After the packets forwarded by P480, I used green packet to present the packets. The configuration of P480 is assumed that SUA is enable when you dial to ISP. The build-in packet scheduler of P480 will try to separate data flow into different connections. The packets sent by PC01 and PC02 are forwarded by connection (1) and those sent by PC03 are forwarded by connection (2).
-
Page 9: Known Bugs
Known Bugs: 1. When PC is using NetCapi service of P480, each PC can only activate one Capi aplication at the same time. 2. In order to use NetCapi, users must edit the file “autoexec.net” to change some system parameters. The old values are as following: ip tcp limit 2 ip tcp window 2...
