Pocket digital radio

Advertisement

Quick Links

P E T E R S F I E L D
P O C K E T D I G I T A L R A D I O
CB1A-DAB-BLK
Instructions Guide
EN

Advertisement

Table of Contents
loading

Summary of Contents for MAJORITY PETERSFIELD

  • Page 1 P E T E R S F I E L D P O C K E T D I G I T A L R A D I O CB1A-DAB-BLK Instructions Guide...
  • Page 2: Table Of Contents

    Mono and Auto Audio ������������������������������������������������������������������������������� 9 FM Station Information ���������������������������������������������������������������������������� 10 Radio Settings ��������������������������������������������������������������������������������������������11 Additional Features ���������������������������������������������������������������������������������� 12 Troubleshooting �����������������������������������������������������������������������������������������13 Specifications ���������������������������������������������������������������������������������������������14 Warranty �����������������������������������������������������������������������������������������������������14 Safety Information �������������������������������������������������������������������������������������15 Register your product online for a FREE 3 year extended warranty at: www.majority.co.uk...
  • Page 3: Box Contents

    Box Contents Box Contents Majority Petersfield Pocket DAB USB Charging Cable Earphones User Guide...
  • Page 4: Controls And Functions

    Controls And Functions Control Buttons 1� Power (On/Off) 5� Previous 9� Menu/Info 2� Earphone jack 6� Volume - 10� Display screen 3� Standby/Mode 7� Enter/Lock 11� USB IN jack 4� Volume + 8� Next...
  • Page 5: Instructions Guide

    Instructions Guide Navigation Controls ON/OFF Button Switch your radio ON or OFF with the switch on the top of the radio� Standby/Mode Press the ‘Standby/Mode’ button (Ref.3) to switch on the radio or press and hold to put it in standby mode. When in working mode, press to switch between DAB and FM mode�...
  • Page 6: Basic Operation

    Instructions Guide Basic Operation Please note all (Ref.) refer to the Controls and Functions guide on Page 2. Ensure the device has been charged� The battery life is displayed on the screen. To charge the device, use the USB cable provided to plug it into a computer or a USB mains plug�...
  • Page 7: Dab/Dab+ Radio Mode

    Instructions Guide DAB/DAB+ Radio Mode Please refer to page 4 to ensure that your radio is set up correctly� To auto scan (if the unit has not automatically done so, or has no signal) press and hold the ‘Info/Menu’ button (Ref.9). When the display shows “FULL SCAN”, press the ‘Enter’...
  • Page 8: Dab Station Information

    Instructions Guide DAB Station Information When listening to a DAB station, you can view station information. To do this, press the ‘Info/Menu’ button (Ref.9) repeatedly. Dynamic Label Segment (DLS): Displays scrolling text information supplied by the broadcaster� PTY (Programme Type): Shows the type and description of the programme provided by the DAB station�...
  • Page 9: Setting Dab/Fm Preset Stations

    Instructions Guide Setting DAB/FM Preset Stations How to preset a radio station Up to 10 preset stations can be preset for easy navigation� Press and hold the ‘Enter’ button for 2-3 seconds (Ref.7) until the Preset settings open� “Preset Empty x” will show on the display to indiciate an empty preset number�...
  • Page 10: Fm Radio

    Instructions Guide FM Radio Press the ‘Standby/Mode’ button (Ref.3) to switch to FM mode. The first time FM mode is selected, the FM frequency “87.5 MHz” will be displayed on the screen� To auto scan to the next available station, press and hold the ‘>’ button (Ref.8) and then release.
  • Page 11: Mono And Auto Audio

    Instructions Guide Mono and Auto Audio Mono and Auto In working mode, press and hold the ‘Info/Menu’ button (Ref.9) to open FM settings� Use the ‘>’ button (Ref.8) to scroll through available FM settings. The options “SET TO MONO” and “SET TO AUTO” will display. To select Mono or Auto, press the ‘Enter’...
  • Page 12: Fm Station Information

    Instructions Guide FM Station Information When listening to an FM station, you can access station information. To do this, press the ‘Info/Menu’ button (Ref.9) repeatedly to show the programme information� Radio Text: Displays scrolling text information supplied by the broadcaster� Programme Type: Displays a description of the type of programme provided by the broadcaster�...
  • Page 13: Radio Settings

    Instructions Guide Radio Settings Time and Date On first use of DAB Radio, the time and date will automatically update. Set Language Press and hold the ‘Info/Menu’ button (Ref.9) to enter radio settings.Use the ‘<’ or ‘>’ button (Ref.5/Ref.8) to select your language option. Press the ‘Enter’...
  • Page 14: Additional Features

    Instructions Guide Additional Features Charging the Radio Connect the small end of the USB cable (supplied) into the charging port at the bottom of the radio (Ref.11). Connect the other end of the USB cable into a free USB port on your computer or another mains charger� Your radio has an internal re-chargeable battery�...
  • Page 15: Troubleshooting

    Troubleshooting Troubleshooting Observation Potential Cause/Solution Check that the radio is charging and use when fully charged� No power/function Ensure radio is switched on by holding down the ON/OFF button� Check whether unit is set to MUTE. A station may not be tuned in� Perform a No sound rescan of the DAB or FM mode and ensure that you are in an area with good signal�...
  • Page 16: Specifications

    9.5 x 5.5 x 1.5 cm; 99.8 g Dimensions Support If you require further assistance with your new product, please contact our support team on the Majority website: www.majority.co.uk/support Warranty All products come with a standard 12 month warranty� All items must be registered on www.majority.co.uk...
  • Page 17: Safety Information

    Safety Information ADDITIONAL WARNINGS 1� Read these instructions� 2� Keep these instructions� Instructions are also The apparatus shall not be exposed to dripping or available for download at www�majorityradios� splashing and no objects filled with liquid, such as co.uk vases, shall be places on the apparatus. 3�...
  • Page 18 www.majority.co.uk...
