Matrix MAGNUM Series Manual page 3

PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. If applicable, adjust seat pads, leg pads, foot pads, range of motion
adjustment, or any other type of adjustment mechanisms to a comfortable
start position. Make certain that the adjusting mechanism is fully
engaged to prevent unintentional movement and to avoid injury.
4. Sit on bench (if applicable) and get into appropriate position for exercise.
5. Exercise using no more weight than you can safely lift and control.
6. In a controlled manner, perform exercise.
7. Return weight to its fully-supported start position.
MAINTENANCE CHECKLIST
ACTION
Clean Upholstery
1
Inspect Cables
2
Clean Guide Rods
Inspect Hardware
Inspect Frame
Clean Machine
Clean Grips
1
Lubricate Guide Rods
3
Upholstery & Grips should be cleaned with a mild soap
1
and water or a non-ammonia based cleaner.
2 Cables should be inspected for cracks or frays and immediately replaced if present.
If excessive slack exists cable should be tightened without lifting the head plate.
Guide rods should be lubricated with Teflon based lubricant. Apply the
3
lubricant to a cotton cloth and then apply up and down the guide rods.
FREQUENCY
Daily
Daily
Monthly
Monthly
Bi-Annually
As Needed
As Needed
As Needed
WARRANTY
For North America, please visit www.matrixfitness.com for warranty
information along with warranty exclusions and limitations.
PRODUCT SPECIFICATIONS
Max User Weight
Max Training Weight
Max Effective Resistance
Starting Resistance
Product Weight
Overall Dimensions
(L x W x H)*
* Ensure a minimum clearance width of 0.6 meters (24") for access to and
passage around MATRIX strength equipment. Please note, 0.91 meters (36")
is the ADA recommended clearance width for individuals in wheelchairs.
TORQUE VALUES
M12 Bolt (Nyloc Nut & Flowdrill)
M10 Bolt (Nyloc Nut & Flowdrill)
M8 Bolts
M8 Plastic
M6 Bolts
Pad Bolts
159 kg / 350 lbs.
102 kg / 225 lbs.
227 kg / 500 lbs.
22.7 kg / 50 lbs.
154 kg / 340 lbs.
168 x 133 x 109 cm /
66.5" x 52.5" x 43"
135 Nm / 100 ft-lbs.
77 Nm / 57 ft -lbs
25 Nm / 18 ft-lbs
15 Nm / 11 ft-lbs
15 Nm / 11 ft-lbs
10 Nm / 7 ft-lbs
3
