Matrix MAGNUM Series Assembly Instructions

M AT R I X F I T N ES S | 1 60 0 L A N D M A RK D R I V E C O T TA GE G R O V E W I 5 3 5 2 7 U SA
To l l F r e e
86 6. 6 93 . 4 86 3 |
MX15_MAGNUM_OM_MG-PL71 hack squat_r1_5.indd 1
m a t r i x f i t n e s s . c o m | F a x
6 0 8 . 8 3 9 . 8 6 8 7
PA R T # M H 02 0 4 5 2 8 B
REV. 1.5
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX products to instruct all individuals, whether they
are the end user or supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX exercise equipment be informed of the following
information prior to its use.
Do not use any equipment in any way other than designed or intended by the manufacturer.
It is imperative that MATRIX equipment be used properly to avoid injury.
INSTALLATION
1. STABLE AND LEVEL SURFACE: MATRIX exercise equipment must be installed on a stable base
and properly leveled.
2. SECURING EQUIPMENT: Manufacturer recommends that all stationary MATRIX strength
equipment be secured to the floor to stabilize equipment and eliminate rocking or tipping over. This
must be performed by a licensed contractor.
• All anchor points must be able to withstand 750 lbs. (3.3 kN) pull-out force.
MAINTENANCE
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only
replacement parts supplied by your country's local MATRIX dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain
important information. If unreadable or missing, contact your MATRIX dealer for a replacement.
3. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment
as well as keeping your liability to a minimum. Equipment needs to be inspected at regular intervals.
4. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is
qualified to do so. MATRIX dealers will provide service and maintenance training at our corporate
facility upon request.
ADDITIONAL NOTES
This equipment should only be used in supervised areas where access and control is specifically
regulated by the owner. It is up to the owner to determine who is allowed access to this training
equipment. The owner should consider a user's: degree of reliability, age, experience, etc.
This training equipment meets industry standards for stability when used for its intended purpose in
accordance with the instructions provided by the manufacturer.
This equipment is for indoor use only. This training equipment is a Class S product (designed for use in a commercial environment such as a
fitness facility). This training equipment is in compliance with EN ISO 20957-1 and EN 957-2.
PROPER USAGE
1. Do not exceed weight limits of the exercise device.
2. If applicable, set safety stops to appropriate height.
3. If applicable, adjust seat pads, leg pads, foot pads, range of motion adjustment, or any other type of adjustment mechanisms to a comfortable
start position. Make certain that the adjusting mechanism is fully engaged to prevent unintentional movement and to avoid injury.
4. Sit on bench (if applicable) and get into appropriate position for exercise.
5. Exercise using no more weight than you can safely lift and control.
6. In a controlled manner, perform exercise.
7. Return weight to its fully-supported start position.
MAINTENANCE CHECKLIST
ACTION FREQUENCY
Clean Upholstery * Daily
Inspect Cables Daily
Clean & Lubricate Guide Rods † Monthly
Inspect Hardware Monthly
Lubricate Linear Shafts † Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips * As Needed
* Upholstery & Grips should be cleaned with a mild soap and water or a non-ammonia based cleaner.
† Guide rods and linear shafts should be lubricated with Teflon based lubricant. Apply the lubricant to a cotton
cloth and then apply up and down the guide rods/linear shafts.
PRODUCT SPECIFICATIONS
TECH SPECS
Max. User Weight 159 kg / 350 lbs
Max. Training Weight 245 kg / 540 lbs
Product Weight 270 kg / 595 lbs
Overall Dimensions (L x W x H)* 229 x 150 x 145 cm / 90" x 59" x 57"
Starting Resistance 47.6 kg / 105 lbs
Weight Horn Diameter (Storage) 3.8 cm / 1.5"
Weight Horn Diameter (Working Arms) 5 cm / 1.97"
* Ensure a minimum clearance width of 0.6 meters (24") for access to and passage around MATRIX strength
equipment. Please note, 0.91 meters (36") is the ADA recommended clearance width for individuals in wheelchairs.
WARRANTY
VALID IN NORTH AMERICA ONLY
Frame (not coatings) * 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
Accessories 6 months
* Frame is defined as the welded metal base of the unit and does not include removable parts.
Product specifications subject to change without notice.
WARNING WARNING
DEATH OR SERIOUS INJURY CAN OCCUR ON THIS DEATH OR SERIOUS INJURY CAN OCCUR ON THIS
EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID
INJURY! INJURY!
1. All warnings and instructions should be read and 1. Keep children under the age of 14 away from this
proper instruction obtained prior to use. Use this strength training equipment. Teenagers must be
equipment for its intended purpose ONLY. supervised at all times while using this
2. ALWAYS use a spotter if working out on this equipment.
equipment. 2. This equipment is not intended for use by persons
3. Do not allow the lifting bar/sled to drop suddenly. with reduced physical, sensory or mental
4. Visually ensure lifting bar catches are fully capabilities, or lack of experience and knowledge,
engaged and seated in the hooks before releasing unless they have been given supervision or
the load and exiting the machine. instruction concerning use of the equipment by a
5. Adjustable stops must be used at all times. person responsible for their safety.
6. ALWAYS set both adjustable stops to the same 3. All warnings and instructions should be read and
height when using this machine. proper instruction obtained prior to use. Use this
7. PROPER adjustable stop height depends on the equipment for its intended purpose ONLY.
exercise performed. 4. Inspect the machine before use. DO NOT use
Adjust as follows: machine if it appears damaged or inoperable.
• Remove weight from lifting bar/sled. 5. Do not exceed weight capacity of this equipment.
• For squats, perform the exercise and determine 6. ALWAYS use a spotter if using free weights.
the lowest comfortable position of the bar/sled 7. Balance the weight applied to this equipment
that ensures no spinal compression. For other and/or any barbell. Where applicable, use
exercises, perform the movement and determine retention devices to retain weight discs.
the lowest point of bar travel that is 8. Injuries to health may result from incorrect or
comfortable without the bar contacting your excessive training. Cease exercise if you feel faint
body. or dizzy. Obtain a medical exam before beginning
• Position both stop catches to stop the bar at this an exercise program.
point. Ensure that they are completely seated 9. Keep body, clothing, hair, and fitness accessories
on the stop rods or catch plate. free and clear of all moving parts.
• FOR SQUATS PERFORMED ON A SMITH PRESS: 10. Adjustable stops, where provided, must be used
NEVER PLACE THE STOPS BELOW THE HEIGHT at all times.
INDICATED ON THE EQUIPMENT. 11. When adjusting any adjustable mechanism (stop
• Load weights onto the lifting bar and carefully position, seat position, pad location, range of
perform the exercise. motion limiter, pulley carriage, or any other type),
8. DO NOT REMOVE THIS LABEL. REPLACE IF DAMAGED make certain that the adjustable mechanism is fully
OR ILLEGIBLE. engaged prior to use to prevent unintended motion.
12. Manufacturer recommends that this equipment be
secured to the floor to stabilize and eliminate
rocking or tipping over. Use a licensed contractor.
13. If equipment is NOT secured to floor: NEVER allow
resistance straps, ropes or other means to be
attached to this equipment, as this may result in
serious injury. NEVER use this equipment for
support during stretching, as this may result in
serious injury.
14. DO NOT REMOVE THIS LABEL. REPLACE IF
DAMAGED OR ILLEGIBLE.
Plate-loaded / Free Weight
EXCLUSIVE REMEDY
The exclusive remedy for any of the above warranties shall be repair or replacement of defective
Parts, or the supply of Labor to cure any defect, per the terms of the Commercial Warranty. All
Labor shall be supplied by the local Matrix certified technician. The Product must be located within
that service provider's service area. Products located outside service area will not be covered by
the Labor warranty.
EXCLUSIONS AND LIMITATIONS
1. This warranty applies only to the original owner and is not transferable.
2. Under no circumstances will MATRIX FITNESS be liable by virtue of this warranty or otherwise
for damage to any person or property whatsoever for any special, indirect, incidental, secondary
or consequential losses, damages or expenses in connection with exercise products.
3. This warranty is expressly limited to the repair or replacement of a defective Frame or Part.
Repair or replacement will be at the discretion of MATRIX FITNESS, and is the sole remedy of
the warranty.
4. Do not use equipment in any location that is not climate controlled, such as but not limited to
garages, porches, pool rooms, saunas, bathrooms, car ports or outdoors. Failure to comply
may void the warranty.
5. This warranty does not cover normal wear and tear – including but not limited to: cuts in
upholstery, damage caused externally that is not due to a manufacturer defect, improper
assembly or maintenance, or installation of parts or accessories not originally intended or
compatible with the MATRIX FITNESS Product as sold.
6. This warranty does not cover damage or failure due to accident, abuse, corrosion, discoloration
of paint or plastic, neglect, theft, vandalism, fire, flood, wind, lightning, freezing, or other natural
disasters of any kind, power reduction, fluctuation or failure from whatever cause, unusual
atmospheric conditions, collision, introduction of foreign objects into the covered unit, or
modifications that are unauthorized or not recommended by MATRIX FITNESS.
7. Parts reconditioned to As New Condition by MATRIX FITNESS or its vendors may sometimes
be supplied as warranty replacement parts and constitute fulfillment of warranty terms. Any
warranty replacement parts shall be warranted for the remainder of the original warranty term.
This warranty shall NOT apply to the following:
1. Failure to provide reasonable and necessary maintenance as outlined in the Owner's Manual.
2. Software limitations and upgrades.
3. Batteries or other consumable goods.
4. Cosmetic items.
5. Repairs performed on equipment missing a serial number or with a serial number tag that has
been altered or removed.
6. Service calls to correct installation of the equipment or instructing on use of equipment.
7. Pick-up, delivery or freight charges involved with repairs.
8. Any labor charges incurred beyond the applicable labor warranty.
MATRIX FITNESS expressly disclaims all other warranties, express or implied, including but not
limited to all warranties of fitness for a particular purpose or of merchantability. This warranty gives
you specific legal rights, and your rights may vary from state to state.
