Discount Car Stereo BLU-BKR235 Quick Installation Manual

Bluetooth kit for becker aux ready radios
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

Enlarged version
Courtesy of: DiscountCarStereo.com
Serving the internet community since 1995
|
This radio is for illustration purposes only
BLU-BKR235
Quick Bluetooth Installation Guide for Becker AUX Ready Radios
Created June 19, 2015
Revised: February 13, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLU-BKR235 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Discount Car Stereo BLU-BKR235

Summary of Contents for Discount Car Stereo BLU-BKR235

  • Page 1 Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 This radio is for illustration purposes only BLU-BKR235 Quick Bluetooth Installation Guide for Becker AUX Ready Radios Created June 19, 2015 Revised: February 13, 2020...

  • Page 2: Installation

    Introduction: Thanks to the BLU-BKR235 Kit you can keep the radio and car you love while enjoying Bluetooth features only available on new cars. With Bluetooth Technology and your Smartphone's Voice Recognition application (Siri or Google Now); you can initiate hands-free calling, launch Navigation, music streaming or any other application.
  • Page 3 Microphone on 10 ft. cable Visor clip Carefully route microphones 1/8” plug behind the dash and connect to module “MIC” input jack (See Fig 9). Fig. 4 Fig. 9 Module Remove tape backing from control button (See Fig. 10) and secure button to dash area within drivers reach Fig.
  • Page 4 CDR30 & CDR31 Radio Installation With radio removed disconnect the factory Quadlock plug (harness) from Radio (See Fig. 13) Fig. 11 Control button terminals Connect installation harness 16-pin plug to module (See Fig. 12) and proceed to “Enabling Aux function” section on following page Fig.

  • Page 5: Operation

    Operation: The most important steps in this process is enabling AUX function within the Becker radio menu. The following steps are required to enable “AUX” otherwise the adapter will not perform as intended. Note: Becker CDR210, CR210, PCM1 radios do not have AUX function. Simply enter CD Changer mode to operate Bluetooth mode Enabling AUX function Fig.
  • Page 6 Radios with 3 Function buttons (i.e. BE4527) Radios with ☼ button: (i.e. BE6104) Turn radio ON. Press and hold Function button #2 (center) for more than 4 seconds. Turn Radio “ON” The accompanying menu appears on the display. 2. Press and hold the ☼ button for about 8 seconds. Press the multifunction button located directly under “AUX”...
  • Page 7 Sound 5 (BE7077 Sprinter Van) Becker BE7801 Infotainment (Ferrari, Maserati) Press the TP button for more than 2 seconds Turn radio ON. Press multifunction button “AUX” Press the repeatedly until EXT menu appear. Select Ext audio source Turn Rotary control knob clockwise and select EXT AUX. press the right control knob to select “ON”...

  • Page 8: Bluetooth Pairing And Connection

    Bluetooth Pairing and Connection Test Operation This process is required the first time you use the BLU-BKR235. After initial Phone Calls Incoming call mode (phone ringing) pairing, the BLU-BKR235 automatically reconnects to paired device upon 1) Single Press Answer entering vehicle.
  • Page 9 Email support@discountcarstereo.com © 1995-Feb-20 Discount Car Stereo, Inc. All rights reserved. Information in this document is subject to change without notice. Other products and companies referred to herein are trademarks or registered trademarks of their respective companies or mark holders.
