Discount Car Stereo BKR-HF Quick Start Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Courtesy of:DiscountCarStereo.com
Serving the internet community since 1995
Radio for illustration purposes only
BKR-HF
Quick Start Bluetooth Installation Guide for Becker Radios with Aux Menu Option
Created June 3, 2016
Revised: December 22, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BKR-HF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Discount Car Stereo BKR-HF

Summary of Contents for Discount Car Stereo BKR-HF

  • Page 1 Courtesy of:DiscountCarStereo.com Serving the internet community since 1995 Radio for illustration purposes only BKR-HF Quick Start Bluetooth Installation Guide for Becker Radios with Aux Menu Option Created June 3, 2016 Revised: December 22, 2019...

  • Page 2: Installation

    Voice Recognition application (Siri, Google Now, Assistant etc.) and initiate phone calls and launch applications. Thanks to the BKR-HF Kit you keep the radio and car you love while enjoying Bluetooth features only available on newer vehicles.
  • Page 3 Connect blue plug (See Fig. 4) from installation harness (See Fig. 4) to Connect power supply harness 8-pin plug to radio 8-pin connector (Chamber A) chamber C-3. Also ensure 3.5mm male plug from installation harness is mated with audio jack on module pigtail wire (See Fig. 4a) Connect supplied 3.5mm male to male cable (See Fig.
  • Page 4 and phone dialog (cable is 6ft. long). We recommend completing the wherever your installation demands without drilling) rest of the install prior to securing the control/mic button to the dash. Once you decide on a location simply remove tape backing from Flush to Dash or Panel (drilling required) control /mic button...

  • Page 5: Bracket Mount

    Bracket Mount (No drilling) Locate a flat surface at location of choice within 3.2 ft. of radio and mount USB support bracket (See Fig. 16) to surface using adhesive/tape or screws. Fig. 13 Module USB port Push USB head (See Fig. 14) until it snaps in place and flush with mounting surface (See Fig.
  • Page 6 Tuck and secure any extra wire away from moving parts and test operation Alert! Factory 12-pin micro Quadlock (Green for AUX and Blue for See Initial Radio Setup Bluetooth) are pictured above. The Green micro-Quadlock must be disconnected and replaced with black micro-Quadlock plug on adapter harness.

  • Page 7: Initial Radio Setup

    Initial Radio Setup: A very important step in this process is enabling AUX function within Becker radio menu. Note: Becker CDR210, CR210, PCM1 and others do not have an “AUX” function and not compatible with this part. Enabling AUX function Fig.
  • Page 8 Radios with ☼ button: (e.g. BE6104) Nav Traffic Radios Turn Radio “ON” Press the "Radio" button to enter Radio mode. 2. Press and hold the ☼ button for about 8 seconds. Press the "Navi" and "F10" simultaneously Press "Next" until the AUX input, Changer Res screen 3.
  • Page 9 Sound 5 (BE7077 Sprinter Van) Becker BE7801 Infotainment (Ferrari, Maserati) Turn radio ON. Press the TP button for more than 2 seconds Press the repeatedly until EXT menu appear. Press multifunction button “AUX” Turn Rotary control knob clockwise and select EXT AUX. Select Ext audio source Press the CD button repeatedly until “AUX”...

  • Page 10: Bluetooth Operation

    Bluetooth Pairing/Connection Bluetooth Operation This process is required the first time you use the BKR-HF. After initial pairing, Set the radio to AUX mode the BKR-HF will automatically reconnect with the paired phone upon entering the Adjust the Radio Volume vehicle.

  • Page 11: Package Contents

    Bluetooth conversations in others. Congratulations, you’ve just updated your vehicle to support new technology while preserving the original radio and dash components. Enjoy! Bluetooth Adapter Comparison Chart: Feature BLU-BKR A2D-BKR BT45-BKR A2DIY-BKR BKR-HF Fig. 22 CD Changer Retention 3.5mm AUX input ✓ ✓...
  • Page 12 3. Connect push-to talk button (blue or green phone) to splitter “Control button” jack as seen in Fig. 20 (smaller jack) 4. Connect splitter harness male plug to module “Mic” input (blue) as seen in Fig. 25 Fig. 23 Installation: Fig.

  • Page 13: Frequent Asked Questions

    How can I play a non-Bluetooth device (e.g. MP3 Player, Satellite Radio etc.) if the BKR-HF connects to the Radio AUX port? The BKR-HF includes a 3.5mm input jack for users to connect and play any audio device with a 3.5mm output. Press control button 4 times to activate AUX input 6.
