EP675/ LA-7021AC
Please read the manual before your first use. Keep this manual
Radio DAB+/FM
Instruction manual
safe for future reference!
1. PRODUCT DESCRIPTION
1. Antenna
2. Volume down -
3. Volume up +
4. IN button*
5. Menu button
6. POWER/ MODE button
7. Alarm button
8. Program button
9. Prev button (P-)
4* Information about the
radio station
1
English
10. Next button (P+)
11. SCAN/SELECT button
12. Earphone jack
13. Reset hole
14. USB port

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 44445 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eurotops 44445

Summary of Contents for Eurotops 44445

  • Page 1 English EP675/ LA-7021AC Radio DAB+/FM Instruction manual Please read the manual before your first use. Keep this manual safe for future reference! 1. PRODUCT DESCRIPTION 1. Antenna 10. Next button (P+) 2. Volume down - 11. SCAN/SELECT button 3. Volume up + 12.

  • Page 2: Battery Charging

    2. BATTERY CHARGING 1. Connect the mini USB end of the USB charging cable to the USB port of DAB+/FM radio. Connect the other end to the USB port of computer. A battery symbol displays on the screen, indicating the radio is charging. Charging time for full charge (Computer): About 4/ 5 hours –...

  • Page 3: Using Your Dab+ Radio

    IMPORTANT REMARKS ON DAB and FM • Pull out the antenna completely before scanning. • On first use, if no DAB or FM stations are preset, the radio will do a scan after switching to DAB or FM mode. • The radio can store up to 20 DAB and 20 FM stations.
  • Page 4 4. Press P+ or P- to select a preset number you wish allot to the station (for instance : 01. (EMPTY). 5. Then, press “SCAN/ SELECT” button to save. The message “PRESET 01 is stored” displays and the radio goes back to the progamme station; a star with the preset number displays, at bottom of display in the middle.
  • Page 5 3.2.5.3 DRC (Dynamic Range Control) « DRC » is intended to control the sound or noise when listening in a noisy environment. Note:This function may not be available on some DAB+ stations. After entering DRC menu: 1. Press P+ or P- to choose among the 3 DRC options below : DRC Off DRC Low DRC High...

  • Page 6: Manual Time Setting

    Notes: The options proposed are the following: “Set time and date”/ Auto update/ Set 12/ 24 hour/ Set date format. After selection of some options, the green star icon displays beside the chosen option. Note: To update the time automatically or set time manually, see next sections. 3.2.6.3 AUTOMATIC UPDATE OF TIME After entering time menu (follow steps 1 to 5 below in section 3.2.6.2: Time menu if you...

  • Page 7: Alarm Menu

    3.2.6.7 ALARM MENU You can set 2 alarms: Alarm 1 and Alarm 2. After entering Alarm menu, “Alarm 1 setup” displays. 1. Press P+ or P- to select Alarm 1 or Alarm 2. 2. Press “SCAN/SELECT” to enter. The hour digit starts flashing. 3.

  • Page 8: Sleep Mode

    3.2. 6.8 BACKLIGHT This menu enables the setting of duration of light with the option “TIMEOUT”, setting of brightness level and activation/ deactivation control of the brightness level with options “ON LEVEL” and “DIM LEVEL”. For example, if you select “10 seconds” for “TIMEOUT” and select “ON LEVEL”...

  • Page 9: Factory Reset

    3.2.6.9.3 FACTORY RESET FACTORY RESET (Activation/ Deactivation) “Restarting” displays on the screen. The radio starts carrying out the full scan. After it finishes, it switches to DAB radio whatever you are in FM or DAB menu. 3.2.6.9.4 SW VERSION= Information about software version. This option does not need to be set.

  • Page 10: Troubleshooting Guide

    3. Press and hold “PROGRAM” for 3 seconds. The message “PRESET STORE” displays. 4. Press P+ or P- to select a preset number which you would like to allot to the station (for instance : 01.). 5. Then, press “SCAN/ SELECT” button to save. The message “PRESET 01 is stored” displays and the radio goes back to the radio station.

  • Page 11: Technical Specifications

    This may occur if the broadcaster The display is The unit will try re-tune. If not perform a changes the label of a service or blank new scan removes a label while tuned. I can hear a Battery power is low. Recharge the battery.

  • Page 12: Maintenance

    If the power cable is damaged, it must be replaced by the manufacturer, its after-sales service, or a person qualified in this area in order to avoid accidents. Imported by EML/ Prodis 1 rue de Rome 93110 Rosny-sous-Bois-France/ Made in PRC Marketed by EUROTOPS VERSAND GMBH D-40764 LANGENFELD...
