RYLE RAINFALL SHOWER SET
INSTALLATION INSTRUCTIONS
Before you begin, read the installation instructions below. Observe all local building and safety codes.
Unpack and inspect the product for any shipping damages. If you find damages, do not install. Contact Customer
Service at 1.866.855.2284. If you need assistance or have questions while installing your shower set, contact
Customer Service.
We recommend consulting a professional if you are unfamiliar with installing bathroom fixtures, and plumbing.
Signature Hardware accepts no liability for any damage to the plumbing or wall, or for personal injury during
installation.
TOOLS AND MATERIALS:
Screwdriver
VALVE EXPLODED VIEW:
1
SD10101000200
2
M0105004
3
SD15617000100
4
SD10117000400
5
SD10117000500
6
SD15619000300
7
OXQ50030
8
FX0402
9
SD10117000600
10
SD10119000800-1
11
SD10119000700-1
12
M0305022
13
SD10119000900
14
M0805032
15
SD10119001000
16
SD10119001100
17
M110405
Teflon Tape
